Vernitron Synchro Resolver Model 23r3n4 Nsn 5990-00-330-5412

US $36.00

Farmingdale, New York, United States
Jan 29th

Open on mobile:
QR code

VERNITRON SYNCHRO TORQUE RECEIVER MODEL 23R3N4 NSN 5990-00-330-5412, US ARMY P;N MIL-R-14346A NOS CONDITION. NEVER USED. 14 DAY WARRANTY FOR COMPLETE REFUND. ALT P/NS: 7677411 US ARMY 23R3N4 MILITARY VRB23/41-4C AXSYS TECHNOLOGIES, Name Value BODY MATERIAL STEEL, CORROSION RESISTING BODY STYLE STANDARD ROUND D SHOULDER DIAMETER 1.9850 INCHES MINIMUM AND 1.9950 INCHES MAXIMUM PILOT DIAMETER 0.5900 INCHES MINIMUM AND 0.6000 INCHES MAXIMUM SECOND SHOULDER DIAMETER 1.9985 INCHES MINIMUM AND 1.9995 INCHES MAXIMUM SECOND SHOULDER LENGTH 0.1700 INCHES NOMINAL OVERALL LENGTH 4.7430 INCHES MINIMUM AND 4.7990 INCHES MAXIMUM FLANGE DIAMETER 2.2490 INCHES MINIMUM AND 2.2500 INCHES MAXIMUM FLANGE THICKNESS 0.2500 INCHES NOMINAL BODY DIAMETER 1.9850 INCHES MINIMUM AND 1.9950 INCHES MAXIMUM SHAFT DIAMETER 0.2402 INCHES MINIMUM SINGLE SHAFT AND 0.2405 INCHES MAXIMUM SINGLE SHAFT SHAFT LENGTH 0.6930 INCHES MINIMUM SINGLE SHAFT AND 0.7190 INCHES MAXIMUM SINGLE SHAFT FRAGILITY FACTOR MODERATELY RUGGED BODY SIZE 23 STATOR INPUT VOLTAGE RATING IN VOLTS 90.0 MAXIMUM STATOR INPUT CURRENT RATING 445.0 MILLIAMPERES MAXIMUM STATOR INPUT ELECTRICAL POWER RATING 5.3 WATTS NOMINAL FREQUENCY IN HERTZ 400.0 NOMINAL ZSO IMPEDANCE MAGNITUDE IN OHMS 234.00 NOMINAL ZSO IMPEDANCE ANGLE IN DEG 83.00 NOMINAL ROTOR DC RESISTANCE IN OHMS 16.50 NOMINAL STATOR DC RESISTANCE IN OHMS 4.70 NOMINAL PHASE SHIFT ANGLE IN DEG 1.300 INPUT TO OUTPUT NOMINAL MAXIMUM FUNDAMENTAL NULL VOLTAGE IN MILLIVOLTS PER VOLT 30.00 OUTPUT MAXIMUM TOTAL NULL VOLTAGE OUTPUT IN MILLIVOLTS PER VOLT 60.00 PILOT LENGTH 0.1090 INCHES NOMINAL SHOULDER LENGTH 0.2500 INCHES NOMINAL AFT OF FIRST FLANGE DIAMETER 1.9985 INCHES MINIMUM AND 1.9995 INCHES MAXIMUM MOUNTING SURFACE TO TERMINAL END DISTANCE 4.0540 INCHES MINIMUM AND 4.0800 INCHES MAXIMUM SHAFT THREAD SERIES DESIGNATOR UNF SINGLE SHAFT

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	VERNITRON
MPN	5990-00-330-5412
Model	23R3N4
Country of Manufacture	United States
