Wej-it Ankr-tite Ccat Wedge Anchor For Uncracked Concrete, Carbon Steel, Zinc

US $140

USA, United States
Jun 11th

Open on mobile:
QR code

Wej-It Ankr-TITE CCAT Wedge Anchor for Uncracked Concrete, Carbon Steel, Zinc Plated Finish, Meets QQZ-325 Type II Class 3 Specifications, 3/8" Diameter, 7" Length, 4-1/2" Threaded Length, 3/8"-16 Threads (Pack Of 50) Item Description Wedge anchor provides a secure hold in uncracked concrete and solid masonry Anchor consists of a zinc-plated carbon steel body, a carbon steel washer and nut, and a 316 stainless steel clip that expands to secure the anchor in place as the nut is tightened Meets Fed. Spec. QQZ-325 Type II Class 3 and meets ICC-ES Report Number ESR-2777 Category 1 design criteria Round clip evenly distributes force within the mounting surface, enabling high load capacity Line marking and length identification code stamped on the anchor's visible end for post-installation inspection SPECIFICATIONS The Wej-It Ankr-TITE CCAT wedge anchor provides a secure hold in uncracked concrete and solid masonry up to 3/8" thick, and meets Federal Specification QQZ-325 Type II Class 3 and ICC-ES Report Number ESR-2777 Category 1 design criteria. The anchor consists of a carbon steel body that is zinc-plated for corrosion resistance, a carbon steel washer and nut, and a corrosion-resistant 316 stainless steel clip. It must be installed into a drilled hole with a diameter equal to that of the anchor. The washer lies flush against the mounting surface when the anchor is inserted into the hole, and the nut tightens with a wrench to draw the threaded portion of the anchor up, causing the clip to expand and secure the anchor in place. The clip is round for even distribution of force within the mounting surface for high load capacity. A line marking and length identification code are stamped on the anchor's visible end for post-installation inspection, and the dog point on the opposite end prevents damage during installation. A safety shoulder above the clip provides support when the anchor is under severe strain. Specifications Ultimate Tensile Strength Anchor Diameter Effective Embedment Depth 2,500-psi Uncracked Concrete 2,500-psi Cracked Concrete 3/8" 2" Not Available Not Applicable 1/2" 2-3/4" 4,737 lb. 2,616 lb. 1/2" 5" 5,115 lb. 3,584 lb. 5/8" 3-3/8" 7,082 lb. 5,144 lb. 5/8" 5-3/4" 12,734 lb. 6,645 lb. 3/4" 7" 16,607 lb. 11,849 lb. Ultimate Shear Strength for Seismic Applications Anchor Diameter Effective Embedment Depth 2,500-psi Cracked Concrete 3/8" 2" Not Applicable 1/2" 2-3/4" 3,239 lb. 1/2" 5" 6,476 lb. 5/8" 3-3/8" 5,055 lb. 5/8" 5-3/4" 8,154 lb. 3/4" 3-3/4" 8,504 lb. 3/4" 7" 11,957 lb. Warning: Use one-fourth or less of listed maximum values for safe working loads (as required by local regulations). For more information, see the manufacturer's literature. Anchors provide reinforcement to fasteners installed in materials that are considered brittle or have insufficient hold such as drywall, concrete, brick, and stone. Anchors provide support through methods such as expansion from within or behind the substrate, or insertion of adhesive compounds into drilled holes. Wej-It Fastening Systems manufactures mechanical and adhesive fasteners for use in concrete and drywall. The company, founded more than 60 years ago, is headquartered in Norwalk, CT. ADDITIONAL FEATURES Manufacturer: Wej-It Shipping Weight: 1050 Product Dimensions: Width: 4.70 Length: 8.10 Height: 2.90 SHIPPING INFORMATION ● Our stock all ships from our US-based warehouses. ● Shipped via USPS or UPS (depending on location and package weight) ● Unless stated otherwise, all orders will ship within 24 hours of your payment being processed. Check our feedback to see the great reviews of FAST shipping we offer. ● Shipping is always FREE! RETURN & REFUND POLICY ● We offer a 30 day return/exchange policy for our products. ● You can choose refund or exchange if you are dissatisfied for any reason with your product. ● When returning an item, it must be in all of the original packaging and include all of the original accessories or items that came with it. The item and package should be in original and perfect condition. ● You will be required to cover shipping on the return of defective items. ● All returns MUST be done within 30 days of date of purchase. Please note that we cannot give refunds or replacements after the 30 day limit has expired. ● When sending in a return, please note that it can take up to 7 business days for the return to be processed. We do our best to process as quickly as possible. ● Buyers outside the U.S.A please note - ALL of our electrical appliances sold in our store are 110-120V. ● Return policy for buyers outside the U.S.A - We offer to return the items within 30 days. The BUYER will ship the item at his own cost. We are extremely fair, and in the rare event of something out of the ordinary happening with our products or shipping, we will gladly work with you to find a solution. ABOUT VIVIAN STORE Since 2005 we have been available to online customers, offering a variety of brand new products at great prices. All of our products ship directly from our different warehouses across the United States so you get your items quickly and in perfect condition. We know how important it is for you to get what you ordered and get it fast. Our products are a 100% authentic and brand new. We work with the biggest suppliers of high quality products to bring you only the best items. It is very important to us that we put our customers first and you will see this reflected in every transaction with us. We consider it a top priority that our customers are happy and in the rare event that they are not, we do everything we can to fix the situation. No customer will walk away from our store unhappy. If there's a problem, just let us know and we fix it. We guarantee you only the best experience when shopping with us! Please see our other items Automotive Baby Camera & Photo Clothing Electronics Health & Personal Care Home & Kitchen Home Improvement Kitchen & Dining Office Products Shoes Sports & Outdoors Toys & Games Feedback Profile Other Auctions
