Upgrade Usb 5 Axis Cnc Breakout Board Interface Adapter For Stepper Motor Driver

US $620

Los Angeles, United States
Jun 9th

Open on mobile:
QR code

Upgrade Usb 5 Axis Cnc Breakout Board Interface Adapter For Stepper Motor Driver More.. 5 Axis USB Breakout Board For CNC Single Stepper Motor Driver Controller Description The latest upgraded salable 5 axis breakout board is speacilly designed for the CNC single axis stepper driver controller, such as M542, M542H, MA560, MA860H, 2M542, 2M982, DM542(A), DM860(A) etc single axis stepper driver controller series. With this 5 axis breakout board, any 1-5 single axis stepper driver controllers can be directly controlled by the PC via the MACH3, EMC2, KCAM4, etc. Features Upgraded circuit, work more peacefully and steady than the previous version Maximum support 5-axis stepper motor driver controllers Two ways to get power, 5V DC power supply or USB port to get power from PC directly Two-stage signal processing, smooth signal transmission, powerful anti-jamming 5-input interface to define the Limit, Emergence-Stop, Midpoint-Alignment, Cutter-Alignment, etc. Relay output control interface, accessed by the spindle motor or the air pump, water pump, etc. 5-axis work LED display, visually display the working condition of the stepper driver controller Wiring Diagram Electrical properties (ambient temperature Tj = 25 °C pm). Input Voltage 5V DC power supply or USB port to directly get power from PC Compatible Stepper Motor Driver Max 5 single axis stepper motor driver controller Drive type Pulse + Direction + Enable Signal Control Net/Total Weight Approx 80g/300g Dimensions 90 * 82 * 15mm (L*W*H) 1 x 5 Axis Breakout Board 1 x DB25 Parallel Cable 1 x USB Power Cable 1 x CD Shipping Payment Warranty Estimated Delivery Time USA (excl. Alaska, Hawaii, Puerto Rico) USPS First-Class Package/UPS Ground/USPS Priority 3-7 business days Other Countries (May depart from other stock location) International Airmail Service 10-20 business days Please DO CONTACT AND CONFIRM with us BEFORE you bid IF you: - need the item urgently. - require that the item should be delivered within a certain time. - have any other questions/requirements about delivery. Remarks: *Usually, your order will be dispatched before the next working day after the full payment is cleared when stock lasts. *Notification will be sent after your order is dispatched, please check you email or ebay order records for date of dispatch. *It is not guaranteed that parcel should arrive within the time stated above. However, 95%+ parcels will be delivered within the reference time. *Please contact us if you have any trouble in receiving your orders. We will help you to track them. PayPal: We accept PayPal (Allows you to pay by credit cards, debit cards or echecks securely with NO surcharge) * If you have difficulty to make payment by PalPal please contact us for alternative payment method. Remarks: *Please send payment within 5 days after auction ends. All sales are final, shipping and handling costs are also NOT negotiable. *We will use your PayPal shipping address as the delivery address. *Please make sure that your shipping address is correct. 30 Days Money Back Guarantee: If you are not satisfied with the item purchased from us. Please inform us in writing(e.g. e-mail, eBay message, fax, letter) within 30 days of receipt of goods. We will guide you to return and refund the item. Please note that the postages / custom fees(if any) spended in such an order are on the customer's cost. Free Replacement: If you receive a not-as-described (e.g. defective, incorrect, part missing) item, please contact us when you get the item. We will arrange a replacement as soon as the case is confirmed. Suppliers Warranty: We offer ONE YEAR warranty on this product. If your item has any warranty issue please contact us for a satisfying solution. Requirements: *All qualified returns/replacement must be guided by us. We may not accept your return without informing us in advance. *Customs fee, handling charge, postage and insurance are on customers cost and not refundable.
