Wavetek 296 50 MS/s Synthesized Multichannel Arbitrary Waveform Generator, US $590 – Picture 0
Wavetek 296 50 MS/s Synthesized Multichannel Arbitrary Waveform Generator, US $590 – Picture 0

Wavetek 296 50 Ms/s Synthesized Multichannel Arbitrary Waveform Generator

US $590

  • Lake Forest, California, United States
  • Jun 3rd
Open on mobile:
QR code
Wavetek 296 50 MS/s Synthesized Multichannel Arbitrary Waveform Generator With Calibration and 90 day warranty Used but good condition. Satisfaction Guaranteed, 7-day warranty Included.  Calibration available upon request at additional charge. For International sales, please contact us for a shipping quote. (image shown is not necessarily representative of exact product) Product Description The Wavetek 296 combines sophisticated performance with ease of use in a way previously not available in arbitrary waveform generators. The Wavetek 296 includes advanced waveform sequencing capability up to 4,096 waveform segments for complex waveform generation. It also provides a 16 bit digital output on each channel. It can contain up to four separate channels. When run independently, each channel is essentially a stand-alone arbitrary waveform generator. When in master/slave mode, phase relationships between channels can be set by the user. Each channel outputs 15 Vp-p (into 50 W load) at 50 MS/s sampling frequency maximum or can output 100 volts peak-to-peak when Option 007 is installed (please consult your sales representative for availability). Each channel has a high-speed clock output that runs at a maximum of 100 MHz. Arbitrary waveforms can be created and stored to nonvolatile RAM or on the standard MS-DOS compatible 3.5-inch, high-density disk drive. In addition, ten commonly used synthesized functions are built in. Specifications     Up to 4 Independent Channels     10 Standard Functions (sine to 20 MHz, square to 25 MHz)     Up to 50 MS/s Sampling with 12-Bit Vertical Resolution     Waveform Sequencing of up to 4,096 Segments     Frequency Control of Individual Sequence Segments     16-Bit Digital Output to 50 MS/s     Optional 100 Vpp Output     Versatile Interchannel Triggering, Summing and Phase Control     Frequency Sweep     Amplitude and Suppressed Carrier Modulation     Graphical User Interface     Front Panel Waveform Creation/Editing Tools     Floppy Disk Drive     GPIB and RS-232 Interfaces     Compatible with Waveform DSP     SCPI Compatible
