Vacuum Table Vtz4824 Cnc Clamps Engraving Or Milling

US $1,189.00

Exeter, Rhode Island, United States
Jan 30th

Open on mobile:
QR code

Vacuum Clamping Table VTZ4824 Size is 48inches by 24inches Four Sections Will Cover Typical 4ftx8ft CNC Router Table Includes clamping mats High flexibility due to an aluminum surface with additional clamping threads. This table works in wet and dry machining environments. This vacuum table represents a combination of highly efficient processing with top-class materials. The cover plate consists of massive aluminium, the base plate from hard plastics. This makes for an extremely rigid sandwich construction that has many advantages. Work pieces can be clamped by using additional clamping threads that one could not otherwise be clamped with a vacuum table. To do this, you can remove the suction nozzle from the clamping hole and an M6 thread is then freely available. After work is completed, the suction nozzle can be screwed in again and the hole reset to its original position. Check out our Videos at: Clampusystems.com/Videos.html This is ideal solution to clamp almost all materials that are processed by manual means on CNC machines or automatically. Typical areas of use are electronics, electrical engineering, sinking, model making – simply every form of machining. No matter whether on CNC milling machines, surface grinding machines, laser cutting machines or simply when used in measurement engineering. In contrast with a magnet clamping plate, non-magnetic materials such as aluminum, brass, copper or plastic sheets can also be clamped here. Operation can be completed via practically every vacuum pump. Attempts with a normal vacuum cleaner promise great success; a connecting adapter is included in the delivery contents. The retention force is proportional to the covered area, the friction coefficient and the differential pressure. A holed rubber mat is included in the delivery contents with the aim of raising the friction coefficient. At the same time, this is used to protect the vacuum plate, if work pieces are milled through. Drilled rubber mats are wear parts and are inexpensive to purchase. This vacuum plate allows for wet processing with non-detergent cool lubricants customary in the trade. However, one should ensure that in a case where a significant amount of fluid is used, a liquid separator which can be delivered as an option, is used between table and vacuum pump This type vacuum plate should not be dressed after mounting as the heat can cause damage to the plastic base. Due to the size of this vacuum table it is not recommended to be used with a shop vac and should be used with a properly size vacuum generator. Not recommended for wood products other than veneer. Here are the key advantages at a glance: 1. Use of high-quality materials resulting in high long-term stability Wet processing is not a problem. Significantly lower default than for pure synthetic vacuum tables. 2. Multifunctional vacuum plate, dowel pins can be set which allows for smooth reproducibility in the case of mass production. 3. Additional M6 clamping threads offer a maximum of flexibility. Very low height of only 21mm, therefore no unnecessary operating range losses for the Z-axle. 4. Sintered rubber mats or sintered rubber mats that are permeable to air (with homogenous microporous surface) to be received as accessories 5. Exchangeable vacuum plate, in case a fault occurs, it can be simply repaired. 6. Optimal vacuum distribution through intricate ducts inside the vacuum chambers. 7. High air turnover through generous fitting of the connections. · Measurements: 48.375” x 24.0” x 13/16” (1228.7 x 609.6 x 21 mm) · Effective vacuum area: 48.0” x 24.0” (1219.2 x 609.6 mm) · Threaded mounting points · 80 lbs (table weight only) The contents of delivery include: · 1 vacuum table · 1 connecting adapter for large hose size (Table works with vacuum pump, or Venturi) · 1 sintered rubber mat · 1 cover rubber mat to cover gaping holes · Connecting tube We not only welcome your Ebay feedback but also email feedback as well. We will continually be coming out with new and different types of vacuum table systems. Feel free to email comments and suggestion for future vacuum table ideas you would like to see and we will do our best to accommodate the popular requests in future models. We stock a variety of different vacuum tables that are temperature-controlled upon request. Our daily business involves constantly working on new technological solutions to problems. Of course, we can deliver even larger vacuum tables with varying designs and complete solutions including the necessary electronics. By design, we like to proceed by unconventional means. Not all the paths we choose are suited to distribution at Ebay. This sale is our intellectual property. It is subject to copyright law, singly and in the aggregate. Whoever copies or disseminates individual passages, images or the complete text without our prior consent, shall receive correspondence from our attorney. You will receive a guarantee of one year from the date of purchase with this table. Exceptions are mechanical defects that are the result of faulty processing or any damage by the user. International buyers are responsible for all duties, taxes, import, export and or customs fees.
