Vishay Uf5402-e3/4t Diode Switching 200v 3a 2-pin Do-201ad T/r, Rectifier

US $230

  • Kennesaw, Georgia, United States
  • Jun 24th
Vishay Diode Switching 200V 3A 2-Pin DO-201AD T/R, Rectifier Selling balance of roll as (1) Unit = 235 pcs / Will remove from roll for shipping purposes. Specifications EU RoHS Compliant  Type Switching Diode Minimum Operating Temperature (°C) -55 Maximum Operating Temperature (°C) 150 Peak Reverse Current (uA) 10 Configuration Single Packaging Tape and Reel Peak Reverse Repetitive Voltage (V) 200 Maximum Continuous Forward Current (A) 3@Ta=55C Peak Reverse Recovery Time (ns) 50 Peak Forward Voltage (V) 1 Peak Non-Repetitive Surge Current (A) 150 Operating Junction Temperature (°C) -55 to 150 Package Diameter (mm) 5.3(Max) Mounting Through Hole Package Length (mm) 9.5(Max) PCB changed 2 Standard Package Name DO-201-AD Supplier Package DO-201AD Pin Count 2 Lead Shape Through Hole
