Wilbur Curtis G4 - 1 Gallon Twin Brewer Commercial Coffee Brewer

US $1,550.00

Los Angeles, California, United States
Jun 22nd

Open on mobile:
QR code

Model: G4TP1T10A3100 ** Dispenser sold separately ** *Refurbished* FEATURES AT A GLANCE Generation Four (G4) Digital Control Module – Large, 4.3” touch screen, icon-driven interface streamlines operation. Stainless steel ThermoPro® vacuum-sealed servers keep coffee fresh and flavorful. Built-In Self Diagnostic System – Includes real-time feedback of the brewing process and energy saving mode. Gold Cup Series – Digital control module provides precise control over all aspects of brewing: time, temperature, volume plus specialty coffee needs from pre-infusion, pulse-brewing, and water bypass. Pre-Set, One-Touch Global Recipes – Based on coffee type, grind and weight. Single unit is field selectable for one, two or three batch brewing. Centrally located hot waterspout for instant hot beverages and other hot water needs. DIMENSIONS Height (in.) 24.980” Width (in.) 20.070” Depth (in.) 20.750” ELECTRICAL Phase 1 Volts 220 Amps 23.0/34.5 Heat Configuration 3 x 2500W Wire 3W+G Watts 5100/7600 Hertz 50/60 WATER Connector 3/8” Flare Pressure 20-90 psi Min. Flow Rate 2.0 GPM Tank Volume 5.2 Gal SHIPPING Ship Height (in.): 30.00” Ship Width (in): 17.00” Ship Depth (in): 26.00” Ship Weight: 75.00 lbs Ship Cube: 10.8 cuft GENERAL Certification: UL/ NSF Warning: Proposition 65 Warning — Applies to the State of California Only. Learn More > Installation Requirements A secure surface capable of supporting the weight of the appliance. For units without an attached cord set: Appropriately sized, UL listed, grounding type power cable to meet the electrical specifications for the appliance. If you have questions about the correct cable size and length, consult a qualified installer. If the unit will be hard wired to a junction box, the power cable must be long enough so that it can be moved for cleaning underneath. A grounded electrical connection to an electrical circuit that meets the electrical specifications of the appliance (see SPECIFICATIONS). The circuit must be protected by the appropriate sized circuit breaker. If you are not certain that the existing circuit meets the requirements for your unit, consult a licensed electrician. A water filtration system is required to maintain trouble-free operation. Potable water supply line connection from the water filter capable of supplying the minimum flow rate required by the specifications. The water supply line must be able to connect to the flare fitting on the back of the unit. See the SPECIFICATIONS section for the correct size. The water line should also be capable of being controlled by a shut off valve. Do not connect the water line to a saddle or needle valve. Quote Sku: 6298 Coffee Machine Depot USA StoreOur MachinesReviewsContact UsAdd to Favorites Wilbur Curtis G4 - 1 Gallon Twin Brewer Commercial Coffee Brewer Model: G4TP1T10A3100 ** Dispenser sold separately ** *Refurbished* FEATURES AT A GLANCE Generation Four (G4) Digital Control Module – Large, 4.3” touch screen, icon-driven interface streamlines operation. Stainless steel ThermoPro® vacuum-sealed servers keep coffee fresh and flavorful. Built-In Self Diagnostic System – Includes real-time feedback of the brewing process and energy saving mode. Gold Cup Series – Digital control module provides precise control over all aspects of brewing: time, temperature, volume plus specialty coffee needs from pre-infusion, pulse-brewing, and water bypass. Pre-Set, One-Touch Global Recipes – Based on coffee type, grind and weight. Single unit is field selectable for one, two or three batch brewing. Centrally located hot waterspout for instant hot beverages and other hot water needs. DIMENSIONS Height (in.) 24.980” Width (in.) 20.070” Depth (in.) 20.750” ELECTRICAL Phase 1 Volts 220 Amps 23.0/34.5 Heat Configuration 3 x 2500W Wire 3W+G Watts 5100/7600 Hertz 50/60 WATER Connector 3/8” Flare Pressure 20-90 psi Min. Flow Rate 2.0 GPM Tank Volume 5.2 Gal SHIPPING Ship Height (in.): 30.00” Ship Width (in): 17.00” Ship Depth (in): 26.00” Ship Weight: 75.00 lbs Ship Cube: 10.8 cuft GENERAL Certification: UL/ NSF Warning: Proposition 65 Warning — Applies to the State of California Only. Learn More > Installation Requirements A secure surface capable of supporting the weight of the appliance. For units without an attached cord set: Appropriately sized, UL listed, grounding type power cable to meet the electrical specifications for the appliance. If you have questions about the correct cable size and length, consult a qualified installer. If the unit will be hard wired to a junction box, the power cable must be long enough so that it can be moved for cleaning underneath. A grounded electrical connection to an electrical circuit that meets the electrical specifications of the appliance (see SPECIFICATIONS). The circuit must be protected by the appropriate sized circuit breaker. If you are not certain that the existing circuit meets the requirements for your unit, consult a licensed electrician. A water filtration system is required to maintain trouble-free operation. Potable water supply line connection from the water filter capable of supplying the minimum flow rate required by the specifications. The water supply line must be able to connect to the flare fitting on the back of the unit. See the SPECIFICATIONS section for the correct size. The water line should also be capable of being controlled by a shut off valve. Do not connect the water line to a saddle or needle valve. Quote Sku: 6298 COFFEE MACHINE DEPOT USA Contact us for more information on our Equipment! WE HAVE OVER 400 MACHINES & GRINDERS IN STOCK WITH 100 ADDITIONAL MACHINES ARRIVING EVERY 4 WEEKS. PLEASE CONTACT US FOR MORE INFORMATION REGARDING OUR STOCK OF: | La Marzocco | Synesso | Faema | Kees Van Der Westen | San Marino | Astoria | Wega | La Nuova Era | | Nuova Simonelli | Fiamma | Brugnetti | Mazzer | Fiorenzato | ECM | Rocket | Orchestrale | La Cimbali | | Rancilio | Mahlkoneig | Jura | Anfim | Boema | Ciao Bella | Compak | Dalla Corte | Elektra | Expobar | | La San Marco | Coffee Carts | Quamar | SAB | Macap | Bunn | Eureka | Victoria Arduino | Ditting | Payment Shipping Returns About US Installation Guide Terms of Sale Payment Payment Shipping Returns About US Installation Guide Terms of Sale Payment We accept PayPal and all major credit cards. All in state residents of California will be charged state and/or local sales tax at the time of checkout. An unpaid claim case will be opened on eBay after an item goes unpaid for two (2) days. Be sure to confirm your PayPal shipping address prior to payment. We do not allow changes to an address after payment. We only ship to the confirmed address registered to your PayPal account. Please contact us with questions. Payment Shipping Returns About US Installation Guide Terms of Sale Shipping Payment Shipping Returns About US Installation Guide Terms of Sale Shipping Important Information about your Freight Delivery. Your order will be delivered curbside on a full size 18 wheeler. You are responsible for: Removing the shipment from the truck Bringing it into your location Noting damaged or missing items on the carrier's delivery receipt If you do not make note of these issues in any way on the delivery receipt, we cannot guarantee any compensation for damaged or missing items. By signing your name on the delivery receipt without declaring these exceptions, you are stating that you have received your shipment in acceptable condition. Upon inspection, if any piece of the shipment is damaged or missing: Note it clearly on the delivery receipt before signing (ie - "missing 3 pieces", "holes in packaging", "multiple dents on the espresso machine", etc). Keep your copy of the delivery receipt Contact us within 1 business day Keep the damaged packing materials for inspection Take pictures of the damaged items and packaging Additional Shipping Notes Please see specific products for more detail on lead times. We reserve the right to choose the most efficient carrier for your order at the time of shipment. Estimated arrival dates are not guaranteed. Weather delays and other unforeseen circumstances may impact delivery time. Most items ship within one to five business days, but some may take longer. You will receive order updates with tracking information as they become available. Rest assured, every item is thoroughly padded to protect against bumpy travel. Some items require a signature for delivery. Shipping to a residential address? Please contact us for residential surcharges. Looking to ship internationally? Contact us via email or phone. We offer free local pick-up - contact us for details. For other shipping-related questions, please contact us directly. Packages DO NOT ship from our distribution center on the following holidays: New Year's Eve Day New Year's Day Martin Luther King Jr. Day President's Day Memorial Day 4th of July Labor Day Columbus Day Thanksgiving The Friday after Thanksgiving Christmas Eve Day Christmas Day Contact us with any questions. Payment Shipping Returns About US Installation Guide Terms of Sale Returns Payment Shipping Returns About US Installation Guide Terms of Sale Returns RETURN POLICY: Any returns must be initiated within 30 days of receipt of the item by the buyer. Returns will only be accepted if the item is unused, in its original condition, and in its original packaging. All returns are subject to a 20% re-stocking fee. Buyer is responsible for return shipping, as well as any fees or additional costs. Payment Shipping Returns About US Installation Guide Terms of Sale About US Payment Shipping Returns About US Installation Guide Terms of Sale About US Coffee Machine Depot is the number one dealer of New and Refurbished commercial espresso equipment in the United States. Buy. Sell. Simple. We specialize in selling new and refurbished commercial espresso machines, coffee brewers, tea brewers, grinders, water filtration systems and coffee accessories. Our goal is to provide our customers with quality products at a competitive price. Why buy with us? We care about what you need, and if you don't know what that is we can help you figure it out. If you are starting a new business, looking to add to the services your bisness already provides, or simply looking to make a quality cup of coffee at home, we are here for you! Not the machine you want? Unsure on what machine to buy? We have hundreds of machines in stock, so give us a call today if there is a specific machine you want. We have years of experience in the coffee industry, so if you are new to the industry, and aren’t sure what machine to buy give us a call to schedule an appointment at our showroom. Not local to Los Angeles, or even California? Are you located outside the United States? Are you an overseas buyer? You can email or call us anytime; we have assisted many businesses around the world set up for their new coffee ventures! We tailor make packages to suit each customer’s requirements and budgets. ARE YOU A ROASTER? Inquire now about supplying your clients with our equipment for excellent package pricing. We can also help organize competitive finance rates. We can help you. We deliver nationwide, and freight internationally regularly. Payment Shipping Returns About US Installation Guide Terms of Sale Installation Guide Payment Shipping Returns About US Installation Guide Terms of Sale Installation Guide Installation Guide for Espresso Machine & Grinder The below information is a great reference and should be used as a guide when installing a commercial espresso machine and grinder. Commercial Espresso Machine We suggest a dry, well ventilated work bench, this should be approx 32” - 45” high, with 6” clear space around the machine to allow for cleaning and maintaining the machine. Please do not forget to allocate an area for your grinder which is usually on the right side for right handed Baristas. Under the machine you should dedicate an open space of approx 17 x 17 x 12 (In w x h x d) for your filter and an external motor and pump (This is for machines that have external pumps) Rancilio do not have external pumps. In order to connect of these up it is advisable to have a 3” hole drilled your bench, for water pipes and electricity cables. This hole should be set for the middle of the machine. Water You need to engage a licensed plumber to install a cold water outlet which is easily accessible. The water that is fed into the espresso machine must remain at 2 – 3 GPG otherwise most manufacturers will void your warranty. Most espresso machine inlet hoses terminate in a 3/8? female fitting which will connect directly to a filter. We recommend that the water supply enter low on either side and near to the back surface within 40” of the machine. Power Supply Always use a licensed electrical contractor to connect your espresso machine and grinder. Your espresso machine will require a 220 - 240 Volt single-phase supply with the specific current protection ratings as per machine specifications. Espresso machines generally have a 40” lead coming out from the rear left side. Therefore the GPO should be located near the left side. Many caf owners have a power supply installed below the machine in the service area and therefore run the cable from the machine through the hole in the bench for water and drainage. IMPORTANTLY if your power or isolating switches are located in areas affected by water it is compulsory to install weatherproof power switches. The majority of commercial espresso machines will generally require a minimum 15A – 30A power supply. Some multi boiler 3 – 4 group machines may require a 40amp outlet to be installed. Single group domestic (home) machines require 10A and 110v outlet. In these circumstances, we recommend having a licensed electrician install a dedicated circuit for your espresso machine. For your commercial grinder these can either run on 110V or 240V and be anywhere between 10A – 20A. Please note that it is not un common for a commercial coffee machine direct from the factory to be delivered without a plug and therefore it would be the responsibility of your licensed electrician to install and supply a suitable plug. Outlet Drain/Waste A drain-pipe with trap is required which will allow for direct drainage. 99% of the time a drain hose from machine to trap will be provided with your machine and these are usually 30” – 40”. Payment Shipping Returns About US Installation Guide Terms of Sale Terms of Sale Payment Shipping Returns About US Installation Guide Terms of Sale Terms of Sale INTRODUCTION: These terms of use (“Terms”) set forth the binding agreement between United Global Coffee Solutions, Inc. (dba “Coffee Machine Depot USA”) on behalf of itself and its affiliates and subsidiaries (collectively “Company”) and you, and describe the rules and conditions by which you agree to upon purchasing a product or service from Company. These rules and conditions also govern your use of any website, Facebook site, mobile app, or other social media channel owned and/or operated by Company now or in the future (collectively and individually, the “Site”). The products and services for sale and the Site itself are owned and controlled by the Company. Your purchase of a product or service and/or your use of the Site constitutes your agreement to these Terms. By purchasing a product or service and/or using the Site, you agree to be bound by these Terms and any additional terms that may be posted for any specific Company Site. If you do not agree to these Terms, do not purchase any products or services, or use the Site. Company reserves the right to modify or change these Terms from time to time, at Company’s sole discretion, without prior notice to you. Please periodically visit this section of the Site to review the current version of these Terms. By purchasing a product or service and/or using the Site, you agree to the most current version of the Terms and any and all future changes that may be placed in effect. You also agree to comply with any additional terms which are referred to on this Site or any area within the Site. BY PURCHASING A PRODUCT OR SERVICE AND/OR USING THE SITE, YOU ACKNOWLEDGE THAT YOU HAVE READ AND UNDERSTAND THIS AGREEMENT AND AGREE TO BE BOUND BY ITS TERMS. YOU FURTHER AGREE THAT THIS AGREEMENT IS THE COMPLETE AND EXCLUSIVE STATEMENT OF THE AGREEMENT BETWEEN YOU AND COMPANY REGARDING YOUR PURCHASES AND THE SITE ITSELF. INFORMATION ABOUT ITEMS: Company uses commercially reasonable efforts to describe its products accurately. However, Company does not warrant that the product descriptions or other content of its Site are accurate, complete, reliable, current, or error-free. Company does not represent that any products sold on its Site meet certification standards for any jurisdiction. This includes, but is not limited to UL, CE, FCC, and/or NSTL certification. Through the act of purchasing products or services from the Company and/or using the Site, you represent that you understand there is a possibility the product you are purchasing might not have any electronic products testing certification. RETURN POLICY: Any returns must be initiated within 14 days of receipt of the item by the buyer. Returns will only be accepted if the item is unused, in its original condition, and in its original packaging. All returns are subject to a 20% re-stocking fee. Buyer is responsible for return shipping, as well as any other fees or additional costs. LIMITS ON LIABILITY: Company shall not be responsible for and disclaims all liability for any loss, liability, damage (whether direct, indirect or consequential), personal injury or expense of any nature whatsoever which may be suffered by you or any third party (including your company), as a result of, or which may be attributable to, directly or indirectly, your use of any product or service purchased from Company, as well as your access and use of the Site, any information contained on the Site, you or your company's personal information or material and information transmitted over Company’s system. In particular, Company shall not be liable in any way to you or to any other person, firm or corporation whatsoever for any loss, liability, damage (whether direct or consequential), personal injury or expense of any nature whatsoever arising from your use of a product or service purchased from Company. Furthermore, neither the Site owner nor any third party or data or content provider shall be liable in any way to you or to any other person, firm or corporation whatsoever for any loss, liability, damage (whether direct or consequential), personal injury or expense of any nature whatsoever arising from any delays, inaccuracies, errors in, or omission of any information or the transmission thereof, or for any actions taken in reliance thereon or occasioned thereby or by reason of non-performance or interruption, or termination thereof. WARRANTY DISCLAIMER: The products and services purchased on the Company Site, as well as the Site itself, and the materials on this site are provided ‘as is’ and without warranties of any kind, whether express or implied, unless noted otherwise. To the fullest extent permissible pursuant to applicable law, Company disclaims all warranties, express or implied, including, but not limited to, implied warranties of merchantability and fitness for a particular purpose and non-infringement. Company does not represent or warrant that the functions of products purchased from its Site or the functions contained in the Site itself will be uninterrupted or error-free, that the defects will be corrected or that this Site or the server that makes the Site available are free of viruses or other harmful components. Company does not make any warranties or representations regarding the products and services it sells, nor the use of the materials in this Site in terms of their correctness, accuracy, adequacy, usefulness, timeliness, reliability or otherwise. INDEMNIFICATION: You agree to indemnify, defend, and hold harmless Company, its officers, directors, employees, agents, licensors and suppliers from and against all losses, expenses, damages and costs, including reasonable attorney’s fees, resulting from any violation of these Terms or any activity related to a product or service you purchased from the Company, your account (including negligent or wrongful conduct) by you or any other person utilizing a product or service you purchased from Company or accessing the Site using your Internet account. LIMITS ON WEBSITE USE: Company grants you a personal, limited, non-exclusive, non-transferable, revocable license to install and use any proprietary software necessary to use the Site, including any updates and enhancements, in object code form, including on your mobile device, if necessary (the “License”). Except as otherwise expressly provided, Company grants no other express or implied rights to you in regard to the Site. The License granted to you may not be sublicensed, commercially distributed, or shared with any third party without the prior written consent of Company. Except for information, products or services clearly and specifically identified as being supplied or endorsed by Company, Company does not endorse any products or services on this Site or other sites linked to or from it. Company may add, change, or remove any content posted on this Site, including features and specifications of products described or depicted on the Site, at any time, without notice and without liability. WEBSITE COPYRIGHT: The entire content included in this Site, including but not limited to text, graphics or code is copyrighted as a collective work under the United States and other copyright laws, and is the property of Company. The collective work includes works that are licensed to Company. Copyright 2017, Coffee Machine Depot USA ALL RIGHTS RESERVED. Permission is granted to electronically copy and print hard copy portions of this Site for the sole purpose of placing an order with Company or purchasing Company’s products or services. You may display and, subject to any expressly stated restrictions or limitations relating to specific material, download or print portions of the material from the different areas of the Site solely for your own non-commercial use, or to place an order with Company or to purchase Company products. Any other use, including but not limited to the reproduction, distribution, display or transmission of the content of this Site is strictly prohibited, unless expressly authorized by Company. You further agree not to change or delete any proprietary notices from materials downloaded from the Site. TRADEMARK: All trademarks, service marks and trade names of Company used in the Site are trademarks or registered trademarks of Company. ENFORCEABILITY: Unless otherwise specified, the Site and the content thereof are displayed solely for the purpose of promoting Company and its products and services. These Terms shall be construed in accordance with the laws of the State of California, U.S.A., without regard to any conflict of law provisions. Any dispute arising under this Agreement shall be resolved exclusively by the state and/or federal courts of the State of California, U.S.A. By purchasing a product or service and/or using this Site, you agree and submit to the personal jurisdiction and venue of such courts. You agree that in the event you have or may have any alleged claim against Company or any of its vendors, contractors, licensees, or licensors, you shall pursue such claim only in your individual capacity, and you shall not agree to join or be a part of any class action, consolidated action, or similar action. You also agree that your damages are limited as set forth elsewhere in these Terms and that you are not eligible to receive, and shall not seek, attorney’s fees in relation to any claim you have or may have against Company or its vendors or licensors. TERMINATION: These Terms are applicable to you upon purchasing a product or service and/or upon your accessing the Site and/or completing the registration or shopping process. These Terms, or any part of them, may be terminated by Company without notice at any time, for any reason. The provisions relating to Copyrights, Trademark, Warranty Disclaimer, Limitation of Liability, and Indemnification, shall survive any termination. WARNING: Products sold on this site can expose you to chemicals including Acrylamide and Bisphenol A (BPA), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Listing and template services provided by inkFrog

Condition:	Seller refurbished: The item has been restored to working order by the eBay seller or a third party. This means the item was inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See seller’s listing for full details. ...	Brand	Wilbur Curtis
Water Source	Direct Connection
MPN	Does Not Apply
Country/Region of Manufacture	United States
Style	Automatic
Number of Cups	1
Color	Metallic Red & Chrome
Power	200-240V
UPC	Does not apply
