Ut7020-3 / Ds616-6 Slotted Locator Bushing 3/8"

US $19.26

Redford, Michigan, United States
Jan 30th

Open on mobile:
QR code

Boeing UT7020-3 / Lockheed DS616-6 Slotted Locator Bushing for 3/8" Pin FEATURES: Use with L Pins, T Pins, Shoulder Pins, or Ball Lock Clamps to align two holes without binding. Precision bushing with a tight tolerance in one direction and full relief in the perpendicular direction. SIZES: Available for 3/16 to 1" diameter pins (6 to 25mm in metric) — see Dimensions page for part numbers. INSTALLATION: To install, first drill and ream hole for roll pin (furnished), then bore large bushing hole for .0003-.0005" press fit. Press in bushing and roll pin simultaneously for accurate orientation. MATERIAL: Bushing > Tool steel, heat treated Rc 58-62, black oxide finish. Roll pin > Spring steel. **Use The Chart Below along with Photo #2 for specifications on this part.** Highlighted in Bold Red for this item PART NO. PIN DIA A B DIA C DIA L M DIA N DS616-3 3/16 .1876/.1882 .312 .7500 .40 3/16 3/8 UT7020-1A / DS616-4 1/4 .2501/.2507 .375 .7500 .40 UT7020-1 1.0000 UT7020-2 / DS616-5 5/16 .3126/.3132 .437 1.0000 .40 UT7020-3 / DS616-6 3/8 .3751/.3757 .500 UT7020-4 / DS616-8 1/2 .5001/.5007 .625 1.0000 .40 UT7020-5 .90 We are currently listing a limited number of UT and DS parts in our Ebay Store. Please E-mail us at Toolcomp1@aol.com for any other Boeing UT or Lockheed DS parts you need. This Item and many others may also be available for Buy it Now Purchases in our Ebay Store At http://stores.ebay.com/toolcomp1 Click Here > to visit our Store. ***Please Note: Our stock amounts change daily. If by chance we are out of stock of this item at the time of your order. Your order will be shipped as soon as our next shipment arrives, Which is usually within 3 to 4 business days, depending on factory stock availability at the time of our order. We will notify you if there will be any delay in shipping your order beyond 4 business days. Your order may also be direct shipped from the factory depending on the quantity and Amount of your order.*** Thank You For Visiting Our Store
