Vernitron Synchro Control Type 23CT4, P/N :7674821, NSN; 5990-00-644-0120, US $25.00 – Picture 0

Vernitron Synchro Control Type 23CT4, P/N :7674821, NSN; 5990-00-644-0120, US $25.00 – Picture 1

Vernitron Synchro Control Type 23CT4, P/N :7674821, NSN; 5990-00-644-0120, US $25.00 – Picture 2

Vernitron Synchro Control Type 23ct4, P/n :7674821, Nsn; 5990-00-644-0120

US $25.00

Farmingdale, New York, United States
Jan 29th

Open on mobile:
QR code

Vernitron Vintage Synchro Control Transformer, Type 23CT4, P/N : 7674821. NSN; 5990-00-644-0120 USED Condition Manufacturing Part Numbers CT23-4X2 AXSYS TECHNOLOGIES INC AY240AA 2 A1 HONEYWELL INTL C767482100 NORTHROP GRUMMAN SYSTEMS 14 Day Warranty for complete refund. Name Value BODY MATERIAL ALUMINUM BODY STYLE A4 STANDARD ROUND D SHOULDER DIAMETER 1.9890 INCHES MINIMUM AND 1.9900 INCHES MAXIMUM PILOT DIAMETER 0.5900 INCHES MINIMUM AND 0.6000 INCHES MAXIMUM SECOND SHOULDER DIAMETER 1.9985 INCHES MINIMUM AND 1.9995 INCHES MAXIMUM SECOND SHOULDER LENGTH 0.1700 INCHES NOMINAL OVERALL LENGTH 4.2430 INCHES MINIMUM AND 4.2940 INCHES MAXIMUM FLANGE DIAMETER 2.2490 INCHES MINIMUM AND 2.2500 INCHES MAXIMUM FLANGE THICKNESS 0.2500 INCHES NOMINAL BODY DIAMETER 1.9900 INCHES MAXIMUM SHAFT DIAMETER 0.2402 INCHES MINIMUM AND 0.2405 INCHES MAXIMUM SINGLE SHAFT SHAFT LENGTH 0.6930 INCHES MINIMUM AND 0.7190 INCHES MAXIMUM SINGLE SHAFT BODY SIZE 23 STATOR INPUT VOLTAGE RATING IN VOLTS 90.0 NOMINAL STATOR INPUT CURRENT RATING 6.0 MILLIAMPERES MAXIMUM STATOR INPUT ELECTRICAL POWER RATING 240.0 MILLIWATTS MAXIMUM FREQUENCY IN HERTZ 400.0 NOMINAL MAXIMUM FUNDAMENTAL NULL VOLTAGE IN MILLIVOLTS PER VOLT 30.00 OUTPUT MAXIMUM TOTAL NULL VOLTAGE OUTPUT IN MILLIVOLTS PER VOLT 60.00 ELECTRICAL ERROR ANGULAR RANGE IN MINUTES -6.0 TO 6.0 ACTUATOR FRICTION TORQUE AT MINUS 55 DEG CELSIUS 0.50 INCH-OUNCES MAXIMUM ACTUATOR FRICTION TORQUE AT PLUS 25 DEG CELSIUS 0.20 INCH-OUNCES MAXIMUM PILOT LENGTH 0.0460 INCHES NOMINAL SHOULDER LENGTH 0.2500 INCHES NOMINAL AFT OF FIRST FLANGE DIAMETER 1.9985 INCHES MINIMUM AND 1.9995 INCHES MAXIMUM MOUNTING SURFACE TO TERMINAL END DISTANCE 3.4350 INCHES MINIMUM AND 3.4450 INCHES MAXIMUM SHAFT THREAD SERIES DESIGNATOR UNF SINGLE SHAFT SHAFT THREAD DIRECTION RIGHT-HAND SINGLE SHAFT SHAFT THREAD CLASS 3A SINGLE SHAFT TERMINAL LOCATION REAR On Jun-21-11 at 08:30:23 PDT, seller added the following information: Sellers: Get your own map of past buyers. Fast. Simple.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Vernitron
MPN	7674821
Model	Type 23CT4
Country of Manufacture	United States
