USR-K3 Super Port Serial TTL UART to Ethernet Module with Cortex M4 Kernel, US $18.04 – Picture 0

USR-K3 Super Port Serial TTL UART to Ethernet Module with Cortex M4 Kernel, US $18.04 – Picture 1

USR-K3 Super Port Serial TTL UART to Ethernet Module with Cortex M4 Kernel, US $18.04 – Picture 2

Usr-k3 Super Port Serial Ttl Uart To Ethernet Module With Cortex M4 Kernel

US $18.04

Shenzhen guangdong, China
Jun 9th

Open on mobile:
QR code

USR-K3 Super Port Serial TTL UART to Ethernet Module with Cortex M4 Kernel USR-K3 is the high-performance and industrial version of Super Port.It is an embedded serial networking module,whose function is to realize bidirectional transparent transmission between TTL and Ethernet.The amazing part of K3 lies in its Ethernet port integration design.You can apply K3 to your products to realize networking communication.User can directly process data interaction through network and device to realize remote data acquisition, remote control and management. K3 adopts Cortex-M4 solution,which has high speed,high stability and basic frequency up to 120MHz.And it has the same kernel solution and parameters as USR-TCP232-E2. Parameter Parameter Value Input Voltage DC 3.3V Input Current 120mA(115~125)@ 3.3V Power <1W Size 33.02 x 19.01 x 19.15 (mm) (including clips) Operating Temp. -40 ~ 85°C (industry) Storage Temp. -40 ~ 85°C, 5 ~ 95% RH(no condensation) Interface TTL UART Network Protocol IP, TCP, UDP, DHCP, DNS, HTTP, ARP, ICMP, Web socket, Httpd client Packing list USR-K3 *1 USR-K1 USR-K2 USR-K3 Function Comparison Product image Built-in Webpage with Custom Extensions The interface is more friendly. The right side adds humanizing help hint. And built-in webpage also supports customized definition. The built-in webpage is not only good-looking, but also practical. K3 supports function of Ethernetto serial, which adopts HTML5 Websocket technology. Combined with customized webapge function, User can design built-in webpage to realize webpage control and data acquisition according to project requirement. Data Submitted to Web Server Directly Httpd client function of K3 supports direct data interaction with web server.If send serial data to module according to some format, data will be submitted to web server like apache,IIS and tomcat in the way of Http. General web programmer can process database storage by using PHP and ASP. Can used as Modbus Gateway The setting is very simple : select modbus TCP in modbus TCP option to realize bidirectional automatic conversion between modbus RTU and modbus TCP in the setup software. Support USR-VCOM and D2D Cloud Server

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	USR
MPN	Does Not Apply
Model	USR-K3
UPC	Does not apply
