Vertex, Milling, Semi Universal Dividing Head, New. Prev Stop Play Next Vertex, Milling, Semi Universal Dividing Head, New. Semi universal type, comes complete with dividing plates DP-1 and tailstock TS-1. Dividing Head can divide in any angle by the direct, in-direct, or different methods. The ratio between the warm and the warm gear is 40:1. All internals are hardened and grounded, spindle is rigidly held in a taper roller bearing, the swivel head can be locked in any position, from 10 degress below the horizontal to 90 degrees above, (vertical position), the movement is smooth and precise. All models have threaded spindle nose and 24 hole dividing plate with easy conversion to fast direct indexing on numbers 2,3,4,6,8,12, and 24. Easy indexing of all numbers from 2 to 50 and many others from 52 to 380. The head is accurate, precise, have almost non backslash, excellent appearance and a strong structure all combined to offer a smooth operation Hardened and ground spindle is rigidly held in a taper roller bearing. Worm is hardened and ground also. Specifications: Dividing Head. Applicable Chuck: 5" Dividing Head. Measure CFT: 0.8 cubic feet Dividing Head. Weight G.W.: 20 kg Dividing Head. Weight G.W. Case: Carton Dividing Head. Weight. N.W.: 19 kg Head-stock. A: 177mm(6 61/64in) Head-stock. B: 188mm(7 25/64in) Head-stock. H: 173mm(6 51/64in) Head-stock. I: 13mm(1/2in) Head-stock. a: 160mm(6 19/64in) Head-stock. b: 91mm(3 37/64in) Head-stock. g: 16mm(5/8in) Head-stock. h: 100mm(3 59/64in) Head-stock. Spindle Through Hole: 18mm(45/64in) Head-stock. Taper of Center: MT-2 Tail-stock. A1: 155-180mm(6 3/32 - 7 5/64in) Tail-stock. B1: 64mm(2 33/64in) Tail-stock. H1: 107mm(4 13/64in) Tail-stock. I1: 11mm(27/64in) Tail-stock. a1: 134mm(5 17/64in) Tail-stock. b1: 94mm(3 11/16in) Tail-stock. g1: 16mm(5/8in) Tail-stock. h1: 108mm(3 9/64 - 4 1/4in) Tail-stock. Weight N.W.: 4 kg SKU: BS-0-BH Brand: Vertex Condition: New Country of Origin: Taiwan Don’t forget to visit our store! We carry a complete line of products for the metal mechanic enthusiast, if you don’t see what you need, we find it! Over 50 years of combined experience on machining and metal mechanic machinery, from manual machines to CNC, combined with the best prices on the web, you can’t miss! chuck collets setscrew milling drilling precision grip hydraulic tool Holders mill shank Axial Taper cutting Flange Tooling BT bt NMTB nmtb cat CAT gripping End Mill screw nut Squeezers machined drill spindle tension shrink fit toolholders shell arbors arbor morse Morse slim SIMIS tap CNC cnc er ER stubby standard dual DRIVE floating wrenches wrench retention knob boring Boring inch metric Rigid Tapping Coolant 1/32 1/16 1/8 ? ? ? 5/8 3/8 7/64 25/32 13/64 RDO RDA RDF endmill blade Taig clamp power lathe cutter spring solenoid pneumatic grinder grinders Mandrel gib saddle slots headstock drawbolt shaft Crosslide Toggle Switch Leadscrew Post Pivot Pin Tee Nut Self Tapping Thrust Collar CCK NK KM TIR flange set kit Accessories fixtures die bit pull stud mounting volts TMX keyless annular reducers MT2 MT3 MT4 MT5 PowerTool4Less operates from Monday through Friday, 9 am to 5 pm EST. We accept only PayPal payments from confirmed PayPal addresses; through PayPal you can use Visa, MasterCard, American Express, Discover and Debit. In order to insure the security of all parties, we will only ship to the address confirmed by PayPal to the continental 48 states only - by UPS Ground service or USPS. We do not ship to any destinations that are not specified here. Countries besides the US, Puerto Rico, Guam and shipping to Alaska and Hawaii are subject to higher shipping rates. Sorry no PO Boxes or APO/FPO addresses and no collect on delivery (COD), local pick up is available; please contact us for your shipping rate in case you need it. All sales are final. Shipping charges (if any) are not refundable, unless the return is due to our mistake. If you decide you don't need a part, we don't mind taking it back but we can't recover the shipping cost. All returns must be applied within 7 days of receipt. If you refuse delivery or the carrier returns a package because you provided an invalid address, the cost of return shipping will be deducted from your refund. All returns must be approved by us first. Please contact us and we will give you specific instructions on returning the item. We also charge a 20% charge of the item value if the item has free shipping and is returned. This is not accumulated with any other fees. This is simply because once a Free Shipping order has been shipped out; we have already paid for shipping charges that are not refundable. All orders with payment cleared will be sent out within 2 days except weekends and holidays. We highly recommend to inquiring about fitment on parts that requires it before you buy any parts. When inquiring about fitment, please include all relevant information. For shipping quotes, please include your postal code. All our parts are 100% Brand New. Our merchandises are packed carefully and correctly utilizing a triple check method before it leaves our facility. PLEASE INSPECT PART UPON RECEIPT, in the presence of the carrier. Customer is responsible for notifying us of any fault found with the part, for shortage of items or discrepancies, within 48 hours of receipt of merchandise. Please keep all shipping cartons and packing material for carrier inspection. Upon the return of the item, an inspection will determine if the fault is genuine and not customer inflicted. If the fault is ours, you will receive a replacement part at no additional charge. If you refuse delivery for any reason, or the carrier returns a package because you provided an invalid address, the cost of return shipping will be deducted from your refund. Shipping charges (if any) are not refundable unless the return is due to our mistake. All returned items must include a copy of the original packing slip and a Return Manifest Authorization (RMA), no returns will be accepted without a RMA. Once you've received the RMA from us upon your request, you can ship the item as instructed. We will not initiate any claims with the carrier. Any refused shipments sent back does not constitute the right to a refund or credit and will not be accepted. We are here to help you! Always keep this in mind before buying: - Not sure if the part you selected will fit your needs? Please feel free to contact us with any questions about it. We highly recommend to inquiring us before you buy any parts. - Please inspect all items by the time they arrive, in the presence of the carrier. - In case you need to return a part, please send it back to us in original package, there should be no signs of being used. It is the sole responsibility of the customer to confirm the correctness of size and application before use. We will inspect the returned item and verify the problem. If the returned item has been used; no refund will be issued. - Parts include 12 month warranty (please see our Warranty policy). - PROFESSIONAL & QUALIFIED operator is highly recommended. Buyer assumes all risk on usage. - Feedback: Our goal is to meet our customers? expectations by 100% with our products and services. We will give you a positive feedback as soon as we shipped the order. Your positive feedback is highly appreciated. - For shipments to Florida, we are required by State law to collect 7% Sales Tax. - For shipping quotes, please include your Postal code. - WE SHIP WORLDWIDE, but if you are an international buyer, please contact us for your shipping rate, as well if you are located at other than 48 continental states. Buyers are responsible for brokerages fee, duties, and any other expenses. We warranty all parts to be free from defects in material and workmanship for 12 consecutive months, starting from the date on your invoice. This warranty does not cover any expenses for TIME, RENTAL, OR OTHER PARTS not purchased from us, or ANY LABOR. This warranty covers replacing the part only. This warranty is offered only to the original purchaser of the part. This warranty does not apply, and will be voided, if the part sold has been damaged by abuse, misuse, accident, neglect, or alteration, or if it has been repaired. Your warranty will be null and void if the part fails due to improper use. If the part sold should prove defective in material or workmanship within the warranty period, return the part to us, postage prepaid, along with your sales invoice and RMA form properly filled. Your dated invoice will establish your eligibility for the warranty. Welcome to PowerTool4Less, one of America's fastest growing online retailers of power tools and metal mechanic machinery accessories. We are committed to providing you with top quality products from trusted name brands. Our products are designed to enhance performance for all works & reduce machining time in a safe and friendly work environment. PowerTool4Less core belief is to always do what is in the best interest of the customer. Our most important goal is to be regarded as providing the absolute best service in the business. We monitor customer feedback on a daily basis. The team is always fostering improvements and taking pride in delighting and satisfying customers. We are closely connected to the product manufacturers, eliminating middlemen markups and passing the savings on to you, our valuable customer. Not sure if this part will suit your needs? Please feel free to contact us with any questions you may have. Not sure if this part will suit your needs? Please feel free to contact us with any questions you may have about this item. We try to answer all questions within 1 business day; the best way to contact us is through the eBay Messages System.
