Welding Inspection Scale Small Height Gauge Hi-lo Dedicated Internal Welding Ry6

US $19.51

  • Shenzhen, China
  • Sep 4th
Open on mobile:
QR code
Welding Inspection Scale Small Height Gauge Hi-Lo Dedicated Internal Welding RY6 Root Weld spacing gauge:Easy operation determines rootweld spacing 1. Unlock the retaining screw and insert the gauge interior alignment stops between the two pieces of pipe to be fitted 2. Insert the leg with the longer taper into the root gap until it makes contact with both slides of the gap. 3. Re-lock the retaining screw, remove the gauge and read it 4. The scale is calibrated in fractional dimensions from 1/32 to 3/16 in 1/16 inch increments, the read-out you receive represents the amount of rootweld gap DIY Supplies:Metalworking Model Number:2924043 Internal Hi-Lo gauge: 4 steps check internal alignment You can check the internal alignment of you fit-up ly with the Hi-Lo gauge 1. Unlock the retaining screw. press the gauge legs beyond the barrel 2. Insert the legs (wired) into the root gap space or the two pieces of pipe to be fitted, turn the gauge 90°, being careful to apply a constant back pressure to the barrel 3. Hold the gauge as square as possible with the fitting to obtain an accurate reading. lock the retaining screw. reverse the 90° turn and remove the gauge, you're now ready to read the increment opposite the red line 4. When the red line aligns with the 1/32 increment line you have a good internal alignment and fit-up. misalignment can be determined from the zero line by increment marking of 1/16 inch Color: black, silver Material: Stainless steel Package Contents: 1 * Wedling Single Purpose Gauge 1 * Portable leather bag 1 * User manual
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
MPN Does Not Apply
Bundle Description No
Brand Unbrand
Modified Item NO
Marke SODIAL
Modification Description No
Hersteller SODIAL
Gage Type Regular Type
Country/Region of Manufacture China
Custom Bundle Regular
UPC 194031005049
ISBN 194031005049
EAN 194031005049

Directions
