Vacuum Table Vt3020 Cnc Clamps Engraving Or Milling

US $101.00

Exeter, Rhode Island, United States
Jan 30th

Open on mobile:
QR code

Vacuum Tables, Vacuum Table, Vacuum Clamps, Vacuum Pods and T-tracks from Clampusystems.com var blankSrc = "wpscripts/blank.gif"; --> Vacuum Table VT3020 for CNC, Milling & Engraving (12.0” x 8.0” vacuum area) Hole Grid Type - Vacuum Table This table works in wet and dry machining environments. Check out our Videos on our ClampuSystems site This vacuum table represents a combination of highly efficient processing with top-class materials. The cover plate consists of solid aluminum, the base plate is made from hard plastics. This makes for an extremely rigid sandwich construction that has many advantages. This is ideal solution to clamp almost all materials that are processed by manual means on CNC machines or automatically. Typical areas of use are electronics, electrical engineering, sinking, model making – simply every form of machining. No matter whether on CNC milling machines, surface grinding machines, laser cutting machines or simply when used in measurement engineering. In contrast with a magnet clamping plate, non-magnetic materials such as aluminum, brass, copper or plastic sheets can also be clamped here. Operation can be completed via practically every vacuum pump. Attempts with a normal vacuum cleaner promise great success; a connecting adapter is included in the delivery contents. Material smaller than 1/3 the size of the table may require additional vacuum generation other than a shop vac. Not recommended for holding of wood products thicker than veneer. Items that come with the vacuum table Phone: 401-385-3181 Fax: 401-753-6331 The VT3020 Vacuum Table PERFORATED RUBBER MAT SOLID RUBBER MAT SHOP VAC ADAPTOR VACUUM HOSE This vacuum table represents a combination of highly efficient processing with top-grade materials. The cover plate consists of solid aluminum, the base plate is made from hard plastics. This makes for an extremely rigid sandwich construction that has many advantages. The retention force is proportional to the covered area, the friction coefficient and the differential pressure. A perforated rubber mat is included in the delivery contents with the aim of raising the friction coefficient also provided is a solid rubber mat to cover unused holes. At the same time, this is used to protect the vacuum plate, if work pieces are milled through. Rubber mats are wear parts and are inexpensive to purchase. This vacuum plate allows for wet processing with non-detergent cool lubricants customary in the trade. However, one should ensure that in a case where a significant amount of fluid is used, a liquid separator which can be delivered as an option, is used between table and vacuum pump · Measurements: 12.375” x 8.0” x .811” · Effective vacuum area: 12.0” x 8.0” The contents of delivery include: · 1 vacuum table · 1 connecting adapter for Shop Vac (Table will also work with proper vacuum pump) · 1 perforated rubber mat · 1 solid rubber mat to cover unused holes · Connecting vacuum hose Caution: Shop vacs used as a vacuum generators are just for testing and intended for temporary use at short intervals as this type process can overheat a shop vac. Also more than 30% of the table surface must be covered with plastic or metal material and remainder covered with provided rubber mat is needed for most shop vacs to work. A shop vac is not a replacement for a properly sized pump or blower. We carry a wide variety of vacuum tables and are constantly engaged in further development and new technological solutions. Not all of our vacuum systems are suitable for marketing on Ebay; therefore, if you don’t see it on Ebay, we may have it in stock or can create custom orders. Just ask us!!
