Victorshome Changeover Switch Lw28-32 3 Positions 8 Terminals Universal Rotary C

US $22.92

Denver, Colorado, United States
Aug 28th

Open on mobile:
QR code

Store New Arrivals Add to Favorite View Feedback Contact VictorsHome Changeover Switch LW28-32 3 Positions 8 Terminals Universal Rotary Cam Selector Latching Switches 690V 32A Description Item model number Z20190120W04 Part Number Olikmuiu-083 Batteries Required? No Item Dimensions LxWxH 2.56 x 2.56 x 2.24 inches Plug Profile Panel Mount Item Weight 8.1 ounces Product Dimensions 2.56 x 2.56 x 2.24 inches Material Metal Switch Style Slide Switch Terminal Screw Manufacturer VictorsHome Operation Mode ON-OFF-ON Batteries Included? No Measurement System Metric, Imperial Actuator Type Rotary Circuit Type 3-way Size 8 Terminals 32A Is Discontinued By Manufacturer No Brand VictorsHome Contact Material Silver HIGH QUALITY DESIGN: Flame retardant PC material shape has good insulation and high temperature resistance. With flexible handle conversion, rotary selector is easy to control, square plate and screws for easily mounting. EXCELLENT COPPER PARTS: Premium copper parts with silver alloy point, make it not easy to slideand has strong thermal conductivity. The quality and service life of changeover switch are improved, it is durable for use. TECHNICAL SPECIFICATIONS: Model: LW28-32/2, 3 positions(1-0-2), 2 phases, 8 terminals latching type switch, Ui 690V Ith 32A. Image 3 has shown which terminal will be connected in different position, please read the wiring diagram as a reference. WIDE APPLICATION RANGE: Ideal for electrical wiring in the power switch, speed switch and induction motor, also can make the conversion of the control circuit. WHAT YOU GET: 1pcs x Changeover Switch, 4pcs x Screws. Technical parameters as images show. If you have any question, please feel free to contact us ! Size:8 Terminals 32A Description 1. Suitable for the thickness between 1mm to 5mm of the mounting board. 2. Ideal choice for electrical wiring in the power switches, speed switches and asynchronous motor for their start-up and reversing, also can make the conversion of the control circuit. 3. Widely used as circuit control switches, test equipment switches, motor control switches and master control switches, signal transfer switches, or change-over switch for electric welding machinery and other equipment. Image3 has shown which terminal will be connected in different position , please read the wiring diagram as a reference. Position 1 : 1-2 , 5-6 Position 0 : All terminal disconnected Position 2 : 3-4 , 7-8 Specifications Model: LW28-32/2 Positions: 3 Terminals: 8 Ui: 690V Ith: 32A Action Type: Latching Positioning angle: 60-0-60 Degree Rating: DC-13: Ui: 220V, Ith: 0.14A; AC-15: Ue / Ie: 380V / 1.5A Mounting Hole Distance: 48mm x 48mm / 1.89inch x 1.89inch (L*W) Total Size: 65mm x 65mm x 94mm / 2.59inch x 2.59inch x 3.7inch (L*W*H) Package Content 1 x Changeover Switch 4 x Mounting Screws

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	VictorsHome
Terminal	Screw
Item model number	Z20190120W04
Manufacturer	VictorsHome
Part Number	Olikmuiu-083
Operation Mode	ON-OFF-ON
Batteries Required?	No
Batteries Included?	No
Item Dimensions LxWxH	2.56 x 2.56 x 2.24 inches
Measurement System	Metric, Imperial
Plug Profile	Panel Mount
Actuator Type	Rotary
Item Weight	8.1 ounces
Circuit Type	3-way
Product Dimensions	2.56 x 2.56 x 2.24 inches
Is Discontinued By Manufacturer	No
Material	Metal
Contact Material	Silver
Switch Style	Slide Switch
Type	Does not apply
