Used Isc Model 55 Vsi Portable Crusher, Conveyor, Sand, Gravel, Go

US $20000

Gallipolis Ferry, West Virginia, United States
May 30th

Open on mobile:
QR code

For Auction - 1 - ISC Vertical Shaft Impactor (VSI) Model 55. I bought this crusher with the intent of producing a cubical non-polishing aggregate for a customer. While the crusher was at the shop being rebuilt, the customer was purchased by another producer with their own source. We have never turned the crusher on since we have owned it, or even wired it up. We purchased it from Process Machinery and they did the rebuild work as well. Following are a list of new parts installed; List of new parts and new components to be installed: Qty Description 1 M-55 24 Count Anvil Ring 2 5310A Anvils 6 5014D Shoes 2 New Pedestal Oil Seals 1 New Oil flow system 1 New Oil Filter 1 New Lube oil 1 150 HP 1200 rpm WEG Motor 1 Motor sheave for correct speed Please note that all 6 shoes were replaced but only 2 anvils. I am no judge but I would estimate that the remaining 22 are at about 50%+ condition. Below is the description as presented to me by Process Machinery. The machine has been setting for about 3 years but is in better condition than when I received it. We painted the unit, installed new belting on the underconveyor and generally cleaned and straightened the unit. If you have any questions, please call me at 740-441-5308. Thanks for looking Crusher description: One (1) Used ISC Model 55 VSI Crusher as follows: - Unitized frame construction with square base plate and dual opposing drive tunnel bolt plates - Heavy duty bearing pedestal assembly and flywheel with cast liners and cast skirt cone - Cast tunnel liners and tub liners - Lid with three (3) hinged rubber sealed inspection doors with wedge lock latch bar and safety lock pin and cast lid liners - Twelve (12) quick release lid wedges with chain tie downs - Power operated hydraulic lid lifter for easy lid removal (360 degree rotation) - Externally adjustable feed tube assembly with 12" ID cast feed tubes and rubber dust seal - Rotatable feed box with two (2) cast liner - Adjustable feed splash plate with two (2) cast liners - 27" 6 Shoe Heavy duty double bolt impeller table with cast liners and cast impeller shoes - Adjustable anvil cluster ring with twenty-four (24) heavy duty dovetail cast anvils - One (1) bolt-on drive tunnel with adjustable V-belt take-up and removable V-belt safety guard - One (1) drive end motor mount and cover - One (1) drive tunnel cover plate for opposite drive end - V-belts with one (1) sheave and bushing for required speed - Oil Lube System: - Bolt-on lube tunnel and thirty-one (31) gallon tank - 2 HP, 1720 RPM, lube pump motor and oil pump, oil pressure switch, temperature gauge, high oil temperature switch, spin-on oil filter, in-line oil flow sight gauge, oil level sight gauge, and side mount oil filler/breather cap assembly - 2 HP, 1720 RPM, frame lid lifter pump and motor and oil pump, manifold block, check valve, flow control valve, pressure relief valve, pressure gauge, directional control valve, cylinder flow control valve - Single Electric Drive to include a new 150HP motor on the adjustable V-belt take up and removable V-belt safety screen belt guard, drive motor mount and cover, and motor sheave and bushing for required speed
