Vacuum Table Vt4220ral Cnc Chuck Engraving Or Milling

US $304.00

Exeter, Rhode Island, United States
Jan 30th

Open on mobile:
QR code

Vacuum Tables, Vacuum Table, Vacuum Clamps, Vacuum Pods and T-tracks from Clampusystems.com Vacuum Table VT4220RAL for CNC, Milling & Engraving (16.15” x 7.85” vacuum area) Grid Type - Vacuum Table When it depends on hold strength, precision and stiffness Check out our Videos at: www.ClampuSystems.com/Videos.html Our RAL Series type vacuum table is made of high grade, cast, precision aluminum, machined on both sides. These characteristics ensure both the maximum possible firmness and distortion-freeness when heated (not a bimetal effect). This vacuum clamping technology guarantees a clamping force, which is around 4 - 5 times higher than using an ordinary vacuum cleaner or a side channel compressor. There is no need for a very powerful vacuum pump because the whole system is sealed up during the production process - even while countersinking your component! Solid aluminum can be used in combination with coolant without almost any restrictions and therefore this vacuum table is practically indestructible. Items that come with the vacuum table Here is an example of the results achieved by vacuum milling techniques when used properly. This test uses this same VT4220RAL vacuum table to lift a mesh box filled with wood and an approximate weight of 500 kg., which is over half a ton! Click here to see the video >>VIDEO<< Included in delivery - VT4220RAL Grid Type, Solid Aluminum Vacuum Table - Customizable, Clear, Flexible, PVC Mat - Vacuum Manifold with Ball Valve - Generous Length of Gasket Material - Vacuum Hose Material: All Solid Aluminum Overall dimensions: 16.55 x 7.85 inch Vacuum Area: 16.15 x 7.45 inch Height: 0.71 inch We carry a wide variety of vacuum tables and are constantly engaged in further development and new technological solutions. Not all of our vacuum systems are suitable for marketing on Ebay; therefore, if you don’t see it on Ebay, we may have it in stock or can create custom orders. Just ask us!! Phone: 401-385-3181 Fax: 401-753-6331 The VT4220RAL Vacuum Table VACUUM HOSE MANIFOLD VALVE GASKET MATERIAL CUSTOMIZABLE CLEAR MAT By the use of a connecting adapter with the ball valve, several of these vacuum tables can be driven by a single vacuum pump at the same time. This guarantees a high flexibility with repeat production. You can for example, work with two vacuum tables: On the first table your product is being milled while on the other table you prepare the next item for the production process. Using this process of a submerged single length foam rubber cord, the work piece is located directly on the aluminum surface of the vacuum table. This will achieved the maximum possible accuracy in the Z-axis direction. A thin material can also be placed inside the gasket area allowing you to cut the entire vertical edge of your part without cutting into the vacuum table surface. Furthermore, we produce various types of vacuum tables and sizes in addition to vacuum pods. We also sell two complete lines of vacuum pumps and blowers as well as venturi.
