Wiltron/anritsu 360b Vector Network Analyzer Vna Sm5399 3622a 68069b 68037b

US $35,999.00

Singapore, none, Singapore
Mar 4th

Open on mobile:
QR code

WILTRON/ ANRITSU 360B VECTOR NETWORK ANALYZER VNA MODEL 360C3 MILLIMETER-WAVE SYSTEM CONSOLE with SM5399 3622A 68069B 68037B Product Features The 360 VNA (Vector Network Analyzer) VNA measures the S-parameters, gain, phase, and group delay characteristics of a wide variety of microwave components, systems, and subsystems. On-wafer measurements are becoming increasingly important in the microwave industry. Modern MMIC designs have opened the way to cost reduction and industry expansion in both military and commercial applications. The Anritsu 360B and 37XXXA/B series Vector Network Analyzers are used to make accurate, high-speed on-wafer measurements in both R&D and production environments. Rather than relying on models based upon low frequency measurements, the 360B VNA permits actual measurement of MMIC performance and accurate characterization of active and passive on-wafer components to 110 GHz. Product Manual Unit's Specifics Make: Wiltron/ Anritsu Model: 360B Type: Vector Network Analyzer/ VNA Cabinet: 360C3 Millimeter-Wave System Console System consists of the following components: Wiltron Model 360B Network Analyzer (Please refer to photos for Error Report, PROM and RAM checks etc.) Options Installed: 2A High Speed Time Domain 3 LRL/LRM Calibration 4 Multiple Source Control Comes with the Basic Measurement Software Version T04.06 w Option 2 Time Domain shown Anritsu SM5399 Millimeter Multiplexer Test Set Wiltron 3622A Active Device Test Set 40MHz to 60GHz (SM5398) Wiltron 68069B Synthesized CW Generator 10MHz to 40GHz (SM5321) Firmware V3.37 Option 14 Passes All Self-Tests Wiltron 68037B Synthesized CW Generator 2GHz to 20GHz (SM5321) Firmware V3.37 Option 14, 15A Passes All Self-Tests Note: You will receive the actual unit shown. All/only components/modules/cables/accessories shown are included Description This unit is used and in overall good physical condition (except the cabinet's filter needs to be changed and mouldy dots on the screens of the Wiltron 68069B and 68037B). The system can be powered up as shown and it was pulled from a working environment. As we do not have the technical expertise to further test the unit, we are selling it on an "AS IS BASIS". Inspection is available, or if you'd like us to perform further tests/checks, please write to us with your set of instructions. We'd also consider offers for individual components of this VNA system. Please email us for details. Shipping We ship worldwide. We also help to arrange affordable freight options and professional crating services for this shipment. Please email us for details. My Store | Follow us on Twitter for Real-Time Inventory Updates | Contact Us

“Used, powers up successfully, includes all components/modules/cables/accessories shown, see description for further details on each module”

Model	360B/ SM5399/ 3622A/SM5398/ 68069B/SM5321/ 68037B
Type	Vector Network Analyzer/ Signal Frequency Source
MPN	360B/ SM5399/ 3622A/SM5398/ 68069B/SM5321/ 68037B
Brand	Wiltron/ Anritsu
