Electrocardiograph-ECG300G(vet) Description Introductions ECG300G three channel ECG is such a kind of electrocardiograph,which samples 12 leads ECG signals simultaneously and prints out the ECG waveforms with thermal printing system. Its functions are as follows:recording and displaying ECG waveforms in auto/manual mode;auto-measuring and auto-diagnosing the ECG wave parameters;prompting the state of lead off and paper lack;switching the interface lauguages (Chinese/English);managing the case database. Features ?3.5" TFT Color LCD display shows the working status and ECG waveform. Check the waveform before printing to save record paper. ?12 leads ECG simultaneous acquisition, digital signal processor, to get higher quality ECG waveforms through the AC filter, baseline filter and EMG filter of the ECG signals. ?Simultaneous display of 3/6/12 leads ECG waveform, and the state of printing mode, sensitivity, speed, filter etc., to be easy for interpretation. ?Include multiform printing modes and format, such as auto 3*4 +1, auto 3*4, auto 2*6 +1, auto 2*6, auto 4*3, rhythm 4, rhythm 3, rhythm 2 and manual etc; the length of wave printing can be adjusted and the function of periodic printing is included to satisfy different applications. ?The instrument has the function of regular auto-analysis and auto-interpretation of ECG waveform parameter, provides measurement parameters such as HR, P-R interval, P Duration, QRS Duration, T Duration, Q-T interval, Q-Tc, P Axis, QRS Axis, T Axis, R(V5), S(V1), R(V5)+S(V1) etc and auto-interpretation conclusion to help reducing doctor’s abundance and improve working efficiency. ?The power supply includes both AC/DC. This device includes built-in lithium polymer rechargeable battery. It can standby for 4 hours, print 150 pieces of ECG waveform and print 90 minutes continually under the best DC state to satisfy the need of visiting patients and physical examination. ?It has build-in storage with large capacity, and can memory more than 1000 cases, which is easy for the doctor review and statistic. ?Support Chinese, English, Spanish, Turkish, Polish, Spanish, French, German Operating interface, can print out Chinese, English, Polish report. Technical Specification ?Safety Type: Class I, Type CF applied part,which has defibrillation-proof applied part ?Lead : Standard 12 leads ?Input way: Floating and defibrillation protection ?Patient leak current : <10?A ?Sampling rate : 1000Hz ?A/D conversion: 12bit ?Frequency response: 0.05Hz~150Hz (-3dB, + 0.4dB) ?Time constant: >3.2s ?CMRR: >60dB, >100dB( With AC filter) ?Enduring polarization voltage: ±500mV ?Noise level: =20dB) ?Recording way : Thermal printing system(8spots/mm) ?Recording paper: 80mm(W)x20m(L) ?Sensitivity: 2.5mm/mV 5mm/mV 10mm/mV 20mm/mV 40mm/mV ?Paper speed: Auto-mode: 25mm/s, 50mm/s Manual-mode: 5mm/s, 6.25mm/s, 10mm/s, 12.5mm/s, 25mm/s, 50mm/s ?Power supply:AC:100/240V,50/60Hz DC:7.4V, 3700 mAh rechargeable lithium battery ?Fuse Specification: 2 pcs ?5x20mm AC time lag; T1.6A/250V(Power Supply:220V) ?Size: 315mm(L) x 215mm(W) x 77mm(H) ?Net Weight: 2.25Kg Accessories: ?ECG leads 1 set ?Limb electrode clamp 1 set ?Chest electrode 1 set ?Power connection 1 piece ?Ground wire 1 set ?User manual 1 set Option: ?ECG-Sync software, connect with the PC by USB connector to form a ECG workstation, collect real-time data to the software to analyze and print the report, and can update the old cases in the ECG machine to PC. It has optional functions of FCG, HFECG, QTd, HRV analysis etc. Certification ?CE,CCC ?Safety Type Class I, Type CF applied part, which has defibrillation-proof applied part ?Lead Standard 12 leads ?input way: Floating and defibrillation protection ?Patient leak current <10µA ?Sampling rate 1000Hz ?A/D conversion 12bit ?Frequency response 0.05Hz~150Hz (-3dB, + 0.4dB) ?time constant >3.2s ?CMRR >60dB, >100dB( Add filter) ?Enduring polarization voltage: ±500mV ?Noise level =20dB) ?Recording way Thermal printing system(8spots/mm) ?Recording paper 80mm(W)x20m(L) ?Sensitivity 5mm/mV 10mm/mV 20mm/mV 40mm/mV Auto ?Paper speed: Auto-mode: 25mm/s, 50mm/s Rhythm-mode:25mm/s, 50mm/s Manual-mode:5mm/s, 6.25mm/s, 10mm/s, 12.5mm/s, 25mm/s, 50mm/s ?Power supply: AC:220V,50Hz(110V ,60 Hz) DC: 7.4V, 3700 mAh rechargeable lithium battery ?Fuse Specification: 2 pcs ?5x20mm AC time lag; T1.6A/250V(Power Supply:220V) ?Size: 315mm(L) x 215mm(W) x 77mm(H) ?Net Weight 2.25Kg The following FDA Disclaimer is required for all eBay listing in Healthcare category and is included for REFERENCE: The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If so, do not bid on this item unless you are an authorized purchaser. If the item is subject to FDA regulation, We will verify your status as an authorized purchaser of this item before shipping of the item. Certifications from CONTEC Medical systems: CE & ISO certification Shipping *By Airmail: Generally, about 20-35 working days *By Express: Generally, about 7-15 working days We can also ship the item through express service like TNT,DHL, UPS, if you are ready to pay the extra charge. To know the details please contact us with messages. 1. For your earlier and safer to receive the item, please leave us your detailed address and telephone number for posting the item. 2. Your item will be sent via small parcel within 48 hours after payment is received. The shipping time may is around 5-15days. 3. As the usual way, the buyers are responsible for the duties, taxes or other VAT or extro charges from the import countries. Taxes, Customs & Duties There are not extra taxes, VAT or other unmentioned payment. You pay us with goods subtotal + shipping cost (not include duties).But you need to pay for the importn duties in case that occurred for certain goods,or you may kindly give us some suggestionsabout that,we promise to do our best to help you! Terms of Sale We offer 14 days return policy. 100%satisfaction is our goal! 1.All items are brand new ,with 1years warranty. 2.If you have a defective item, you want to return or discount. Please contact us within 2 days from you receive the shipment. 3.We will refund the money to you when we get the return items or replace item for you. 4. All return items must be returned with it's original packaging and accessories. Customer is responsible for shipping charges on returned items. International Buyers - Please Note: ? Import duties, taxes and charges are not included in the item price or shippingcharges. These charges are the buyer's responsibility. ? Please check with your country's customs office to determine what these additional costs will be prior to bidding/buying." About Us Contec Medical Systems focusing on research, manufacture and distribution of medical instruments,was founded in 1992 as a high-tech company.At present there are more than 1200 employees in our company.Our product line covers a wide range of 13 categories.Most of the domestic hospitals are our customers. Contec hopes to cooperate with international companies to supply more innovative design and advanced technology products We sincerely welcome you to become one of our global partners.We are looking forward to establishing a successful business relationship with you.
