Velleman K8055 Usb Experiment Interface Board Kit

US $44.99

  • Boca Raton, Florida, United States
  • Feb 27th
Open on mobile:
QR code
AUTHORIZED DISTRIBUTOR VELLEMAN K8055 USB EXPERIMENT INTERFACE BOARD KIT The K8055 interface board has 5 digital input channels and 8 digital output channels. In addition, there are two analogue inputs and two analogue outputs with 8 bit resolution. The number of inputs/outputs can be further expanded by connecting more (up to a maximum of four) cards to the PC's USB connectors. All communication routines are contained in a Dynamic Link Library (DLL). You may write custom Windows (98SE, 2000, Me, XP) applications in Delphi, Visual Basic, C++ Builder or any other 32-bit Windows application development tool that supports calls to a DLL. Features DIAGNOSTIC / TEST SOFTWARE:separate output / input test clear all / set all function counter function on inputs 1 and 2 with adjustable debounce (max 2kHz depends on total I/O load) analog output set sliders analog input bar-graph indication minimum system requirements:Pentium class CPU USB1.0 or higher connection Windows 98SE or higher (Win NT excluded) CD ROM player and mouse also available in mounted version: VM110 Specifications 5 digital inputs (0= ground, 1= open) (on board test buttons provided) 2 analog inputs with attenuation and amplification option (internal test +5V provided) 8 digital open collector output switches (max. 50V/100mA) (on board LED indication) 2 analog outputs:0 to 5V, output resistance 1K5 PWM 0 to 100% open collector outputs max 100mA / 40V (on board LED indication) general conversion time: 20ms per command power supply through USB: approx. 70mA dimensions: 5.7 x 3 x 0.8" Extras K8055, K8055N, VM110, VM110N application for Android This is an Android version of the demonstration app used for the Velleman K8055, K8055N, VM110 & VM110N USB Experiment Interface Board. Download the application here: K8055 Android Application © 2011 John Marshall plug-in for IPEmotion measurement software Students who are already working with the Velleman K8055 Experiment board will benefit from the plug-in for IPEmotion measurement software.. Download: Velleman K8055 Plugin See how easy it is on Youtube!
