Voltech Ps1000 Solid-state Switch For Inrush Current Measurement W/ Power Meter

US $150.00

Tottenham, Ontario, Canada
Jan 29th

Open on mobile:
QR code

This item is a Voltech PS1000 Solid-state Switch for accurate Inrush Current Measurement with a Power Meter. All pictures are of the actual unit. This item comes with a 1 Month (30 day) warranty. All functions are guaranteed to work or money will be refunded (buyer pays return shipping only). The Voltech PS1000 solid-state switch controls the turn-on of an AC supply to allow accurate measurement of the inrush current into an AC load. It is designed for use with Voltech power analyzers such as the PM100, PM300 or PM3000A. A push-button switch on the PS1000 front panel allows the turn-on point of the AC supply to be selected between the zero-crossing or peak value of the AC voltage waveform. Trigger point accu- racy for supply frequencies in the range from 40Hz to 440Hz is automatically maintained by a phase-locked loop in the unit. A fully isolated trigger output is provided on a rear-panel BNC connector, so that other equipment, such as a storage oscilloscope, can be triggered when the PS1000 turns the AC supply on. Self-powered from the AC supply that it controls, the PS1000 connects directly into the load circuit via 4mm safety sockets on its front panel. It is housed in a fully insulated, impact resistant ABS case. Specification AC Supply Voltage: 80V to 265V rms AC AC Supply Frequency: 40Hz to 440Hz Peak Inrush Current: 200A maximum Protection: Fuse 5AT HRC 20mm on rear panel External Trigger Output: Amplitude: 2V Pulse Width: 5?s Isolation: 2.5kV rms (sinewave) to the front-panel AC supply terminals Environmental Conditions: Operating Temperature: 5° to 40°C Storage Temperature: -40° to +70°C Humidity: 10% to 80% RH,non-condensing Operation: z Connect the PS1000 as shown in the circuit illustration opposite. z Set the trigger point on the PS1000 to 0° (zero crossing) or 90° (peak voltage), as required. z Set up the power analyzer for inrush current measurement. z Energize the AC supply. z Press the RUN button on the front panel of the PS1000. On pressing RUN, the PS1000 will connect the AC supply to the load at the next programmed trigger point (0° or 90°) on the source voltage waveform, disconnecting it again at the 180° point when the voltage falls to zero. The front panel LED will be illuminated when the voltage is applied. You may select the trigger point that gives the maximum inrush current depending on the type of load: z Inductive loads such as transformers and motors -0° z Resistive loads such as lamps and heaters -90° z Capacitive loads such as switch-mode power supplies -90° Because the PS1000 is self-powered, a leakage current of a few mA flows through the unit, even when its solid-state switch is in the 'OFF' condition. In applications where the load is capacitive, this current will prevent proper discharge of the capacitor between measurements. The problem can be simply resolved by fitting a 1000?, 1-watt bleed resistor in the position shown in the circuit, where it will provide the necessary discharge path without affecting the measurement of peak inrush currents in the load. For more information, see data sheet: http://www.farnell.com/datasheets/1650904.pdf Any questions or clarifications, feel free to ask Please see our other items! We accept VISA / Mastercard by phone, mail, or email. Paypal is also accepted. International Buyers – Please Note: Import duties, taxes, and charges are not included in the item price or shipping cost. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to bidding or buying. UPS/FedEx brokerage charges are typically higher than Canada Post/USPS/local post office. Will ship worldwide. We make our best efforts to get you the best shipping prices. Contact us for other international rates and we will be pleased to give you a quote. Sales to within Canada are subject to 5% GST. Ontario sales subject to 13% HST.

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Unit is in good condition, was a demo unit.”
