Wilcom Fs1318 Tri 1310/1490/1550nm Fiber Optic Laser Source

US $995.00

Hurst, Texas, United States
Feb 28th

Open on mobile:
QR code

FS1318 Tri 1310/1490/1550nm Laser Source Tri 1310/1490/1550nm Laser Source The FS-1318 1310/1490/1550 Laser Source is a hand-held battery powered stabilized laser source with three laser outputs. Together with Wilcom's FM-1317 power meter, this team makes the perfect combination for accurately testing singlemode FTTH cable installations including, cable attenuation, point-to-point connection verification, end-to-end testing, and system installation verification. Model FS-1318 operates at 1310nm, 1490nm , and 1550nm wavelengths with a single SC connector optical port allowing this unit to test passive optical networks (PONs) at the three main wavelengths recommended by the ITU-T (G.983.3) for use in fiber-to-the-home (FTTH), and fiber-to-the-premise (FTTP) networks.The highly efficient, stabilized output uses rear facet diode technology to compensate for short and long-term drift. The FS-1318 Laser Source features both continuous wave (CW) and modulated output modes. In CW mode the units feature extremely stable output power at 0 dBm for standard optical loss measurements. In the modulated mode, each unit provides 2kHz, 1kHz or 270Hz for fiber identification when used with Wilcom’s optical fiber identifier Models F6121A, F6121R, F6222, F6222C or the F6225. Product Description Tri- wavelength - Single Port - 1310/1490/1550nm SC/UPC Model Part Number Price Quantity FS1318 30131801 $2,500.00 Submit Choose your Wavelength 1310nm, 1490nm, or 1550nm wavelength with a single SC optical port connnector. Two Way Power Each unit offers the convenience of two way power. They can operate by using either AA Alkaline batteries, or optional rechargeable NiMHD batteries. CW, 270Hz, 1-kHz, & 2-kHz Modulation Users can easily select between continuous wave (CW) or modulated frequencies with the push of a single key. Single Key Operation Ease of operation is provided for by single key entry for wavelength selection, and CW or modulated frequencies. Hand-Held, Battery Operated for Field Use Don't get stuck away from the truck with dead batteries; your AA batteries last longer, and our low battery indicator is an early warning system that gives you plenty of time. Soft Carrying Case Each unit includes a padded carrying case with a strap, belt-loop and window allowing convenient use of unit while in the case.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	wilcom
Model	f 1318
