Whelen Siren And Light Controller

US $330

Charleston, West Virginia, United States
Oct 26th

Open on mobile:
QR code

The Whelen 295SLSA6 Siren & Light Controller is a rugged, compact, self-contained unit, that is totally plug-in compatible with the 295HFSA6 unit that it replaces. This siren is designed for under-dash or console mounting. The Master Power switch is programmable for On/Off operation of the siren only, or siren and switch functions. The four position slide switch activates up to three 20 amp circuits. The six push buttons are programmable momentary switches that activate six 15 amp circuits for auxiliary control of lightbar functions or auxiliary lighting. All seven positions of the rotary switch serve a primary function plus programmable override tones. Primary functions are: Radio Repeat, Manual 1, Manual 2, Hands-Free, Tone 1, Tone 2, Tone 3. There are 16 Scan-Lock siren tones to choose from. This model comes with Si-Test, a silent self-diagnostic feature which provides real time indication of proper siren/speaker operation. Two different diagnostic tests include: Continuous dynamic testing during normal siren operations and silent testing while in "Radio" mode with the "manual" button depressed. The two speaker LEDs serve as Si-Test's diagnostic indicators. This siren supports one or two 100 watt speakers. Comes with hard-wired microphone. An adjustable bail bracket allows mounting in a variety of positions. Meets SAE J1849 and California Title 13 requirements. Features: Master Power switch is programmable for On/Off operation of the siren only, or siren & switch functions. Four position slide switch activates up to three 20 amp circuits. Six push buttons are programmable momentary switches that activate six 15 amp circuits. Six push buttons can be programmed for Push On/Push Off, Momentary, Flashing or Timed Output. 7 rotary switch functions: Radio Repeat, Manual 1, Manual 2, Hands-Free, Tone 1, Tone 2 and Tone 3. All seven positions of the rotary switch serve a primary function plus programmable override tones. There are 16 Scan-Lock siren tones to choose from. Vehicle horn button activated "Hands-Free" operation. Si-Test, silent siren/speaker diagnostic feature. PA volume control with PTT siren override. Adjustable Radio repeat volume on front panel. "Siren in Use" icon driver. "Siren Disable" function when vehicle is parked or door is open. Ability to easily copy all siren programming to another 295SLSA6 siren. LED backlighting. Over/under voltage protection. Short circuit protection. Input polarity protection. Sold As Is No International Shipping Specifications: Voltage: 12.8 VDC (+/-20%) Polarity Protection: Diode/Fuse Amps Draw: 16 Amps Max. Weight: 4.6 Lbs. Size: 3-5/16" H x 6" W x 7" D.
