VGA OV7670 CMOS Camera Module Lens CMOS 640X480 SCCB Compatible W/ I2C Interface, US $10.99 – Picture 0

VGA OV7670 CMOS Camera Module Lens CMOS 640X480 SCCB Compatible W/ I2C Interface, US $10.99 – Picture 1

Vga Ov7670 Cmos Camera Module Lens Cmos 640x480 Sccb Compatible W/ I2c Interface

US $10.99

Spotsylvania, Virginia, United States
Mar 2nd

Open on mobile:
QR code

OV7670 Digital CMOS Camera Buy American: get it faster. We ship from our facility in the United States! Description High sensitivity for low-light operation Low operating voltage for embedded application Standard SCCB interface compatible with I2C interface. Raw RGB, RGB (GRB4:2:2, RGB565/555/444), YUV(4:2:2) and YCbCr(4:2:2) output formats Support VGA, CIF and from CIF to 40 x 30 format Auto Image Control: AEC, AGC, AWB, ABF, ABLC Image Quality Control: Color saturation, hue, gamma, sharpness and anti-blooming ISP includes noise reduction and defect correction Support image scaling Lens shading correction Flicker 50/60Hz auto detection Color saturation level auto adjust Edge enhancement level auto adjust De-noise level auto adjust Package Contents 1 Camera Module Specifications Sensor Type: CMOS Resolution: 640 x 480 px I/O Voltage: 2.5V to 3.3V Operating Power: 60mW / 15 fps VGAYUV Sleeping Mode: <20?uA Operating Temperature: -30 to 70 deg C Output Format: YUV/YCbCr4:2:2, RGB565/555/444, GRB4:2:2, Raw RGB Data (8 digit) Lens Size: 1/6 in Vision Angle: 25 degree Max. Frame Rate: 30fps VGA Sensitivity: 1.3V / (Lux-sec) Signal to Noise Ratio: 46 dB Dynamic Range: 52 dB Scan Mode: By row Electronic Exposure: 1 to 510 row Pixel Coverage: 3.6?um x 3.6 um Duck Current: 12 mV/s at 60°Cdeg C PCB Size (L x W): 1.4 x 1.4 in / 3.5 x 3.5 cm

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	VGA OV7670 CMOS Camera Module
MPN	VGA OV7670 CMOS Camera Module
