Wireless Bluetooth Transeiver Rf Module For Arduino 51 Avr Pic 5v Hc-06 V1.06

US $7.58

Hong Kong, Hong Kong
Jan 29th

Open on mobile:
QR code

a¦aЂ“a°a?a»a?a§a 1/2 aЂ~a©a?aµ 6 5V HC-06 V1.06 Wireless Bluetooth Transeiver RF Module For Arduino 51 AVR PIC Description: 100% brand new and high quality Quantity:1pc Weight:7 g Color: as picture show Size:35mm x15mm /1.38"x0.59"(inch) (approx) Product Features: 1. The core module HC-06 main modules, leads the interface includes VCC, GND, TXD, RXD, KEY pin high trigger to clear the pairing information re search 2. led indicate Bluetooth connection status, flash unpaired slow flash indicates paired but not slave connection, Always follow machine connected 3. Backplane settings LDO input voltage of 3.6~~6V unpaired current is about 30mA, paired 10mA, input voltage prohibit more than 7V absolute prohibition of reverse power! 4. Interface level 3.3V, can be directly connected the various SCM (51, AVR, PIC, ARM, MSP430, etc.), the 5V MCU also can be connected directly, without MAX232 can not go through the MAX232! 5. Open to effective distance of 10 meters, over 10 meters is also possible, but not of this the quality of the connection of the distance do to ensure 6. The pair later when full-duplex serial use, do not need to know anything about the Bluetooth protocol, but only supports 8 data bits, 1 stop bit, no parity communication format, which is the most commonly used communication format does not support other formats. 7. Support to establish a Bluetooth connection through AT commands set the baud rate, passkey, set parameters are saved after. Bluetooth connection is automatically switched to the pass-through mode 8. Compact. Sets transparent shrink tube , dust and beautiful, and there are certain anti-static capabilities. 9. The link for the host, only paired with HC06 slave host can not match. Note, please attention! 1. When this module is master, it can only match with HC06 slave, and master can't match with master. And at the same time, it can match with the devices such as mobile phones or computer. 2. It can match with slave automatically, when connected with the power next time, it can only match with the previous slave, if use other slave, you need KEY pin input, and at lease 100 ms high level pulse. 3. It can't be searched by other bluetooth devices. 4.The order to revise the title is invalid. NOTE ! ! ! Please don't connect the power supply to the signal feet, it will burn directly!! Module and microcontroller follow the connection below please If AT.EXE not run . Please download dotnetfx. After installation you can run. Please don't terminate in the installation process. If you terminate it , may be be causing unknown problems Download 1 Download2 Package includes: 1pc 5V HC-06 V1.04 Wireless Bluetooth Transeiver RF Module Payment: We accept payment through Paypal ONLY. If you do not have Paypal account, please registered with (http://www.paypal.com) Payment must be received within 5 days after auctions ended. Please do not bid if you are not intending to buy. Unpaid dispute will be filed to ebay for the non payable bidders. Shipping and handling::
