Vacuum Table Vtz1212 Smart Cnc Engraving Or Milling

US $490.00

Exeter, Rhode Island, United States
Jan 30th

Open on mobile:
QR code

VTZ1212SMART Vacuum Clamping Table VZT1212SMART Smart clamping - a new vacuum clamping process with impressive results “Smart Clamping” is a specialized vacuum system using a maximum concentration of vacuum suction at each and every orifice below the table surface to create a holding capacity unmatched by any vacuum system found in the market place today. This new technology found nowhere else in the world was developed in Germany and now available for purchase in the U.S.A. You can now securely clamp work pieces having an even surface with a vacuum output of 500Watts per m? without having to cover any of the remaining open suction holes. So throw away those toggle clamps and see what full production really means. Check out our Videos at: ClampuSystems.com/Videos.html This is achieved as a result of the enhanced efficiency of the system, which displays more clearly with an increasing number of open drilled holes. If a conventional breadboard vacuum table displays more and more open drilled holes in the course of continuous processing, less and less of the energy that has been produced will be used to clamp the work piece, while the lion’ s share is blown through the room as leakage gas. Smart clamping drastically reduces this effect. This results in a flexibility which was never there when processing several work pieces in a clamping as well as making operation more comfortable. At the same time, an enhanced cut quality can produce a much greater clamping volume. This saves CNC capacities and thus ensures even greater profitability. As an example of the efficiency of this process using one of our other table models, the following video shows an aluminum disk with a surface area of 7.09” (180mm) x 4.72” (120mm) and a thickness of 0.787” (20mm) equipped with several pockets. Here are the milling parameters: - Professionally Packaged and Delivered to Your Door - Technical Data: Material: high grade precision aluminum machined on both sides Chamber: 2 sealed vacuum chambers distributor with 2 ball valves, strain relief fitting and vacuum gauge Weight: about 11 lbs. 4 oz. including hose, connector, manifold and mats Measurements: 12" x 12" x 3/4" Effective surface: 12” x 12” Only 0.75” high! The contents of delivery include: · Smart clamping VZT1212SMART vacuum table with 5 threaded holes for surface mounting · Single manifold with 1/2" hose attachment from your vacuum generator · Vacuum gauge · 2 Ball Valves · 1 vacuum hose with all quick-connections · Holed rubber mat for the seal (although you do not have to cover, 2 cover rubber mats are also supplied, since the vacuum table can be very easily released of clamps if there is no chip suction.) We guarantee long-term availability of accessories and spare parts for every smart clamping system you purchase from us. We not only welcome your Ebay feedback but also email feedback as well. We will continually be coming out with new and different types of vacuum table systems. Feel free to email comments and suggestion for future vacuum table ideas you would like to see and we will do our best to accommodate the popular requests in future models. We stock a variety of different vacuum tables that are temperature-controlled upon request. Our daily business involves constantly working on new technological solutions to problems. Of course, we can deliver even larger vacuum tables with varying designs and complete solutions including the necessary electronics. By design, we like to proceed by unconventional means. Not all the paths we choose are suited to distribution at Ebay. Should this vacuum table not satisfy your requirements, then please do not hesitate to contact us directly. This applies in particular, if you, as the manufacturer of machines or equipment have regular requirements and are looking for low-cost customization. International buyer are responsible for all duties, taxes, import, export and or customs fees. This sale is our intellectual property. It is subject to copyright law, singly and in the aggregate. Whoever copies or disseminates individual passages, images or the complete text without our prior consent, shall receive correspondence from our attorney. You will receive a guarantee of one year from the date of purchase with this table. Excepted are mechanical defects that are the result of faulty processing or damage by the user. Mill diameter 0.6299” (16mm) Lining (immersion depth) 0.315” (8mm) Cutting feed (velocity) 4.92 ft. per minute (1.5m/minute) Rotational speed 11000 rpm Intentionally a vacuum pump was not used to produce the vacuum and work was done with a low-cost vacuum generator (VT-VE2)! Click Photo for Video This system is used in CNC machine shops, CNC router shops, general and specialized manufacturing, and by home hobbyists. The tensile strength of this system is five times as great as when clamping with conventional radial turbines or as often practiced, with industrial shop vacuum cleaners. At the same time, mounting to a CNC machine is clearly simplified, since the feed cables require fewer cross-sections than conventional clamping technology which has been practiced to date. Smart clamping avoids leakage instead of distributing it evenly on the surface by means of a particularly expensive ducting. Note: This vacuum table is designed to work with a Vacuum Pump or a Venturi but NOT a shop vacuum cleaner. See our "Standard" and "SEAL" vacuum tables for use with a shop vacuum cleaner. Although this vacuum system has the performance of a clamping vacuum table costing several hundreds of dollars, there is no reduction in quality or performance and can go head to head with any other vacuum system on the market today and clearly out perform it.
