Uv Curing Conveyor

US $9,335.00

Farmington, Connecticut, United States
Jan 30th

Open on mobile:
QR code

Systematic Automation's UVC-UL400, 63.5" (1600 mm) long, is used for curing inks, adhesives, and coatings. This compact and modular unit utilizes ultraviolet light energy to cure or solidify specially formulated materials virtually instantaneously. It features a curing system with a UV lamp delivering up to 400 watts per inch of curing power. A special black pigmented Teflon coating on the conveyor belt assures long belt life. Touch-screen user interface, PLC controls, Tri-Power (200/300/400 watts per inch) UV power levels are standard features on all 12" (304 mm) lamp systems and larger. These features are available on the 6" (152 mm) lamp system as an option. Since the UV light energy emitted by the UV lamp remains constant, the desired level of cure is achieved through adjustments to the conveyor belt speed setting or through adjustments to the lamp focal length. The variable speed DC motor may be set to deliver belt rates of 0 to 100 feet per minute. The height of the entire conveyor unit can be adjusted to facilitate integration into the setup of your current production line. As the product is deposited on the intake end of the moving conveyor belt, it passes under the UV lamp. Here, the product is held flat to the belt by a vacuum drawn by the blower assembly mounted directly below the belt. Engineering Features Space saving design. Smooth quiet operation. Digital variable speed DC motor control. Belt travel direction is reversible. Special Teflon coated belt for longer life than conventional non-pigmented belts. Cooling air is drawn through unit by a blower to keep heat sensitive parts from warping or distorting. Variable vacuum hold down. Unique conveyor pulley design provides perfect belt tracking. Modular irradiator has adjustable focal point height. Adjustable legs for conveyor height position from 35.5" (902 mm) to 42.5" (1079 mm). Modular power supply. Touch screen controls for 12" (304 mm) and longer lamps. Machine tool quality and durability. 100% American made. Specifications Length 63.5" (1600 mm). Height 69" (1750 mm). Width of conveyor belt 14" (355 mm). Maximum substrate height for standard unit: 2.5" (63.5 mm). Tri-power (200/300/400 watts per inch) for 12" (304 mm) and longer lamps. Weight: 400 lbs. (180 Kg) Belt speed: 0-100 feet per minute. Electrical requirement: 110, 208, 220 or 240 volts, 1 phase, 50/60 HZ. The listed eBay price is for a complete conveyorized unit with a 6" (152 mm) lamp. We also manufacture conveyors with 12" (304 mm), 18" (457 mm), 25" (635 mm) lamps. For more information, call the factory direct at 860-677-6400.
