Version 3-channel Ecg Holter System/recoder Monitor+free Analyzer Tlc9803 Fas

US $583.00

Alhambra, California, United States
Jan 30th

Open on mobile:
QR code

TLC9803 3 Channel Holter ECG System Introduction The TLC9803 Holter system is composed of the ECG recorders, a computer system, a laser printer and the software. The recorder has build-in flash storage media that increases its memory capacity. The software of the system is checked by AHA and MIT data, which ensure its accuracy. We are glad to send DOMO of this device if you enquiry it. ECG Holter System--3 Channel Holter Recorder and Analyzer Holter Recorder: Model: TLC9803 Features: v 5-lead Color LCD Holter recorder v Compact size, light weight v Fully programmable, high Fidelity v Lower power consumption v Fast data transfer v Pacemaker detection Specification: v Channel: 3 digital recording channels for 5-lead v Sample rate: 1000Hz v Resolution: 12 bit sampling v Frequency response: 0.05-60Hz v Recording time: 24 hours, full disclosure, no data compression, 5-lead ECG v Storage: 2G built-in flash memory v LCD display: ECG waveform and lead number v Dimension: 80mmx45mmx18mm v Weight: 75g (battery not included) v Lead: 10 wire patient cable (I, II, III, aVR, aVL, aVF, V1~V6) v Power: 2 AA size batteries Holter Analyzer Softeare: CardioScape Holter Functions & Features: v QRS Templates Apply Demix technology, ensures the accuracy of QRS templates, includes N (Normal), V (Ventricular Ectopy), S (SVE), U (Unknown), P (Pacemaker), A (Artifact). All the templates can be combined or separated as individual beats. beats can be superimposed. Weak signal can be identified such as P wave. v Arrhythmia Analysis VE, SVE, aberrant beats, V-Tach, V-Pair, V-Bigeminy, Tri-geminy etc.. v HRT (VE Chaos) Analysis HRT is the most powerful ECG-related risk predictor for assessing the death risk following myocardial infarction. The predictive value is comparable with that of the LVEF. v Pacemaker Analysis Unique pacemaker analysis is suitable for various models i.e. AAI, VVI, DDD, DDR pacemakers. v HRV (Heart Rate Variability) Analysis Time domain and Spectral domain HRV analysis, superlower HRV analysis.(Heart Rate Variability is analyzed in both Time Domain and Frequency.The top of the HRV display shows the Poincare-Lorenz scatter plots. The lower left shows the Frequency power graph. The range boundaries for LF, LF and HF can be adjusted. The lower right shows the Time Domain histogram. Day and night times can be entered for Sleep Apnea and for A-Fib.) v Atrial Fibrillation and Atrial Flutter Analysis v Atrial Fibrillation is very important for the cardiologist concern. Holter ECG is an excellent test to detect transient A-Fib. v OSAS (Obstructive Sleep Apnea Syndrome) Analysis Using Holter test to detect the OSAS earlier and cost-saving. v ST Analysis ST analysis trends, form and support report, identify ischemia location. v TWA (T-wave alterans) Analysis Unknown for the past 40 years, T-Wave Alternans (TWA) in excess of 20 micro-volts have been in Holter recordings but have been undetected. TWA is a strong predictor of V-Tach and other serious cardiac abnormalities. It takes less than 10-seconds to do a complete 24 hours TWA analysis. You can check for TWA anywhere in teh 24hours ECG file. Not only can you detect TWA in the ECG file, this software lets you view the ECG showing the actual TWA, so that you can verify and validate the presence of real TWA. The TWA algorithm detects two modes of TWA. Mode 1 is the beat-to-beat change in T-Wave amplitudes exceeding 20 micro-volts, as shown in the adjacent picture. Mode 2 is the gradual up and down changes of T-wave amplitudes over a series of several beats.. Inside The Box ? 1 Holter recorder? 1 CD of software ? 5 pieces of patient cable ? 20 pieces of disposable ECG Eletrodes ? 1 porch for hanging recorder ? 1 USB cable for data download ? Instruction Manual ? 2 year warranty The following FDA Disclaimer is required for all eBay listing in Healthcare category and is included for REFERENCE: The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. as an authorized purchaser of this item before shipping of the item. Quality First, Service Excellent, Global Trust! Quality First, Service Excellent, Global Trust! Medical equipment,we are more professional

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Ecg
MPN	New Version 3-channel ECG Holter System/Recorder
Model	ECG
