Usb Fifo Evaluation Development Module Breakout Board Kit Ftdi Ft245r

US $14.99

Union City, Georgia, United States
Jan 29th

Open on mobile:
QR code

You are bidding on 1 pc HIVITRONIX FT 245R Development Kit OVERVIEW This kit offers a first-hand top performance evaluation of the popular FT245RL chip from FTDI. The FT245 chip offers developers ability to communicate in a FIFO format via USB port using sets of control inputs. All the data pins, the select pins and microcontroller (device) interface pins of the SOP 28 package are brought out in a convenient format for quick and easy development. This kit is unique and different from all other evaluation kits in the market in the sense that it does not restrict or bound the developer to a specific microcontroller interface. You will be able to implement all the various configurations as detailed in the FT 245R datasheet with this kit. FEATURES Compact small size and packed with several features for easy application USB 2.0 forward compatible port Synchronous and Asynchronous Bit Bang operation mode Select options (e.g microcontroller) via header pins in a SIL format - I/O (3.3V or VCC), Power (USB or SELF), LED Implements all configuration samples Optional 3.3V or 5V (ext. VCC) for I/O via VCCIO ROYALT FREE USB drivers for communication development from FTDI. D0~D7 digital data I/O pins LED monitoring Power ON Red LED (Default). All inputs and output pins are labeled for easy operation Great for students, engineers, electronics professional, R&D development,data acquisition, automation projects and general purpose microcontroller I/O computer communication applications. WHAT YOU GET 1 X FT245R Dev Kit board (Freestyle or Breadboard) User brochure (contains circuit schematic and configurations implementation instructions). All USB drivers are FREE and other examples, documentation are contained on datasheet POWER SUPPLY USB Powered 5V (max.)External Power (depends on voltage level of configuration used). DIMENSION 49mm x 23mm x H* . H - depends on variant selected. Freestyle (H = 14mm) or Breadboard style (H = 20mm) 2 x 2mm mounting holes at 11.5mm center to center. Provision for a plastic fastener. PAYMENT Paypal, or Credit (Visa, MasterCard, Discover) via Paypal eCheck accepted but will require confirmation. Item will not ship until payment is confirmed/completed. SHIPPING Default Freestyle is shipped. Buyer must indicate preference for the Breadboard Style, if desired Fast shipping within continental USA. Can ship same day with tracking Ships worldwide. Contact us for other details RETURN 100% guarantee Return acceptable on this item. Buyer responsible for all shipping charges. Please contact us to resolve any issue and/or before returning item. NOTE: Freestyle board variant has all header pins over the board (as shown in picture). Breadboard variant has all the CONTROL pins (microcontroller interface pins) and Data pins (D0~D7) configured for breadboard insertion. The configuration selectable header pins (on the left) remains on top of the board for both variants as shown in the picture. Please include a note during checkout or send a message instantly after payment to our ebay inbox. We will not be responsible for wrong shipment due to late notice. If you have any question, ask before buying/bidding. Be sure to add us to your favorites list! - makes future purchases easier. For similar items and other great bargains, check out our other items! We are stocking new items daily, so be sure to check back as often as possible for high quality products. Froo www.froo.com | Froo Cross Sell, Free Cross Sell, Cross promote, eBay Marketing, eBay listing Apps, eBay Apps, eBay Application

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Hivitronix
MPN	HMFT245A00FB
Model	FT245M
Country/Region of Manufacture	United States
