Uv Sensor Module For Arduino Electronic Brick Ultraviolet Ray Detection

US $7.28

shenzhen, China
Jun 9th

Open on mobile:
QR code

Features Description: The UV Sensor is used for detecting the intensity of incident ultraviolet(UV) radiation. This form of electromagnetic radiation has shorter wavelengths than visible radiation. The UV Sensor is based on the sensor GUVA-S12D which has a wide spectral range of 200nm-400nm. The module outputs electrical signal which varies with the UV intensity, which gives your suggestion if it is a good idea to beach today. PCB size: 33.0mm X 14.00mm X 1.6mm Power supply: 3.3 or 5V DC Compatible interfaces: 2.54 3-pin interface and 4-pin Grove interface Parameter Min. Typical Max. Unit Operating voltage 3.0 5 5.5 VDC Current - 0.3 - mA Output voltage 0 - VCC VDC Response wavelength 200 - 370 nm Demo: void setup() { Serial.begin(9600); } void loop() { int sensorValue; long sum=0; for(int i=0;i<1024;i++) { sensorValue=analogRead(A0); sum=sensorValue+sum; delay(2); } sum = sum >> 10; Serial.print("The voltage value:"); Serial.print(sum*4980.0/1023.0); Serial.println("mV"); delay(20); Serial.print("\n"); } Package Included: 1PCS* UV Sensor Module for Arduino Electronic Brick Ultraviolet Ray Detection Similar Products DC 12V Useful IR Pyroelectric Infrared PIR Motion Sensor Detector Module 5A $2.95 Time left:16d 6h 53m 5Pcs Ultrasonic Module HC-SR04 Distance Measuring Transducer Sensor for Arduino $6.14 Time left:22d 1h 50m 10 x Ultrasonic Module HC-SR04 Distance Measuring Transducer Sensor for Arduino $12.58 Time left:22d 1h 54m 12V PIR IR Pyroelectric Infrared Module Adjustable Relay Output Sensor CZ $3.39 Time left:6d 7h 9m 10PCS DHT11 DHT-11 Digital Temperature and Humidity Sensor $8.54 Time left:10d 3h 42m TTP229 16 Channel Digital Capacitive Switch Touch Sensor Module for arduino $2.10 Time left:15d 6h 23m New Pro Micro ATmega32U4 5V 16MHz Replace ATmega328 Arduino Pro Mini $4.08 Time left:5d 12h 5m NEW HTU21D Temperature & Humidity Sensor Breakout Board Module $4.07 Time left:6d 6h 32m 2PCS Soil Hygrometer Detection Module Soil Moisture Sensor For arduino $2.17 Time left:24d 5h 51m New BMP085 Barometric Digital Pressure Sensor Module Board For Arduino $8.66 Time left:11d 14h 54m Automatic DC 12V-24V 8A Infrared PIR Motion Sensor Switch For LED light Hottest $4.25 Time left:16d 7h 1m LJ12A3-4-Z/BX Inductive Proximity Sensor Switch DC 6V-36V NPN $2.08 Time left:26d 14h 23m 2PCS Rain Weather Module Raindrops Detection Sensor Moduel Humidity For Arduino $2.37 Time left:25d 5h 25m 5PCS DHT22/AM2302 Digital Temperature and Humidity Sensor Replace SHT11 SHT15 $16.87 Time left:24d 10h 47m DC 5V Ultrasonic Module Distance Measuring Transducer Sensor Waterproof $8.22 Time left:23d 23h 2m MCP2515 Controller Bus Module TJA1050 Receiver SPI Protocol for Arduino $3.33 Time left:18d 6h 41m 2PCS Waterproof Digital Thermal Probe or Sensor DS18B20 DS18S20 Arduino Module $3.26 Time left:15d 4h 29m 10Pcs IR Infrared Obstacle Avoidance Sensor Module for Arduino Smart Car Robot $9.75 Time left:27d 3h 53m 5PCS DHT11 DHT-11 Digital Temperature and Humidity Sensor $3.95 Time left:18d 3h 42m New Liquid PH Value Detection detect arduino Sensor Module Monitoring Control $19.95 Time left:1d 4h 8m PIR IR Infrared Pyroelectric IR PIR Motion Sensor Detector Module DC 12V $2.56 Time left:16d 7h 17m Automatic Infrared PIR Motion Sensor Switch DC 12V-24V 8A Detector Practical $6.22 Time left:29d 3h 55m MLX90614 Contactless Temperature Sensor Module For Arduino $7.05 Time left:15d 6h 58m 2Pcs IR Infrared Obstacle Avoidance Sensor Module for Arduino Smart Car Robot $2.36 Time left:27d 3h 53m 2PCS DS18B20 temperature measurement sensor module For arduino $2.83 Time left:15d 6h 40m Mini W5100 LAN Ethernet Shield Network Module board for Arduino high quality $6.05 Time left:23d 6h 45m AM2301 DHT21 Digital Temperature Humidity Sensor module for arduino SHT11 SH15 N $3.19 Time left:15d 15h 42m DIY Infrared Proximity Switch Kit Control Switch Automatic faucet control module $2.33 Time left:22d 23h 47m DHT22/AM2302 Digital Temperature and Humidity Sensor Replace SHT11 SHT15 $3.29 Time left:19d 15h 0m DSM501A Dust Sensor Allergic Smoke Particles Sensor Module for Arduino $8.87 Time left:19d 6h 48m 5Pcs IR Receiver Module 38 kHz TSOP4838 DIP-3 $2.32 Time left:14h 59m LM393 3V-5V Touch Button Detection Switch Sensor Module for Arduino Smart Car $2.67 Time left:23d 7h 7m SPI/IIC MPU-9250 9-Axis Attitude +Gyro+Accelerator+Magnetometer Sensor Module $5.20 Time left:9d 3h 30m Si7021 Humidity Sensor with I2C Interface Arduino Industrial High Precision $3.36 Time left:22d 6h 45m MAX471 3A Range Current Sensor Module Professional Module For arduino $2.23 Time left:24d 6h 36m MS5611 high-resolution atmospheric pressure module height sensor DIY 3V-5V $8.40 Time left:9d 0h 4m 2Pcs Adjust Pyroelectric Infrared IR PIR Motion Sensor Detector Module New $2.24 Time left:29d 11h 1m 2PCS Tank Pool Water Level Liquid Sensor Float Switch Connectors Switches $3.05 Time left:13d 7h 9m 2PCS HY-SRF05 5Pin Ultrasonic Distance Sensor Module Arduino Module Replace SR04 $2.73 Time left:24d 13h 23m 2PCS LJ12A3-4-Z/BX Inductive Proximity Sensor Switch DC 6V-36V NPN $4.56 Time left:28d 14h 21m IR Infrared Reflectance Sensor for Arduino Sensor Shield $5.66 Time left:20d 1h 27m 5PCS NTC Thermistor accuracy temperature sensor 10K 1% 3950 Waterproof Probe 1m $3.74 Time left:11d 7h 42m Water flow sensor flowmeter Hall flow sensor Module Water control 1-30L/min top $3.24 Time left:27d 2h 53m Pulse sensor Heart Rate Sensor PulseSensor for Arduino Raspberry pi $4.86 Time left:7d 6h 46m AM2320 Digital Temperature and Humidity Sensor Replace SHT10 AM2302 for Arduino $2.64 Time left:25d 21h 50m TCS230 TCS3200 Detector Module Color Recognition Sensor for MCU Arduino TOP $3.59 Time left:10d 21h 49m 50 x Ultrasonic Module HC-SR04 Distance Measuring Transducer Sensor for Arduino $62.90 Time left:21d 7h 42m Waterproof Non-contact Distance Ranging Ultrasonic Sensor Module Motion Detector $10.64 Time left:9d 3h 26m Shipping & Handling Shipping Time: The items you ordered will be shipped out in 1-2 business day by Hong Kong Post Air Mail when your payment is clear. Payment We accept PayPal only. We only ship item to your PayPal verified address. Payment must be received within 5 Days from the date of purchase. Return Policy All the products we are selling include factory warranty, don’t cover items that have been abused, burned and damaged in any form. Please contact us via eBay Message if you have NOT received item in 30 days, we will check it with post office, and then resend or refund any missing item. In the unlikely event that your product is faulty in anyway, you must contact us ASAP and then return it within 7 Days of receipt. The postage and packaging fee will NOT be refunded. We will not be responsible for the delivery or insurance charges incurred in returning item back to us. If you return an item purchased from us, it must be back in Factory Condition. This includes packaging, inserts, manuals etc. Please allow up to 5 Working Days for us to process your returned item. Feedback & Contact Us We maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important to us. We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns. We greatly appreciate your POSITIVE feedback. Please do NOT leave negative feedback without asking for help.We will try our best to solve any problem. If you have any questions, please feel free to contact us by ebay message. We will reply you within 48 Hours. On Sep-21-15 at 11:29:49 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded/Generic
Model	arduino UV sensor
Country/Region of Manufacture	China
MPN	arduino UV sensor
UPC	Does not apply
