Waltham, Raytheon Power Transformer 10175869, NSN 5950007632343, Appears Unused, US $580 – Picture 0
Waltham, Raytheon Power Transformer 10175869, NSN 5950007632343, Appears Unused, US $580 – Picture 0

Waltham, Raytheon Power Transformer 10175869, Nsn 5950007632343, Appears Unused

US $580

  • Hurricane, Utah, United States
  • Jun 2nd
Open on mobile:
QR code
Waltham, Raytheon Power Transformer 10175869 NSN 5950007632343 Appears Unused Government Specs Below :   Technical Characteristics ( ILs )        MRC Requirement Reply  AEHZ  III MAXIMUM OPERATING TEMP  130.0 DEG CELSIUS  AAJF  (NON-CORE DATA) THREAD DIRECTION  RIGHT-HAND SINGLE GROUP  TTQY  TERMINAL TYPE AND QUANTITY  22 TAB, SOLDER LUG  AKNA  INCLOSURE TYPE  OPEN  AAJD  (NON-CORE DATA) THREAD CLASS  2B SINGLE GROUP  SR-1  MFR SOURCE CONTROLLING REFERENCE  10175869  AKPV  MOUNTING FACILITY QUANTITY  4 SINGLE GROUP  CQLC  (NON-CORE DATA) WINDING TAP LOCATION  MULTIPLE TAPS W/O CENTER TAP SINGLE COMPONENT SINGLE PRIMARY  BPLC  WINDING FUNCTION AND QUANTITY  1 PRIMARY AND 1 SECONDARY SINGLE COMPONENT  AXGY  MOUNTING METHOD  THREADED HOLE SINGLE GROUP  ACZX  WINDING SHIELDING METHOD  INTERNAL SHIELD GROUNDED TO CORE AND BROUGHT OUT TO TERMINAL SINGLE COMPONENT  ABKR  CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO WIDTH  2.125 INCHES NOMINAL SINGLE MOUNTING FACILITY SINGLE CENTER GROUP  AARG  RELIABILITY INDICATOR  NOT ESTABLISHED  CMLP  THREAD QUANTITY PER INCH  32 SINGLE GROUP  ACZC  INPUT-OUTPUT PHASE RELATIONSHIP  THREE PHASE TO THREE PHASE SINGLE COMPONENT  ACZB  FREQUENCY RATING  400.0 HERTZ NOMINAL SINGLE COMPONENT  SR-1  MANUFACTURERS CODE  18876  CWJS  WINDING OPERATING VOLTAGE  7.96 AC KILOVOLTS MINIMUM AND 8.84 AC KILOVOLTS MAXIMUM SINGLE COMPONENT SINGLE SECONDARY  CRBZ  WINDING OPERATING CURRENT  75.0 MILLIAMPERES AC MAXIMUM SINGLE COMPONENT SINGLE SECONDARY  ABKQ  CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO LENGTH  3.500 INCHES NOMINAL SINGLE MOUNTING FACILITY SINGLE CENTER GROUP  THSD  THREAD SERIES DESIGNATOR  UNC SINGLE GROUP  CQJX  NOMINAL THREAD SIZE  0.164 INCHES SINGLE GROUP  ADAU  BODY HEIGHT  3.438 INCHES MAXIMUM  ADAT  BODY WIDTH  3.000 INCHES NOMINAL  ADAQ  BODY LENGTH  4.531 INCHES NOMINAL Subject to prior sale! Photos show everything that is included. For more information, please feel free to visit our ME page. Handling fee may apply to items requiring additional packing time or materials. 30 day right of return if not satisfied. Thanks for looking!!! Please visit our store for more great items! 2838 3B-22
