W5500 Ethernet Shield Ethernet Network Module With Sd Card Slot

US $140

Shen Zhen, China
Mar 8th

Open on mobile:
QR code

W5500 Ethernet Shield Ethernet Network Module With SD Card Slot HOME DESCRIPTION PAYMENT SHIPPING TERMS OF SALE ABOUT US DESCRIPTION W5500 Ethernet shield is a WIZnet W5500 breakout board with POE and Micro-SD designed for Arduino platform. 5V/3.3V compatible operation voltage level makes it compatible with Arduino boards, leafmaple, and other Arduino compatible board. WIZnet's Hardwired TCP/IP is the market-proven technology that supports TCP, UDP, IPv4, ICMP, ARP, IGMP, and PPPoE protocols. W5500 embeds the 32Kbyte internal memory buffer for the Ethernet packet processing. If you use W5500, you can implement the Ethernet application just by adding the simple socket program. It's faster and easier way rather than using any other Embedded Ethernet solution. Users can use 8 independent hardware sockets simultaneously. Features 3.3/5V level On-board micro SD card slot Support Endspan and Midspan Modes POE Supports following Hardwired TCP/IP Protocols: TCP, UDP, ICMP, IPv4, ARP, IGMP, PPPoE Supports 8 independent sockets simultaneously Supports Power down mode Supports Wake on LAN over UDP Supports High Speed Serial Peripheral Interface (SPI MODE 0, 3) Internal 32Kbytes Memory for Tx/Rx Buffers 10BaseT/100BaseTX Ethernet PHY embedded Support Auto Negotiation (Full and half duplex, 10 and 100-based) Not support IP Fragmentation Specification PCB size 83.82mm X 57.91mm X 1.6mm Power supply 5V DC Indicator SPD,LINK,DUP,ACT Communication Protocol SPI Electronic Characteristics Parameter Min. Typical Max. Unit Power supply 4.5 5 5.5 VDC Input voltage VinH(Target voltage=3.3V) 3 3.3 3.6 V Input voltage VinH(Target voltage=5V) 4.5 5 5.5 V Input voltage VinL -0.3 0 0.5 V Current Consumption - - 150 mA Indicator LED - SPD:Speed LED. This shows the speed status of the connected link.ON:100MbpsOFF:10Mbps- LINK:Link LED. This shows the Link status.ON:Link is establishedOFF:Links is not established- DUP:Duplex LED. This shows the Duplex status for the connected link.ON:Full-duplex modeOFF:Half-duplex mode- ACT:Active LED. This shows that there is carrier sense(CRS) from the active Physical Medium Sub-layer(PMD) during TX or RX activity.ON:Carrier sense from the active PMDOFF:No carrier senseReset It will reset W5500 if you press this button.Pin Map Pin Description D0 Rx/Breakout D1 TX/Breakout D4 SD_CS D10 W5500_CS D11 SPI MOSI D12 SPI MISO D13 SPI SCK A0 Breakout A1 Breakout A2 Breakout A3 Breakout A4 IIC_SDA/Breakout A5 IIC_SCL/Breakout A0 Breakout Package include: 1 x W5500 Ethernet Shield Ethernet Network Module With SD Card Slot PAYMENT We accept PayPal only. SHIPPING 1.Items are shipped from china.we will send out within 1 bussiness day after receive the payment. 2.We only ship to ebay confirmed address. So before bidding, please kindly verify your ebay address. 3.Shipping to USA takes 8-18 days in normal condition by E-packet with tracking number. Shipping to most other countries takes about 12-30 days via Economy Int'l Airmail. Less than $40, without tracking number,if you request tracking number,please pay $3 more and let me know. Over $40,with tracking number free.The shipping time depends on your location and local postal service,as well as the weather condition along the shipping,sometimes may take longer,.please contact us to confirm before leave feedback or open case. 4.Express shipping: Extra $20 --$25 will be charged for the first 500 grams for most countries. Contact us if you need this service. TERMS OF SALE 1.If you are not satisfied when you receive your item, please return it within 30 days for a replacement or money back. Please contact us before you return it. 2.If item is defective in 30 days, We will send you a replacement without extra charger, or offer refund after we receive the defective item. 3.If item is defective after 30 days, you can still send it back to us. We will send you a new one after receiving the defective item. But you have to pay the extra shipping fee. ABOUT US We are honest seller and do our best to serve you. So if you have any concerns,please don’t hesitate to contact us by ebay message. We will do your best to help you out.please don’t leave negative/ neutral feedback or open case before contact us. On Mar-08-15 at 06:01:58 PDT, seller added the following information:
