Wire Edm Large Part Fixture

US $295.00

  • Rochester, New York, United States
  • Jan 30th
Open on mobile:
QR code
Wire EDM Large Part Fixture All parts are made with 420 stainless steel and hardened to 45-55 RC (unless specified) precision ground +/-.0002" flat/parallel. 1- Fixture 2- Sloted clamp  5mm SHCS(stainless)  for mounting clamps, and a stop  5mm set screws(stainless) for holding part Hieght is 2 inch, width is 2 inch, lenght is 6 inch part step is 1.25 inch X 1.25 inch  (size may vary) The two screw counter bores are for 8mm x1.25 screws and they are 50mm apart. both clamps are tapped for 5mm screws and all the tapped holes in the fixture are 5mm  Feel free to ask any questions. PayPal is the desired form of payment. We will also except check or money order. also willing to offer terms on payment with final payment due on delivery(COD). Work will begin once payment is received. Send us a message if you would like to pay without using PayPal or have an interest in setting up payment terms. Thanks Brad B.
