Usbtinyisp Avr Isp Programmer For Arduino Ide Bootloader + 6pin And 10pin Cable

US $7.49

Shenzhen, China
Jan 29th

Open on mobile:
QR code

New USBtinyISP AVR ISP Programmer For Arduino IDE Bootloader 6pin Cable Item Description Summary: Shield Functions Bootloader Compatible Mainboard AVR I/O Operation Level 5V or 3.3V Indicators USB/Power good Busy Board Size 47mm x48mm x15mm Colour Green Weight 21g USBtinyISP is designed for AVR ,based on USB connector's ISP download wire. Officially supported by Arduino IDE. - Both 6-pin and 10-pin AVR-standard interfaces - 2 LEDs to indicate "USB/Power good" and "Busy" - USB powered Steps to burn Arduino bootloader: 1.Download arduino 0018 http://arduino.googlecode.com/files/arduino-0018.zip 2. Download driver, unzip and install http://blog.flamingoeda.com/wp-content/uploads/2009/05/usbtinyisp-w32-driver-v112.zip 3. When you see USBtinyISP AVR Programmer in Device Manager, the USBtinyISP is ready to use 4. There's a jumper sticking out near the PWR ,. When the jumper is in place (connecting the two wires) then that means that the USBtinyISP is providing 5V power to the device being programmed. If you don't want to power the device then just take the jumper out. We will need the jumper in place when burning bootloader for Arduino. 5. Connect USBtinyISP and ICSP of Arduino with the 6-pin cable included. Then connect USBtinyISP to computer by USB cable (A to B type), this cable is not included, but we provide it when you buy our Arduino Duemilanove or Arduino Mega. 6. After the hardwares are connected, we can start the Arduino IDE. Under the list of Tools->Board , choose your Arduino version. Then click Tools -> Burn Bootloader -> w/ USBtinyISP to start burning Arduino bootloader. 7. During burning, you will see the BUSY led flashing 8. It will take awhile to burn (but still faster than USBasp ). You will see Done burning bootloader at Arduino IDE when it is done. Package Including: 1xUSBTINYISP 1x6 pins cable 1x 10 pins cable Payment Description We only accept PayPal. PayPal is the only online payment method we accept. Please make sure you have a valid/confirmed PayPal account prior bidding. Shipping Description Items will be shipped within 1 business day on payment received. we can provide a tracking number when you order more than $35.we will send you a DHL or other Express package when you order more than $200. Items are shipped using Airmail, which reach most of the countries within 10 to 25 business days. Delivery time depends on destination and other factors, it may takes up to 25 business days. Country Delivery Time Working days 5-10 11-15 16-20 21-25 26-30 >31 Calendar days 5-12 13-19 20-28 29-35 36-45 >41 United States Rate of arrival 9% 50% 35% 5% 1% Resend or refund Canada, Australia Rate of arrival 4% 45% 43% 6% 2% Resend or refund United Kingdom Rate of arrival 7% 46% 44% 2% 1% Resend or refund Europe (Exclude UK) Rate of arrival 2% 38% 45% 11% 4% Resend or refund Others Rate of arrival 3% 38% 48% 8% 3 Resend or refund Return Description If you are not satisfied when you receive your item, please return it within 14 days for a replacement or money back. Please contact me before you return it. if item is defective in 2 months, We will send you a replacement without extra charger, or offer refund after we receive the defective item. f item is defective after 2 months, you can still send it back to us. We will send you a new one after receiving the defective item. But you have to pay the extra shipping fee. About Us Please feel free to contact us whenever and whatever. We will be always here for you. please leave us 24 business hour to answer your emails. thank you for your business ,wish you a nice day. Engineered for professional eBay sellers!
