Wavetek Acterna 5073 Wdm Optical Spectrum Network Analyzer 4 Mts 5100e 5200 Osa

US $895.00

Toledo, Ohio, United States
Jun 9th

Open on mobile:
QR code

Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: Wavetek 5073 WDM Analyser Module (BC# 17618) BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! Wavetek 5073 WDM Optical Spectrum & Network Analyzer Module Works With MTS-5100e & MTS-5200e Series OTDR Mainframes (MTS-5100e & MTS-5200e Mainframes Not Included In Sale!) The 5073 WDM module tests all the parameters necessary for maintenance of the DWDM network, including channel wavelength, frequency, channel spacing, power and optical signal to noise ratio (OSNR) Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 90 Day Exchange Warranty Wavetek 5073 WDM Module for C+L Band Features: Maintenance of C+L band (1525-1610nm) Up to 256 channels High wavelength accuracy No moving parts Enables OTDR and WDM testing in a single unit Up to 16 hours of operation Comprehensive user interface with one button testing Automatic channel detection and measurement The 5073 WDM plug-in module for the MTS 5100e/5200e family is a cost-effective solution for DWDM network maintenance in the C+L band (1525-1610nm). Comprehensive DWDM test The 5073 WDM module tests all the parameters necessary for maintenance of the DWDM network, including channel wavelength, frequency, channel spacing, power and optical signal to noise ratio (OSNR). Fast Acquisition and Analysis of DWDM Data « One button testing » means that 5073 WDM module performs all data acquisition and analysis with a single key-stroke. Parameters are presented over the full spectrum in wavelength and tabular formats, with a handy zoom function for more detailed analysis. Efficient Testing of High Fiber Counts To speed multiple fiber testing, 5073 WDM module features a macro function which can be user-programmed for automatic, successive measurement and analysis of large quantities of fibers. All the test modules in the MTS 5100e/5200e range allow « multi-tasking » for continued data acquisition while test parameters are set-up or results are printed. Advanced Modularity for the Field The MTS 5100e and 5200e are the ideal platforms for outside plant applications. Equipped with the 5073 WDM module, the MTSe is the perfect tool to maintain DWDM networks. Optimized for field use (lightweight with 3.5 kg, up to 16 hours of operation and with no moving parts), it provides all test parameters to analyze the quality of a DWDM network of up to 10 Ghz channel spacing. The WDM module is a new member of the family of MTSe modules, which include the essential tools for installation and maintenance of fiber optic links : OTDR, loss test set, Visual Fault Locator, talk set. Switching between functions takes only seconds, enabling the user to concentrate on measurement or results, rather than on instrument configuration. The MTSe platform is the only unit able to measure fiber optic parameters and WDM parameters within seconds, without the need to swap modules. Ready for Comprehensive Measurements and Statistical Analysis Configurable user interface The intuitive interface of the 5073 WDM module is highly user-configurable. Measurement units (nm or THz), SNR measurement set-up (left, right, left and right or custom) and grid (ITU or manual) are user-specified, and channels can be sorted by number, wavelength, power level or OSNR. Comprehensive measurements In addition to the main DWDM parameters which are measured automatically at the touch of a button, the 5073 WDM module can be used to compare total or partial optical power, level, wavelength, gain tilt and gain slope between two points. An innovative overlay function makes it easy to compare stored waveforms. Statistical Analysis The 5073 WDM module can be used for statistical analysis of the results of longterm monitoring. User-defined limits identify potential problems, for effective preventative maintenance of the network. File Management The 5073 WDM module has a comprehensive file management system, which allows successive files to be named and stored automatically, semi-automatically or manually. Automatic Maintenance Testing During maintenance operation of a DWDM network, it is essential to have accurate knowledge of the optical spectrum, primarily the individual channel power and wavelengths, at critical points along the optical link : end terminals, optical amplifiers, add/drop nodes, cross connects and any other locations. Measuring the performance enables the operator to identify degradation or failure. Complete Channel Analysis The MTSe automatically provides all the necessary parameters to maintain a DWDM network. By pressing a single key, the MTSe performs an acquisition followed immediately by an analysis of the existing channels. This enables the user to rapidly detect if a channel is lower in power or missing, or if the entire network has been degraded. Measurement parameters are presented over the full spectrum in a waveform, as well as in a tabular display. For easy analysis, a simple 'click' on the table brings the relevant waveform center screen, with a zoom function available for more detailed analysis. The MTSe automatically provides the following measurements for each channel: Number Wavelength Spacing Power level SNR Ratio between channel power level and composite power level Composite power is also displayed, and slope gain and tilt gain are provided to indicate the quality of the amplified system. Specifications Wavelength parameters Range 1525 to 1610 nm Display resolution 1:00 PM Accuracy +/- 10 pm Minimum channel spacing 0.08 nm (10 Ghz) Power level parameters Display range -90 to +30 dBm (+20 dBm Composite power, +10 dBm channel power) Display resolution 0.01 dB Accuracy +/-0.5 dB (-30 dBm, 1550 nm) Linearity (typical) +/- 0.1 dB (-40 to +10 dBm) Optical Rejection Ratio 40/34 (0.8 / 0.4 nm) Polarization dependance +/-0.2 dB Optical return loss >35 dB Sweep time 1.5 s (real time) Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. UPS Ground United States USD 0.00 USPS Express Mail International (EMS) Worldwide USD 0.00 We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Manage all your eBay listings with Kyozou eBay Listing Software

Condition:	Seller refurbished: An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details. ...	Brand	Wavetek
MPN	5073 WDM
Model	5073 WDM
