Wavetek / Rockland 852 Dual HP/LP Filter 0.01Hz - 111kHz, US $2000 – Picture 0
Wavetek / Rockland 852 Dual HP/LP Filter 0.01Hz - 111kHz, US $2000 – Picture 0

Wavetek / Rockland 852 Dual Hp/lp Filter 0.01hz - 111khz

US $2000

  • East Providence, Rhode Island, United States
  • Nov 4th
Open on mobile:
QR code
Wavetek / Rockland 852 Dual HP/LP Filter 0.01Hz - 111kHz Description: Input Characteristics: Circuit:  single-ended, diode protected Impedance:  1 M ohm shunted to 50 pF; 75 pF in 20 dB gain. Full-Scale Signal at 0 dB Gain:  ±10 V(7.1 Vrms), DC to 300 kHz, decreasing to ±4 V(2.8 Vrms) at 1 MHz (divide these by 10 at 20 dB gain). Absolute Max Input:  ±100 V Max. DC Component (High Pass): ±100 V, 0 dB gain. ±10V, 20 dB gain. Output Characteristics: Circuits: Single-ended Short-circuit protected May be DC isolated from power ground by rear panel switch Impedance: 50 ohms Full-Scale Signal:  ±10 V(7.1 Vrms), DC to 300 kHz, decreasing to ±4 V(2.8 Vrms) at 1 MHz (RL > or + 5 k ohms, ±15 mA max. current 0.01 Hz to 111 kHz Range 3 digits Resolution Butterworth and Flat Delay Responses Functions: Low Pass, High Pass, Band Pass, Band Reject, Notch. Frequency Range and Resolution:  Three 11-position switches and one 4-position multiplier Attenuation Rate per Channel Flat Amplitude (Butterworth) Response Passband Gain: Low Pass: 0 dB/ 20 dB, ± 0.5 dB High Pass:  0 dB/ 20 dB, ± 0.5 dB (± 1 dB in x10 k Multiplier position): -3 d\b at approx. 1 MHz Attenuation at Cutoff: 3 dB Maximum Stopband Attenuation: 80 dB min on x10 K and x1 K ranges for fin <or = 400 kHz. 70 dB min on x100 and x10 ranges for f in <or = 300 kHz. Phase Match Between Channels (typical):  2° or 2%, whichever is greater. Flat Delay Response Low Pass Delay (typical):  1/fc seconds    Attenuation Cutoff:  Approx. 17 dB Includes option 01 The item is in good condition, tested and working. Shipping Weight (lbs.): 17 Shipping Dimensions (in.): 24 x 18 x 10 Click Here for Terms and Conditions of Sale
