Usb Signal Generator 40m~3200mhz --made In Usa

US $2300

Fremont, California, United States
Nov 7th

Open on mobile:
QR code

This High Frequency /RF USB Signal Generator is Made in California, US. 100% satisfaction guaranteed. The package comes with the free software which allows you fully control the device and call API directly. LQ SG01 USB Signal Generator introduction Shipping: Free shipping in US, 1~4 business days. Warranty: 12 month warranty (free parts and labor). After 12 months, support limited warranty. Return: If you are not satisfied with our products, you can return it within 30 days and we 100% refund your money. We are building our reputation with quality and service. Product Specifications SG01 USB Signal Generator is a synthesized continuous wave signal generator and powered by USB. The specifications for the product, 1. Powered by USB 2.0 Full Speed interface 2. DC current consumption 230 mA 3. Output frequency range 40 ~ 3200 MHz 4. Output frequency step 1 KHz 5. Output power level - 23 ~ 10 dBm 6. Output power level step 0.5 dB 7. Output power level accuracy <+/- 1 dB 8. Reference frequency output 12MHz 9. Peak to peak voltage of the reference (50ohm load) 1.5V 10. Phase noise @10KHz offset (fout = 800MHz) - 91 dBc/Hz 11. Harmonics - 9.47 dBc 12. Output impedance 50ohm SG01 Software The software for SG01 USB Signal Generator is SG01 Software, which is in the USB flash drive attached with SG01 USB Signal Generator when you buy the product. The software includes three main elements: 1) One is the SG01 control panel (SG01.exe), which is user friendly Graphic User Interface (GUI).User can control the output of SG01 USB Signal Generator by just clicking the buttons or inputting the number of the desired frequency and inputting the number of desired output power level. 2) Second is Application Programmable Interface (API), which includes static library (SG01lib.h with SG01lib.lib) and dynamic -link library (SG01ALL.dll). Users can write their own programs to control SG01 USB Signal Generator automatically in any programming languages. Even in Windows Office software, such as Excel. 3) Third is command-line (SETSG01.exe). SETSG01.exe is a command at windows console. It can control SG01 USB Signal Generator by 4 parameters (serial number, frequency, output power, and output ON/OFF). The API examples and command-line examples have been installed with the software together. The examples are built by Visual Studio 2005 at 32bit Windows OS. The GUI can control maximum 4 units of SG01 USB Signal Generators at the same time. The API can program maximum 30 units of SG01 USB signal generators. http://www.lqelectronics.com/Support/USBSG/download.html For any inquiry, please email: sales@lqelectronics.com
