Vernitron Corp Synchro Torque Receiver Model 23tr4 Nsn 5990-00-636-4111

US $38.00

Farmingdale, New York, United States
Jan 29th

Open on mobile:
QR code

VERNITRON CORP SYNCHRO TORQUE RECEIVER MODEL 23TR4 NSN 5990-00-636-4111 NOS CONDITION. NOT USED 14 DAY WARRANTY FOR COMPLETE REFUND. ALT P/NS: 7674819 US ARMY AS20708/94 SOCIETY OF AUTOMOTIVE ENGINEERS 23TR4, 467001-1 NORTHROP GRUMMAN SYSTEMS C737834-2 LOCKHEED MARTIN VTR23/36-4A AXSYS TECHNOLOGIES, Name Value BODY MATERIAL STEEL, STAINLESS BODY STYLE STANDARD ROUND D SHOULDER DIAMETER 1.9850 INCHES MINIMUM AND 1.9900 INCHES MAXIMUM PILOT DIAMETER 0.5900 INCHES MINIMUM AND 0.6000 INCHES MAXIMUM SECOND SHOULDER DIAMETER 1.9985 INCHES MINIMUM AND 1.9995 INCHES MAXIMUM SECOND SHOULDER LENGTH 0.1680 INCHES MINIMUM AND 0.1700 INCHES MAXIMUM OVERALL LENGTH 4.2940 INCHES MAXIMUM FLANGE DIAMETER 2.2490 INCHES MINIMUM AND 2.2500 INCHES MAXIMUM FLANGE THICKNESS 0.2480 INCHES MINIMUM AND 0.2500 INCHES MAXIMUM BODY DIAMETER 1.9850 INCHES MINIMUM AND 1.9900 INCHES MAXIMUM SHAFT DIAMETER 0.2402 INCHES MINIMUM SINGLE SHAFT AND 0.2405 INCHES MAXIMUM SINGLE SHAFT SHAFT LENGTH 0.6930 INCHES MINIMUM SINGLE SHAFT AND 0.7190 INCHES MAXIMUM SINGLE SHAFT MAXIMUM TEMP RISE 65.0 DEG CELSIUS BODY SIZE 23 ROTOR INPUT VOLTAGE RATING IN VOLTS 115.0 NOMINAL FREQUENCY IN HERTZ 400.0 NOMINAL ROTOR INPUT CURRENT RATING 945.0 MILLIAMPERES NOMINAL ROTOR INPUT ELECTRICAL POWER RATING 7.8 WATTS NOMINAL ZRO RESISTANCE IN OHMS 9.10 NOMINAL ZSO RESISTANCE IN OHMS 8.20 NOMINAL ZRS RESISTANCE IN OHMS 12.00 NOMINAL ZSO-90 RESISTANCE IN OHMS 6.16 NOMINAL MAXIMUM FUNDAMENTAL NULL VOLTAGE IN MILLIVOLTS PER VOLT 75.00 OUTPUT MAXIMUM TOTAL NULL VOLTAGE OUTPUT IN MILLIVOLTS PER VOLT 100.00 ELECTRICAL ERROR ANGULAR RANGE IN MINUTES -8.0/+8.0 RECEIVER ERROR ANGULAR RANGE IN MINUTES -60.0/+60.0 TORQUE GRADIENT PER ANGULAR DEG 0.130 INCH-OUNCES NOMINAL ALIGNMENT HOLE QUANTITY 3 PILOT LENGTH 0.0360 INCHES MINIMUM AND 0.0460 INCHES MAXIMUM SHOULDER LENGTH 0.2500 INCHES NOMINAL

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	VERNITRIN CORP.
MPN	5990-00-636-4111
Model	23TR4
Country of Manufacture	United States
