Uv-c 254nm Germicidal 125mm L-shape Lamp Bulb 12v Dc Kit

US $16.99

United States
Jan 29th

Open on mobile:
QR code

Kit includes: 1pcs UV Germicidal Lamp L-shape 125mm length by 8.5mm diameter 1pcs 12V DC Single Lamp Inverter 1pcs High Voltage Wire 150mm length 1pcs Low Voltage Wire 250mm length For complete lamp specifications go here: http://www.rexim.com/pdf_files/MCCUV-C, L-125x37.pdf UV-C Cold Cathode 254nm Germicidal Lamps Quartz Germicidal Lamps are low pressure lamps that generate most of the energy at 254nm (253,7nm - Mercury line) and some energy at 185nm. In medical terminology they are known as UV-C lamps. The mechanical structure of a germicidal lamps is the same as for a Miniature Cold Cathode Florescent Lamp but instead glass the envelope is manufactured with quartz. At these wavelength the most bacteria, spores and viruses are complete destroyed. 12V DC Sinvle Lamp Inverter The inverter is designed to supply the Cold Cathode Lamp with correct voltage. First, it will supply a starting voltage up to 900-950 vrms. Then the voltage will drop supplying the lamp a constant current of 4-9 mA at 40-50 KHz. CAUTION! Germicidal Cold Cathode lamps are manufactured with quartz glass. The lamp is filled with gas and a very small amount of Mercury – less than 5mg per lamp. These lamps generate UV radiation at 254nm. There is also a small amount of Ozone generated by the residual radiation of 195nm and corona effect. The voltage supplied to activate the lamp is over 300V and is direct proportional with the lamp length. Longer lamps needs over 1000V. SAFETY CONCERNS: • Although the amount of UV and Ozone generation is very small (UV is Max. 5.0mW/cm2), we recommend all suitable precaution to avoid eyes or skin exposure to UV radiation. It can produce serious damage to the eye, which may lead to temporary or permanent vision impairment. For this reason, the light produced by a germicidal lamp must be carefully shielded against both direct viewing and reflections and dispersed light that might be viewed. • Do not touch the glass/quartz with the bare hands. • Use appropriate protection, wires and insulated materials to avoid surge voltage from the lamp leads. • Discard the lamps in accordance with safety cod requirements for materials containing Mercury. • Take also all suitable requirements recommended by the government safety code to avoid a prolong inhalation of Ozone generated by the lamp. About us Rexim, LLC is an importer and distributor of value brand of Dichroic Reflector Halogen or Gas Filled Lamps, Medical, Dental and Projector Bulbs, Specialty and General Lighting, LCD backlight, Cold Cathode, Germicidal and UV Lamps, LED Lamps, Miniature Neon Lamps and more! Please check our ebay store for our complete products. Payment We accept payment through paypal, checks (payment must clear before shipping). Payment is expected within 7 days after auction closes. MA resident will be charged 6.25% tax on the item purchased. Shipping We ship everything from our Boston, MA location. All orders are shipped within 1 business day by first class mail or priority mail in continental US, and Airmail (7-14 days delivery) outside US. Return Policy We will replace and defective products. Any returns are subject to our approval. In addition, if the return is approved by us, you must obtain a Return Authorization Number from us before shipping back any product. Please contact us with your concerns.
