Usb-6501 National Instruments 779205-01 24-ch 5v Ttl Digital I/o And Ni Daq

US $59.00

Winter Springs, Florida, United States
Jan 29th

Open on mobile:
QR code

NI USB-6501 Low-Cost USB Digital I/O Device by National Instruments Qty: 1 Part No: USB-6501 Mfr: National Instrumants Condition: New This listing is for one National Instruments USB-6501. USB-6501 National Instruments 779205-01 24-CH 5V TTL Digital I/O and NI DAQ The NI USB-6501 is a portable digital I/O device that provides reliable data acquisition and control at a low price. With plug-and-play USB connectivity, the USB-6501 is simple enough for home/academic applications but robust and versatile enough for laboratory/industrial applications. The board-only version is ideal for embedded OEM applications. The USB-6501 is a full-speed USB device that provides 24 DIO lines and a 32-bit counter. The 24 digital lines are arranged in three ports: P0.<0..7>, P1.<0..7>, and P2.<0..7>. P2.7 can also function as a 32-bit counter. You can individually program each of the USB-6501 DIO lines as a DI or DO line and use the DIO lines to monitor or control digital signals. All samples of the DI lines and updates of the DO lines are software-timed. The default configuration of the USB-6501 DIO ports is open-drain for 5 V operation with an Requirements and Compatibility | Ordering Information | Detailed Specifications | Pinouts/Front Panel Connections For user manuals and dimensional drawings, visit the product page resources tab on ni.com. 2/8 www.ni.com onboard 4.7 k? pull-up resistor. You can add an external, user-provided, pull-up resistor to increase the source current drive up to 8.5 mA per line. Each DIO signal is protected against overvoltage, undervoltage, and overcurrent conditions as well as ESD events. At system startup and reset, the hardware sets all DIO lines to high-impedance inputs. The data acquisition device does not drive the signal high or low. Each line has a weak pull-up resistor connected to it. You can configure P2.7 as the source for a 32-bit counter. In this mode, the device counts high to low transitions (falling edges) on P2.7. You can arm and disarm the counter and read or reset the counter through software. The USB-6501 supplies a nominal 5 V from two pins, one on each screw-terminal block. You can use the voltage source, which is provided by the USB host, to power external components. The USB-6501 features current-limiting short-circuit protection for safe USB host power use. TERMS AND CONDITIONS By placing your bid, you consent and agree with all of the following non-negotiable terms and conditions. We do our best to provide the most detailed description as possible. If any portion of our description is unclear to you, contact us with any questions. PAYMENT: We accept PayPal. When paying by PayPal, please be sure to include a "confirmed" street address to avoid possible delays and/or order cancellation. All payments are due within 3 days of auction close. Florida residents add sales tax. International buyers, please note: Import duties, taxes, and charges (typically collected upon delivery or pickup) are the buyer's responsibility and are not included in the item price or shipping charges. Please check with your country's customs office prior to bidding/buying to determine what these additional costs will be. SHIPPING: Once your payment has been received, we will usually ship the next business day. We only ship to PayPal "confirmed" street addresses. Tracking information can be provided. Handling fee includes insurance. No pick ups from our facility allowed at this time. RETURNS: All products are 100% guaranteed against manufacturing defects. Defective products must be returned within 14 days from the date of purchase. Unless otherwise stated in auction details, all returns are for money back or exchange. Please contact us for a Return Authorization Number prior to returning any items. All returns must be clearly marked with a return authorization number and include all original items, in re-saleable condition, all original packaging including manuals, warranty forms, etc. DVD's and Software sales are not refundable. Shipping and handling fees are not refundable. Buyer is responsible for shipping costs incurred when shipping products back. CONTACT US: You can use "Ask Seller A Question" for inquiries. Please contact us to resolve any issues. We strive to deliver 5-star customer service. EDX Electronics 1040 Willa Springs Dr. Winter Springs, FL 32708 407.215.1991 Thank you for viewing and good luck!! . : : .

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	National Instruments
MPN	USB-6501
Model	USB-6501
