Usp Mitek Thfi 25118 ~ Face Mount I-joist Hangers ~ 18 Gauge

US $13.51

West Newbury, Massachusetts, United States
Aug 29th

Open on mobile:
QR code

USP MiTek THFI 25118 ~ Face Mount I-Joist Hangers ~ 18 Gauge These are left over from a project that I did. They have never been used, but a couple of them might have cosmetic blemishes. ------------------------------------------------------------------------------------------------------------ FACE MOUNT I-JOIST HANGERS THFI The THFI is a face mount hanger designed to attach EWP I-joist members to wood headers. The unique design of the THFI combines the installation ease of a top mount hanger with the installation flexibility of a face mount hanger. Because the side flanges extend to the top chord of the I-joist, web stiffeners are not required. The THFI hangers also feature strategically placed Seat Cleats® which lock the bottom flange of the I-joist to the hanger eliminating the need for joist nails to be installed. The innovative top flange alignment tabs with the holding cleats assist the placing and alignment of the hanger prior to nailing by hanging onto the header with holding cleats biting into the wood. If the alignment tabs are not desired or a deeper height member is to be carried, the tabs can be easily bent out of the way. Alignment tabs do not contribute to the allowable design values of the THFI hangers. Patents: U.S. Patent No. 5,564,248 & U.S. Patent No. 9,206,594 B1 Materials: 18 gauge Finish: G90 galvanizing INSTALLATION Use all specified fasteners. Alignment tabs are not structural and can be bent back or removed to assist hanger placement. Web stiffeners are not required for THFI hangers unless specified by the I-joist manufacturer. Web stiffeners are not required for lateral stability. For additional uplift capacity, install (2) 10d x 1-1/2 nails through diamond holes and into the joist member. (web stiffeners required) THFI2514 model has diamond holes in the header flange for MIN/MAX nailing option. For the MAX nailing option, install nails in both the round and diamond shaped header holes.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Shape	Round
Item Thickness	18
Model	yes
MPN	IUS1.81/11.88
Grip Range	0.126 in - 0.25 in
Finish	Treated
Head Style	Flat
Item Length	11.5
Thread Size	#8
Gauge	18
Drive Style	One-Way
Form	Joist
Material	Steel
Color	metal
Screw Size	#10
Brand	Simpson Strong Tie
Holes per Leaf	1
UPC	Does not apply
Rail Height	1 1/4 in
Features	Offcuts
Mandrel Material	Steel
Item Diameter (Interior)	1 in
Grade	Grade 2
Item Diameter	4 in
Type	Sleeve Anchor
End Type	Hook
System of Measurement	Inch
