Used 17" X 100" Clausing Colchester Engine Lathe

US $14,500.00

Watertown, Connecticut, United States
Jan 30th

Open on mobile:
QR code

Item# 4003 - Used 17" x 100" CLAUSING COLCHESTER ENGINE LATHE Equipped With: Swing Over Bed: 17 1/4" Swing Over Saddle Wings: 17 1/4" Swing Over Cross Slide: 10 1/2" Bar Capacity Thru Spindle: 3" Distance Between Centers: 110" Headstock: Spindle Nose: 8" D1 Camlock Hole Thru Spindle: 3 1/16" Spindle Center: 5 MT Spindle Bearings: Gamet Precision Speeds: 16 from 20 to 1600 RPM U.S. Standard Threads: 38 from 2 to 72 Metric Threads: 40 from .4 to 14 Longitudinal Feeds: 45 from .002 to .032" Cross Feeds: .001 to .016 Lead Screw Diameter: 1 1/2" - 4 Acme Feed Rod Diameter: 1 1/8" Carriage: Length on Bed: 20" Width of Bridge: 9 1/4" Cross Slide: 24 1/2", 8" wide Cross Slide Travel: 12 1/4" Cross Feed Dial: Direct reading Compound Rest Travel: 6" Tool Block, Capacity: 2" Cross, Compound Slide Gibs: tapered Tailstock: Spindle Diameter: 2 15/16" Center: 5 MT Spindle Travel: 7" Spindle Graduations: 0-6" by 1/16" Bed Width: 13 1/2" Bed Depth at Center: 13 1/4" Bed Ways, Induction Hardened: 2 V, 2 flat Main Motor: 10 HP, 1800 RPM, 460V/3ph/60c Pump Motor: 460V, 3 ph Machine Specifications: Chip Pan Bed 4-Way Tool Post Threading Dial 3-Jaw Chuck Dimensions: 158" L x 42" W x 52" H+ Weight: 6,800 lbs.+ Shipping Point: AL Price: $ 14,500.00 SPECIFICATIONS SUBJECT TO VERIFICATION** Rigging and Hauling NOT Included Call On Target with all your equipment questions-203-441-4655 kevinb@ontargetmachines.com
