Valcom V-2924a Expandable Talkback Intercom System

US $420

Snellville, Georgia, United States
May 28th

Open on mobile:
QR code

Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge 30 day returns. Please see all pictures showing physical condition. The V-2924A Talkback Intercom System provides 24 stations with one-way, two-way, group call and all call pages. Each station can be programmed for one-way or two-way communication. The stations may be grouped into oneway page groups. The system also provides the ability for a remote speaker location equipped with a call button to call the attendant location. The attendant receives calling speaker identification when using a Caller ID equipped telephone or a Caller ID display. The V-2924A is compatible with standard 45 Ohm speakers and one-way amplified speakers and can be accessed via a single line phone, E-Key line port or PABX loop start trunk port. An RS-232 port on the control unit provides a connection for a serial printer for printout of system activity. The V-2924A provides a background music input and is designed to automatically mute music during a page. The basic system also provides four (4) contact closures associated with the last 4 zones to allow for door strike plate activation. Multiple V-2924A control units can be interconnected to allow global all call and global priority pages for up to six (6) V-2924A control units. The V-2924A Control Unit provides access to 24 stations. A V-2925A Expansion Unit is available for the V-2924A. Each V-2925A Expansion Unit will increase the capacity of the V-2924A by twenty-four (24) additional stations. Up to three (3) Expansion Units can be added to a system for a total of 48, 72 or 96 zones of paging. A V-2926 Plug-in Option Board is also available to provide enhanced Caller ID, flexible architectural numbering, user defined page groups, a secondary serial port for easier programming and real-time clock. A Windows-based programming tool is used with the option board to simplify system programming. The tool can be used with PC compatible computers using the Microsoft Windows operating system. FEATURES 24 zones of handsfree or one-way communication (expandable up to 96 zones) Built-in handsfree amplifier Background music input Built-in all call with "meet me" and "follow me" capability "Ring in" from speaker locations Calls placed in queue Dial tone programmable (On/Off) Alert tone Ringback tone Repeated alert/privacy tone programmable (On/Off) Auxiliary contact closures for zones 21, 22, 23,24 Programmable ring pattern Ring contact closure follows ring cycle Inhibit input Caller identification RS-232 serial printer port Control unit is internally powered (battery backup compatible; (1) VPB-260 per unit) Override port Emergency tone input Time tone input UNA contact closure input All call/priority page through up to six V-2924A systems of any size Group call Programmable class of service CAPACITY The V-2924A is a single talkpath unit. inkfrog terapeak inkFrog Analytics
