Viavi Jdsu Onx-630 One Expert Euro Docsis 3.1 Onx-catv-d31-s-6520-1212 Onx630

US $4,995.00

Scottsdale, Arizona, United States
Jul 11th

Open on mobile:
QR code

Viavi ONX-630 OneExpert CATV Docsis 3.1 Tester w/ Viavi ONX-CATV-D31-S-4285-1012 Module Small scratch on the screen protector. Condition: Excellent Condition. Works Great Installed Options: - Ingress Expert - IPX Package - NTX Package - ONX BLUETOOTH SW OPT - ONX DOCSIS 3.1 OFDM - ONX DOCSIS 32x8 BONDING - ONX FORARD SWEEP - ONX MOBILE SW OPT - ONX REVERSE SWEEP - OneCheck Expert - Ookla Speedtest - REVERSE ALIGNMENT - RSG LOOPBACK - SWEEPLESS SWEEP - SWX PACKAGE - TSX PACKAGE - VoIP The OneExpert CATV ONX-630 is a powerful meter for maintaining HFC networks, including DOCSIS performance analysis, spectrum analyzer, and forward and reverse sweep measurements JDSU OneExpert ONX-630 CATV Tester OneExpertTM CATV helps field technicians fix problems right— the first time. A technician-friendly interface and OneCheck™ automated tests ease complex tasks with a simple dashboard that shows clear pass/fail results. And its future-proof modularity ensures years of use supporting CATV networks. Comprehensive Tools Increase Productivity We built expertise into OneExpert so that technicians at any skill level can quickly optimize performance. With a modular platform that adapts easily to rapidly changing technologies, OneExpert CATV is: Simple — Auto channel identification eliminates channel plan build, maintenance, and deployment overhead and enables automated testing without the potential for channel plan related test failures Fast — OneCheck uses powerful processing and exceptional speed to make more complete testing practical: a tech can run a comprehensive test, including MER and BER on all channels, in about a minute Powerful — More intelligent, powerful algorithms running in the background while testing enables the meter to point out any problems and suggest next troubleshooting steps Benefits: Simplifies and speeds testing and troubleshooting Improves compliance and audit performance Reduces rework Turns any technician into an expert Features: Real-time channel identification eliminates the need for channel plans and plan-related errors 32x8 DOCSIS® 3.0, DOCSIS 3.1, WiFi, 1 Gigabit Ethernet capable, and TrueSpeed™ option Field-exchangeable DOCSIS/RF module A unique dual-diplexer design supports 42/85 or 65/204 MHz networks WiFi 2.4/5 GHz, Bluetooth, StrataSync™ enabled Simultaneous ingress and downstream testing Applications: Troubleshooting QAM carriers/home networks Verifying WiFi in 2.4 GHz and 5 GHz networks Turning up business services Testing Gigabit DOCSIS services Installing PON/RFoG including inspection, power levels, and RF performance Specifications: Frequency Range Diplexer Upstream Downstream ONX-630 - Automatically Switching Diplexer 42/85 4 - 42 MHz and 4 - 85 MHz 54 - 1,004 MHz and 108 - 1,218 MHz 65/204 4 - 65 MHz and 4 - 204 MHz 83 - 1,218 MHz and 258 MHz - 1,218 MHz Accuracy ±10 ppm typical @25°C Downstream Analysis — Port 1 AutoChannel plan builder Auto detection of channel parameters (analog/digital, symbols, QAM) Max input power 60 dBmV total integrated power Operation on powered tap Operate with up to 90 V AC/DC on input port Power detection / notification Notify of AC/DC power presence on port 2 above 2 Volts Return loss >9 dB Upstream Analysis - Port 2 Ingress spectrum scan 0.5 – 204 MHz Sensitivity 45 dBmV RBW 300 kHz Min detectable level upstream 55 dBmV Dynamic range ONX-630 – 60dB Max total integrated power 55 dBmV, 4 – 10 MHz; 60 dBmV, 10 to 204 MHz Accuracy ±2 dB typical at 25°C Sampling rate Hyper SpectrumTM FFT gapless technology - no missed samples, spans 0.5 -110 MHz, 110 to 160 MHz, and 160 to 204 MHz Return loss >9.5 dB Operation on powered tap Operate with up to 90 V AC/DC on input port Power detection / notification Notify of AC/DC power presence on port 2 above 2 Volts Upstream Signal Generator Number of signals generated simultaneously From 1 to 8 Signal types signals either all CW or all modulated Modulation supported QPSK, 16 QAM, and 64 QAM Symbol rates supported 5.12, 2.56, 1.28, 0.64, 0.32, and 0.16 Msym/s Analog Channel Measurement Video and audio levels (dual) Standards NTSC , PAL, SECAM Min detectable signal 50 dBmV (single channel) Level accuracy ±1.5 dB from 20 dBmV to +50 dBmV typical at 25°C; ±2.0 dB, 10°C to +50°C RBW 300 kHz Carrier to Noise Channel types NTSC , PAL, SECAM, non-scrambled Range 30 to 51 dB (NTSC, 4 MHz measurement bandwidth) Required input level 0 to +40 dBmV with 77 analog channels present, maximum ±15 dB tilt 50 to 1,000 MHz Accuracy ±2.0 dB within specified measurement range 600 MHz Downstream Digital Channel Analysis Calibrated power levels -20 dBmV to +50 dBmV Level accuracy ±1.5 dB from -20 dBmV to +50 dBmV typical at 25°C; ±2.0 dB, -10°C to +50°C Modulation(s) 64, 128, and 256 QAM, OFDM Annex A: 5.057 to 6.952 MSPS Annex B: 5.057 for 64 QAM and 5.361 MSPS for 256 QAM Annex C: 5.274 MSPS for 64 QAM and 5.361 MSPS for 256 QAM Regional demods DVB-C Full span MER Ingress under carrier — full span ingress noise trace Group delay and in-channel frequency response (ICFR) Digital quality index (DQI) over time Errored/severely errored seconds Level, measured symbol rate, carrier frequency, modulation, interleaver depth Hum Specification Hum frequency range 25 Hz to 1000 Hz Minimum MER 33 dB Accuracy up to 5% hum +/- 0.8% From 5% to 10% +/- 1.0% OFDM Signal Performance Metrics OFDM Channels 24 - 192 MHz wide - up to 3 active OFDM channels Level - max, min, average, standard deviation relative to a 6 MHz carrier per CableLabs MER - max, min, average, standard deviation, percentile 12 to 50 dB MER channel band graph max, min, avg across entire OFDM carrier Noise max Echo dBc ICFR in-carrier frequency response (dB) Spectrum/IUC spectrum display, including carrier and ingress under carrier OFDM Profile Analysis Profiles A, B, C, D, NCP, and PLC (more profiles as implemented) Lock status, codeword errors (corrected and uncorrected) DOCSIS Testing Supports DOCSIS 3.1 bonding up to 32 SC-QAM + 2 OFDM downstream channels, 8 SC-QAM + 2 OFDMA upstream channels Compliant with CableLabs® specifications for DOCSIS 3.1 Compliant with CableLabs® specifications for DOCSIS 3.0 (32x8 bonding) Displayed DOCSIS Results Top level Number of bonded channels, min receive level, max BER (pre-FEC), min and max MER, max transmit level, max ICFR (in-channel frequency response) Details Downstream SC-QAM (over time charts: level, MER, BER, DQI), Upstream (charts: transmit over time, upstream ICFR, upstream EQ taps Service tests Registration, Throughput, Pin/ Traceroute, Packet Quality; cable modem pass-through OFDM OFDM selected in scan, number of subcarriers, PLC lock status, frequency, level, and MER, CWE (corr, uncorr); OFDM channel(s) - Level variation (max, min, avg), MER variation (max, min, avg), ICFR, profile analysis (locked, CWE corr, CWE uncorr) Downstream Frequency range 54/85/108/258 to 1,000/1,218 MHz (dependent on currently active diplexer frequency) Upstream Frequency range 5 to 204 MHz (dependent on currently active diplexer frequency) OFDMA channels 2, per DOCSIS specification Transmit level range (max) +61 to +48 dBmV depending on modulation format and number of bonded carriers, per DOCSIS specification SC-QAM channels up to 8 per DOCSIS specification MER Specified range (with input level -5 to +20 dBmV) 21 to 40 dB, 64 QAM; 28 to 40 dB, 256 QAM; 16 to 44 dB OFDM Max displayable range 50 dB Resolution 0.1 dB Accuracy ±2 dB typical at 25°C Minimum lock level 15 dBmV BER - ChannelCheck and DOCSISCheck Mode Down to 1E-9 (pre and post FEC) BER - OneCheck mode Down to 1E-8 (pre and post FEC) default; 1E-9 user selectable Interleaver depth 128, 8 max Display/Interface/Usability High-brightness color LCD (800 x 480) 5 inch diagonal Touch screen Capacitive Hard key navigation capable Boot time Approximately 20 sec Environmental For indoor/outdoor use IP 54 light rain (0.5 in/hr; 1.27 cm/ hr) Pollution 2° Drop 1m (3.3 ft) onto concrete Temp range Operating 10 to 50°C (14 to 122°F) Storage temp 20 to 60°C (-4 to 140°F) Humidity 10 – 90% RH non-condensing RF immunity 8.5 V/m (for CATV measurements) Maximum altitude 4000 m (13,123 ft) Input/Outputs RF (2) F connectors replaceable Port 1 Downstream 54/85/108/258 MHz depending on diplexer Port 2 Upstream 4 – 204 MHz and TDR USB host (2) Ethernet (2) RJ45 10/100/1000T Power Polarized Remote Access/Connectivity VNC accessible via IP address HTTPS file access via IP address Mobile application via Bluetooth Battery Field replaceable 96 W/hr 10.4 V, 10-cell LiIon Typical battery life 6 – 8 hr continuous, 15 – 20 hr typical usage Battery charge time 4 Hrs (90%) 6 - 8 Hrs 100% (AC charger) StrataSync Reporting Capability Session based (job/work order) file saving of results gathered at TAP, GB, and CPE Measurement screen capture save and recall StrataSync Core Asset and data management StrataSync Plus Optional extended data management (6 years) Weight ONX-630 5.95 lb (2.7 kg) Protective case and shoulder strap 0.95 lb WiFi Test interface 802.11 a/b/g/n (2.4/5 GHz) Tests WiFi scan; WiFi access point (2.4 GHz only) Scan results SSID (secure set identification); Channel; Security setting; Power level; MAC address Scan modes AP list (access point); Channel graph; Time graph Access point (IPX, TSX models only) Configure OneExpert CATV as WiFi access point (Ethernet to WiFi bridge)

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Model	OneExpert
Brand	JDSU
MPN	ONX-630
