Valcom V-1039 Explosion Proof Indoor Outdoor Speaker Talkback Horn

US $1000

Saint Petersburg, Florida, United States
Jun 5th

Open on mobile:
QR code

This item is new (old stock) in original opened box. EXPLOSION PROOF ONE-WAY PAGING HORN MODEL V-1039 Volume control Not included F HEAVY DUTY STEEL MOUNTING BRACKET DESCRIPTION: Used for high-efficiency reproduction of voice and electronic signals in an explosive or flammable environment. These explosion proof horns are UL Listed approved for use in Class 1, Division 1, Group C & D and Gas Atmospheres. The horn includes a fiberglass projector, built-in 7 watt amplifier, and mounting bracket. Common applications include grain mills, service stations and refineries. The Explosion Proof Horn, Model V-1039A shall be a high efficiency, re-entrant explosion proof horn. It shall be equipped with a removable compression driver. A removable steel mounting bracket allows easy positioning in the vertical and horizontal planes. The frequency response of the horn shall be 250 Hz to 12 kHz. Dispersion shall be 120° horizontal and 60°vertical. Sound pressure level shall be greater than 115 dB @ 4 feet on axis. The explosion paging horn shall be equipped with a built-in amplifier. Amplifier output is 7 watts. Input impedance shall be 600 ohms nominal. The amplifier shall operate on a -24 Vdc, positive ground power supply. Operating current shall be 1.0 Amp at -24 Vdc. Operating temperature shall be -4 to 13°F (-20 to 55°C). Operating humidity shall be 0-95% noncondensing. The bell housing shall be molded of gray fiberglass. The driver shall be all metal construction with a gray epoxy finish. Dimensions shall be 6.0 "H x 14.0 "W x 17.5 "D (15.24 cm x 35.56 cm x 44.45 cm). The weight shall be 19.0 lbs (8.62 kg). cut and paste link to manufacture's data page: valcom.com/lit_library/v1039ats.pdf
