Wavetek 9100 Universal Calibrator.

US $7,500.00

  • Albany, Oregon, United States
  • Jan 29th
Open on mobile:
QR code
WAVETEK 9100 UNIVERSAL CALIBRATOR The Wavetek 9100 is a multifunction calibrator with a breadth and depth of outputs never before available from a single calibration source. In addition to DC and AC voltage to 1050V, variable Resistance to 400MU and DC and AC current to 20A (1000A via the optional current coils), the 9100 delivers continuously variable capacitance values to 40mF and conductance values to 2.5 milliSiemens. It also generates digitally synthesized and phase-locked sine, square, triangle, impulse and trapezoidal waveforms, variable amplitude pulses to 10 MHz, pulse widths to 2 seconds, and duty cycles between 0.05% and 99.95%. Wavetek 9100 Features: DC Voltage: Zero to ± 1050V AC Voltage: Zero to 1050V 10Hz to 100kHz DC Current: Zero to ±20A (Up to 1000A via current coil) AC Current: Zero to 20A (Up to 1000A via current coil) 10Hz-30kHz DC Power: 1mW to 20kW (Up to 1MW via current coil) AC Power: 1mW/mVAR to 20kW/kVAR (Up to 1MW/MVAR via current coil) Resistance: Zero to 400M Ohms Conductance: 2.5nS to 2.5mS Capacitance: 500pF to 40 mF Frequency: 0.5Hz to 10MHz This calibrator is in very good condition. It was last calibrated by Fluke in 2011, and was never used. So, you are getting this calibrator like it has a fresh Z-540 calibration. It does have a small crack on the left side of the front bezel, which has no affect on the operation or the display reading. Display is clear and bright. I did a verification test and all functional are operational. Accessories: Comes with set of leads, Set of Manuals (CD), Power Cord, and 14 day warranty. Shipping: Customer pays for actual shipping charges only. Any questions, please contact me. Also, please visit my store for any other equipment you may need. Thank You.
