Ups Dental Digital X Ray Mobile Film Imaging Machine/ Autoclave Steam Sterilizer

US $529.00

Fullerton, California, United States
May 25th

Open on mobile:
QR code

Descriptions: BLX-8Plus Product introduction: This model combines the advantages of similar products found at home and abroad; it eliminates the shortcomings of the on-frequency X-ray machine (high current intensity and excess amounts of scrap x-rays).Using a Toshiba 0.3 micro-focus tube.The tube voltage frequency of this machine is 30 KHzand the tube current is 1 MA. The radiation scope is at an angle of 24 degrees located within a distance of 1.2 meters ahead. This is an innovative Chinese design named the "Green X-ray Machine." Warning: After turning on the machine, wait for 1 minute, the voltage can be stabilized before normal useAfter each photo, you have to wait 30 seconds before you can take a normal photo TECHNICAL SPECIFICATIONS Tube Voltage 65kv Tube Current 1mA Time Exposure 0.1~~1.8s High pressure generator 30kHz DC Rated Power 60w Focal Spot To Skin Distance >20CM Focus Spot Size 0.3mm(TOSHIBA) Charger Input Voltage AC110V220V Supply Frequency 30Hz Radiation Leakage <20ugy/h Battery 24V DC 2600MA Weight 4.3KG Dimensions 37 cm×31 cm×28cm (L×W×H) Reference of the Angles ' Tooth Upper Lower 1-2 42 -15 3 45 -18 4-5 30 -10 6-8 28 -5 Reference of the time of exposure Tooth Adult Child Central & Lateral 0.2-0.3s 0.2-0.3s Cuspid & 1st Bicuspid 0.3-0.4s 0.3-0.4s Upper 56 0.5-0.6s 0.5-0.6s Upper 78 1.3-1.8 s 1.2-1.5.s Lower 56 0.5-0.6s 0.4-0.5 s Lower 78 0.6-0.8 s 0.5-0.7 s Packing List: Main machine 1pcs Power line 1pcs User manual 1pcs Operation of the Main Unit : Upon receivingopen the box and check the product for possible damage during shipping. Make sure the fittings on the encasement list are packaged within the box. Turn on the Powerthe pilot lamp will be light up.During this timethe digital tube will show the fore setting time. Now the equipment is in standby mode. Setting the time (Skip to next step if unneeded) →then press "+" and" -" to set the time needed (time range is 0.1-1.8seconds); The equipment is now in standby mode. Put the Tooth film plumb behind the tooth which is going to be taken picture and be as close as possible (the smooth side stick to the tooth) Keep the ball head plumb to the tooth projection position; Have the ball headtooth and tooth film steadily mutually plumb. After positioninguse the ON/OFF on the main Unit to take pictures. (Notice: gently press 0.5 sec to turn it on) Points for Attention Make sure the angle of filmtoothand ball head are properly aligned when taking a picture. Keep them steady until the last step of picturing; making sure that there is no change in any of their positions. Remember to turn the power 0ff when work is done. Charge the battery if the machine cannot work and the red lamp lignt After turning the power onwait one minute before taking picturesthis allows the ray to provide a steady output. The equipment switches into protection mode automatically when the voltage is incorrect. If this occurs it will not be able to carry out the normal work of filming. When taking picturesthe ON/OFF button could stop the objection and then the machine goes back to the preparation mode. Use high quality tooth film and developing liquid to make clear pictures. Handle the ball head gently while in useso as not to damage the delicate component. If a situation occurs preventing the machine from taking regular pictures contact the seller to solve the problem instead of trying to service the product yourself. Keep the tooth film and the liquid in a proper place and use them within the shelf-life period. Development of films should be performed at temperatures ranging between 23-25 degrees Celsius to ensure the image quality. Other requests accordance with the scope of the technical parameters. Please read the manual carefully before using. ///////////////////////////////////////////////////////////////////////////////////////////////////////////////////// BLX-5 Features: 1.) The tube voltage frequency of this machine is 30 KHz, and the tube current is 0.2 MA. The radiation scope is at an angle of 24 degrees, located within a distance of 1.2 meters ahead. 2.) Toshiba 0.3mm x 0.3mm micro-focus tube 3.) No protective operation room is needed when installing the complete machine 4.) Flexible adjustment of position and angle of handpiece 5.) Compact in volume, light in weight, convenient for carrying 6.) Time is adjustable, high contrast of picture, imaging in focus 7.) There are vacuum components and high-pressure parts inside of the machine, so for your safety and the maintenance of the machine 8.) The tube head is equipped with excellent radiation-shield protection (except the radial mouth, and tests have shown that the radial index is zero. Safety is guaranteed. 9.) Non-film inspection and storage can be realized when corresponding to a sensor Specifications Voltage: 110v±10% Power: 24V 8000MA Charger: 110V, 50Hz Tube current: 0.1mA Rating: 60W Frequency: 30 KHz Exposure time: 1-9 seconds optional Leak radiation: < 20μgy/h(12lb) Focus Skin Distance: >20cm Tube voltage: 60KV Relative Humidity(RH) < 80% Storage conditions: 5-40 degrees Celsius, relative Humidity Net weight: 5.5 kg Dimension: 47 x 42 x 19 cm Content: Main Unit x 1 Dental Film Position x 1 Charger x 1 English Manual x 1 Warranty Card x 1 ////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////// LK-C27 Fetures: 1.This portable dental X-ray unit is high frequency machine. 2.The body is small, light weight and nearly no radiation. 3.It has excellent image quality, portable storage, save more space. 4.It uses high frequency and DC international power supply. 5.All of the components installed in the central PC board concentrated. Shock,set-up, electron tubes, all of them are insulation vacuum, sealed stereotype protection. 6.There are also manual buttons installed on the surface of shell, as well as batteries and charges7.This unit mainly suitable for oral pre-treatment for learning internal organizational structure, root depth and so on, is indispensable in daily life clinic equipment, especially for dental implant surgery. 8. It also can connect with sensor, is great convenience. 9. The battery is durable, it can take about 5 hundred images after fully charged. 10. It can be connected with intra-oral digital X-ray imaging system. Warning: After turning on the machine, wait for 1 minute, the voltage can be stabilized before normal useAfter each photo taking, you need to wait for the normal value to return before taking a normal photo Technical Parameter: Tube voltage: 60KV Tube current: 1mA Exposure time: 0.1--2.0s Frequency: 30KHz Rate power: 60VA Distance from skin to cone: 130mm Tube focus: 0.3mm*0.3mm Battery: DC14.8V 6400mAh Charger input voltage: AC100V-240V±10% Output voltage: DC16.8V Ambient temperature: 5~40 Relative temperature: <75%RH Net weight: 2.5KG Gross weight: 3.5KG Size(mm): 138*165*185 Package size(mm): 220*240*275 Packing List: Main body 1pc Charger 1pc User manual 1pc Statement The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If so, you can bid it on this item only if you are an authorized purchaser. If the item is subject to FDA regulation, I will verify your status as an authorized purchaser of this item before shipping of the item. Seller name:Dentalinchina City,State:SHENZHEN,China Telephone number:0755-6895621 Payment We accept PayPal Only! All payments must be made within 7 days after the auction ends. Non-paying bidders will be reported to eBay. Please don't buy an item if you can't/won't pay for it. Paypal is the easiest way to pay for items on eBay. Please make sure your Paypal and eBay accounts have the same physical address used for delivery and the same e-mail address to ensure payment confirmation. Shipping: Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Shipping The goods you odered will be posted out in the second working day after the paymet has been made. (We will inform you via email if any delay occured due to holiday events. General shipping time is between 7-12 working days. (After the shipping started, the order will be monitored and the track of the item will be posted on paypal. Return If the item you received is damaged or defective,Please contact us immidately.We will free exchange or refund. We will pay the return shipping costs if the product is defective or the return is a result of our error. If the item is returned for any other reason you are responsible for the return shipping charges. You can return your purchase for up to 15 days from the date of delivery. No refund will be issued if the product shows signs of use. Returned package must be in the original packaging, everything must be in new condition, No missing parts. Our guarantee does not cover accidental damage or wear of product caused by customer.Thank you very much for your understanding! Feedback Your feedback is VERY important to us ^_^ Please leave us positive feedback, an positive feedback will be automatically left for you once we receive your full payment. Please leave us with any concerns prior to leave negative feedback, as we can only correct issues when we are aware of them. We understand the concerns and frustrations you might have, and will try our best to resolve the isuues. Contact Us Serivce is our #1 priority ! If you contact us immediately after placing the order, we will make every effort to assist you with your change request. Unfortunately, we can not make changes or cancel an order once it has shipped. We offer the best items at the best prices. We strive to exceed all your expectations and put a smile on your face. Your experience will be a pleasant and effortless one when you buy . We stand behind our products and pride ourselves on OUTSTANDING customer service. We guarantee that you will be delighted with your purchase or we will gladly and promptly issue you a refund or make things right! Statement:The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. So you can bid it on this item only if you are an authorized purchaser. If the item is subject to FDA regulation,We have to verify your status as an authorized purchaser of this itm before shipping of the item. Thanks for your understanding! Payment 1.We accpet the payment via paypal, PayPal is safest, quickest and secure for seller and buyer. 2.All major credit cards are accepted through secure payment processor PayPal. 3.Payment must be received within 7 business days of auction closing. Shipment 1.We accpet the payment via paypal, PayPal is safest, quickest and secure for seller and buyer. 2.Tracking info of your parcel is available. 3.Returns could be accepted within 60 days after receipt of the item. 4.Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer is responsibility. Please check with your country is customs office to determine what these additional costs will be prior to bidding/buying. Destination Delivery Time Working Days 7-12 10-15 15-25 25-40 >50 US Item arrived 80% 10% 8% 1% Refund ASIA Item arrived 30% 40% 20% 10% Refund EU Item arrived 20% 20% 50% 10% Refund AU Item arrived 30% 30% 20% 20% Refund Other Countries Item arrived 5% 10% 10% 60% -- Return & Refund policy We accept returned in some exceptional cases, please send message before return item(s) otherwise returned item(s) will not be accepted. Buyer is responsible for return shipping cost and we will ship the replacement or make the refund within 2 days after returned item is received. If it is our fault, we will be responsible for the return postage. Feedback We will leave feedback upon receipt from cutomer. If you are dissatisfied for any reason, please don't be quick to leave negative/neutral feedback or open a dispute. We work hard to make sure EVERY CUSTOMER 100% SATISFIED and resolve any problem for you and always leave positive feedback to all our customers. If you are satisfied with the product you received, please leave us positive feedback and 5 scores DSR. Please call five satisfaction Item as described Communication Shipping time Shipping and handing charges About Us We're one of the largest online dental suppliers based on many qualified manufacturers in china. We supply all dental items with very nice qualities and the best reasonable prices for worldwide dentistry students, dentists, and other professionals. Any interests or questions, please do not hesitate to send message. Looking forward to our friendly & win-win cooperation.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	China
Brand	AZDENT
MPN	GJ1170100101
Intended Use/Discipline	Dental Laboratory, Dentistry, Endodontics
