Wavetek 2520A – 0.2 to 2200 MHz Synthesized Signal Generator Opt XP (Hi Power), US $1400 – Picture 0
Wavetek 2520A – 0.2 to 2200 MHz Synthesized Signal Generator Opt XP (Hi Power), US $1400 – Picture 0

Wavetek 2520a – 0.2 To 2200 Mhz Synthesized Signal Generator Opt Xp (hi Power)

US $1400

  • Lachine, QC, Canada
  • May 26th
Open on mobile:
QR code
WAVETEK 2520A – 0.2 to 2200 MHz Synthesized Signal Generator Opt XP (Hi Power): 23 dBm These units have 1 options install. Opt XP: Output Power: 23dBm Features: -         64 front panel stored settings -         keypad or spin knob control -         AutoCal® of frequency and output level -         GPIB and pulse modulation options           -    200 KHz low end/10 Hz MODULATION:   Types: AM, FM, Std. Internal Source: 400 Hz, 1 kHz External Source: AM Frequency Response (0 to 50%): DC to 15 kHz (typical to 20kHz) AM Resolution: 0.1% AM Accuracy: ±(1% F.S. +5% of setting) FM Rate: 20 Hz to 100 kHz FM Resolution: Freq < 1000 MHz 10 Hz (dev. < 10 kHz) 100 Hz (dev. < 100 kHz) 1 kHz (dev. < 1 MHz) Freq > 1100 MHz (2520) 20 Hz (dev. < 10 kHz) 200 Hz (dev. < 100 kHz) 2 kHz (dev. < 1 MHz) FM Accuracy: ±6% at internal rate (typ ±3%) REVERSE POWER PROTECTION: Max. Reverse RF Power: 50 watts Specifications: FREQUENCY Range: 0.2 to 2200 MHz Resolution: 10 Hz < 1100 MHz; 20 Hz > 1100 MHz RF OUTPUT Impedance: 50 ohms Output Connector: Type "N" Output Level Range: -137 to +13 dBm Output Resolution: 0.1 dB Level Accuracy: ±1.5 dB; >37 dBm Flatness: ±1.2 dB (typically ±0.7 dB) SPECTRAL PURITY Harmonics: <-27 dBc <0.4 MHz <-30 dBc <1100 MHz <-25 dBc >1100 MHz PHASE NOISE AT 500 MHz 10 kHz Offset: <-117 typical dBc/Hz 20 kHz Offset: Typ <-123 dBc/Hz RESIDUAL AM: <-65 dBc These units were recently removed from working bench test. These units Pass the Self-Test. The Screen is bright is very easy to read. These units are in good condition. If you have questions, you can email us.
