Waveline 233 Waveguide Elbow 90 Deg. H plane WR-284, US $65.00 – Picture 0
Waveline 233 Waveguide Elbow 90 Deg. H plane WR-284, US $65.00 – Picture 0

Waveline 233 Waveguide Elbow 90 Deg. H Plane Wr-284

US $65.00

  • Salem, New Hampshire, United States
  • Jul 8th
Open on mobile:
QR code
The 90 degree elbows are constructed with precision MIL specification waveguide accurately formed to a constant radius in H planes.  Internal dimensions are carefully maintained.  VSWR is 1.10 maximum over the full waveguide frequency range.  Finish is instrument gray enamel.Model # 233 Waveguide size WR-284 Frequency Range GHz 2.60 to 3.95 Inches A : 5.50 Inches Radius: 3.50
“Used excellent condition”
Model 233
Brand Waveline Inc
MPN WR-284
Frequency Range 2.60 to 3.95
