Usb 4axis 2.2kw 6090 Cnc Router Metal Engraver Milling Drilling Machine Eu

US $3,025.00

Basel, Switzerland
Aug 17th

Open on mobile:
QR code

6090 router 4 Axis+2.2kw Spindle motor +VFD +USB Port Metal Wood Engraver with tool sensor 2200W-6090T1-USB+2200W-6090T2-USB+2200W-TS009USB X axis: SFU1605 Ball Screws; Y axis: SFU1605 Ball Screws; Z axis: SFU1204 Ball Screws Description: Router engraving machine parameters: Model: 6090GZ Outside dimension: 1150x970x650mm(LxWxH) Working platform size: 1045x720mm(LxW) Frame Material: The whole machine used 6061 aluminum profiles Max. Feeding height: 140mm(From base of Z axis to platform) X, Y, Z Working Area: 600x900x150mm Sliding unit: X axis: SFU1605 Ball Screws; Y axis: SFU1605 Ball Screws; Z axis: SFU1204 Ball Screws Drive unit: X axis: 20 High intensity round rail; Y axis: SBR20 high-strength aluminum base rails; Z axis: 12 high-strength round rail Store category Sign Up Now ! You may also like USB 4Axis 2.2KW 6090 CNC Router Metal Engraver Milling Drilling Machine EU Product Description 6090 router 4 Axis+2.2kw Spindle motor +VFD +USB Port Metal Wood Engraver with tool sensor 2200W-6090T1-USB+2200W-6090T2-USB+2200W-TS009USB X axis: SFU1605 Ball Screws; Y axis: SFU1605 Ball Screws; Z axis: SFU1204 Ball Screws Description: Router engraving machine parameters: Model: 6090GZ Outside dimension: 1150x970x650mm(LxWxH) Working platform size: 1045x720mm(LxW) Frame Material: The whole machine used 6061 aluminum profiles Max. Feeding height: ≤140mm(From base of Z axis to platform) X, Y, Z Working Area: 600x900x150mm Sliding unit: X axis: SFU1605 Ball Screws; Y axis: SFU1605 Ball Screws; Z axis: SFU1204 Ball Screws Drive unit: X axis: ø20 High intensity round rail; Y axis: SBRø20 high-strength aluminum base rails; Z axis: ø12 high-strength round rail Stepping motor: two-phase 3A (with handwheels) Driving Power for Stepping motor: AC110, Output DC 24V, 10A Maximum Idle speed: 1500mm/m Working Speed: 50-1500mm/min (different material with different speed settings) Spindle motor: 2200Whigh-speed variable frequency spindle motor, ER20 chuck, matching 6mm bur 1Water cooled spindle motor can work longer time than air cooled motor. 2Water cooled spindle motor has higher stability and better concentricity than air cooled motor. Variable-frequency Drive(VFD): AC110V, 2200W, 0-400Hz (built-in Control box ) tips1. The spindle motor must connect with the VFD. 2. It cannot directly connect with the supply voltage (AC110V). 3. Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor.) Drive of Stepping motor0-3.5A adjustable four-axis drive(TB6560AHQchip, 24V power supply, 2, 4, 8, 16 Subdivision settings, Factory setting: 8 subdivided) Repositioning precision: ≤0.05mm Speed: 0-24000r/m Cooling method: Water cooling, Matching heat dissipation water pump Spindle precision: Radial runout≤0.03mm Carving command:G code/TAB file/nc/TAB /NCC/file Protection: Emergency stop button Communication interface: through USB PORT connect with computer Input Volts: AC110V Gross weight of machine:About 145kg/320lb Update function: with limit switch Application industry: Woodworking industry: sculpture, round carving, wooden handicraft processing Advertising signs: logo making, cutting acrylic , plastic molding, suit for making a variety of materials advertising decorative products Other industries: The engraver could do shadow-carved, sculpture which widely used in the gift industry; can be used in aluminum cutting industry,such as aluminum, aluminum-plastic plate, aluminum honeycomb panels, aluminum, 3D engraving process, Artificial plate, cutting LED and neon letter , making plastic light box model; also can engrave on acrylic, copper, PVC board, artificial stone, MDF board, and other metal sheet. Feature: 1. The NEW 2.2KW water-cooled VFD is available operating for long time, which can reinforced the processing ability of the machine and can be used to engrave on aluminum alloy and hard wood. 2. water cooling spindle works more stable and durable. 3. High quality accurate ball Screws drive make the engrving more precision. Anti-blackflash, high precision, long life circle. How to use: 1. Assembling and locating the Engraving machine on steady desk well. 2. Make sure that your computer has a USB port output. 3. Place the control box in a ventilated dry place where there is no dust, no moisture 4. Connecting the control box with the Engraving machine and you computer and make sure the plug will not come off. 5. Correctly connect the machine with the controller. Don't suspended the cable which connect the Spindle motor with axis(X, Y, Z, A). Otherwise, it will damage the driver of the controller. 6. Correctly instal the Spindle motor and the heat pump. The heat pump should be covered completely in the water, then turned on the electric current to check whether the water-cooling system working well. 7. Before turn on the machine, please check all the cable and water- cooling system to make sure they are working fine. 10. You can enjoy making you dream with using our Engraving machine now. Package list: 1X main unit (Frame) 1X main unit (working base) 2X Fence baffle 1X control box 1X A axis 1X Sinal cable for A axis 1X pump 1X USB cable 2X cutter 2*6mm 2X cutter 3*6mm 10X 4*7mm round head 6X 4*10mm black Inner six angle screw with nut 8X 5*20mm black Inner six angle screw 4X 5*8mm Flat Philip's head screw with nut and gasket 8X 6*24mm BALCK FLAT Inner six angle screw 12X Aluminium fastener 1X 13-15# Wrench 1X 14-17# Wrench 2X six angle Wrench(3mm) 2X six angle Wrench(4mm) 1X Teflon tape 2X Fuse (5A) 1X Power cable 1X Manual 1x Tools Setting Auto-Check Instrument for Engraving Machine. Pease note: We only sell engraver machine not include the software. If you need full version software, please buy it at official web. Payment Delivery details Return policy Feedback Con-tact us Payment We accept PayPal payment only Payment must be received within 7 days after order is made. Fees such as import duties, taxes are not included in the item price or shipping costs. These charges are the buyer's responsibility. Delivery details Please pay attention to the payment in advance: according to experience, a transfer takes 2-3 days depending on the bank until the money is over. As soon as your payment is received, we will send you the goods within 48 hours. On Saturday and Sunday there is no delivery and no shipping. Please note: We ship parcels from Germany warehouse to europe buyers! 3-7 days: GERMANY 5-10days: Other countries We promise that every item has been sent. But sometimes there is also 0.3% package lost during transport . If this happens after we have confirmed this with the post, we will send you the package again as soon as possible or refund the money immediately. Return policy Your satisfaction is our ultimate goal. We work hard to earn your trust and future business. Our certified technicians have tested each item before shipping. The unit comes with 1 year limited warranty on all manufacturing defects. a) If you receive a defective item, Please tell us the problem in details and Please con-tact us within 14 days after you receive the package. b) What you returned must be intact and in its original packaging as received . Customer is responsible for shipping costs of the returned item caused by misorder,or don't need it anymore. c) We will cover the cost of shipping if the item is defect when you received. Or We will send you a new unit or refund the full payment you paid. Feedback Thanks for buying my business. If you have any problem with the item, if you have got it, please do not hesitate to contact us. We will provide you the best solution for any problem with the item. We would be delighted if you kindly contacted us before requesting a return or leave negative feedback. Con-tact us Business Hour : Monday To Friday: 8:30 AM to 5:00 PM (Beijing China time) Due to time zones, our reply to your questions may not be immediately. But within above working time, we will reply you-= within 24 hours. If it's non-workdays, please kindly be patient and wait till Monday. Please con-tact us with ebay message. Please feel free to con-tact us if you have any questions. Feedback On Aug-17-21 at 02:38:01 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	shipping notice	Can not ship to Puerto Rico,Alaska/Hawaii
warranty	life-time
Frame Material	The whole machine used 6061 aluminum profiles
Communication interface:	USB PORT
Max. Feeding height	140mm(From base of Z axis to platform)
MPN	Does Not Apply
X,Y,Z Working Area	900(Y)600(X)140mm(Z)
Brand	Unbranded/Generic
X axis	SFU1605 Ball Screws
Outside dimension	1150970650mm(LWH)
Y axis	SFU1605 Ball Screws
Working platform size	1045720mm(LW)
Model	6090GZ
Machine Type	Metal Engraving Machine
Z axis	SFU1204 Ball Screws
Control	CNC
Carving command	G code / TAB file / nc file / NCC file
Power Source	Electric
VFD	AC110V, 2200W, 0-400Hz(built-in Control box
Modified Item	No
Protection	Emergency stop button
Modification Description	NO
UPC	Does not apply
