Wireless Nfc Reader - µfr Nano Online - Wifi, Bluetooth, Usb Connectivity

US $109.00

Poarevac, Serbia
Jul 19th

Open on mobile:
QR code

Wireless NFC Reader - µFR Nano Online NFC Reader module with WiFi (TCP/IP, HTTP, UDP), Bluetooth (Serial, HID, BLE), Ethernet, UART TTL, RS232, USB, RTC (Real Time Clock), external EEPROM, and I/O. Wireless NFC Reader “µFR Nano Online” is a cross-platform NFC Reader/Writer based on Digital Logic’s proprietary API and communication protocol, combined with an ESP32 system on a chip microcontroller. ESP32 add-on hardware makes the “µFR Nano Online” a unique new product in our portfolio featuring NFC Reader/Writer with USB, RS232 (UART TTL), WiFi, Ethernet, and Bluetooth connectivity, RTC (Real Time Clock), external EEPROM, user-controllable beeper and RGB LEDs, 6 pin IO Port (3 pins for input/output, 2 pins for input only and 1 pin for output only) and one port for connecting an additional µFR Nano RS232 NFC Reader. All this fits in a single compact housing with dimensions of only 86 x 27 x 10 mm. SDK (Software Development Kit) and API (Application Programming Interface) are cross-platform so our device can be used on most major operating systems and popular hardware platforms as well. Wireless NFC Reader “µFR Nano Online” is completely backward-compatible with our other uFR Series devices so our existing clients can quickly and easily upgrade to the new device with no changes in their code, while new API set related to network connectivity is intuitive and easy to implement. Introducing ESP32 in this scenario enables users to write their own code for ESP32 in Arduino-like IDE and make a fully standalone working device that can act autonomously. Software with SDK The reader comes with a fully-featured SDK which consists of external libraries, software examples with source codes, documentation about API reference and communication protocol, and some useful software tools. Libraries are cross-compiled for various platforms and regularly supported are Windows x86/x64 UWP, Linux x86/x64, Mac OSX x64, ARM/ARM HF, and Arduino. Other platforms can be supported as custom releases, on customers’ demand, depending on the existence of the project or partnership relation. Software examples are divided into three stages according to complexity, with some new additions of NFC examples. All examples are written for all major developing platforms and languages, such as: Java (and Java Applet example), JavaScript (unique feature, convenient for PHP usage), Lazarus, Borland Delphi, C++ Borland Builder, Microsoft® Visual .NET family: C++, C#, VB Python Arduino IDE examples Other programming languages examples can be obtained on customer demand, depending on the existence of project or partnership relation. The software package includes a set of very useful applications intended for everyday use, like: Application for programming and manipulation of NFC compliant cards like NTAG and MIFARE Ultralight®, with source code, included. Android NFC phone App - Android NFC phone Application for MIFARE® card reading. Write a card with uFR, read it with an NFC phone! Card Formatter - application for card/tag formatting and programming uFR2FileSystem - keyboard simulation, card data reading, card data parsing into several formats, and sending data to MySQL database via HTTP. Application for NTAG and MIFARE Ultralight® card programming and manipulation. Application for creating and writing common NDEF messages into NFC tags and cards Reader Keys application – for easy manipulation of keys stored in the reader Application for managing DESFire cards Examples of credit card use with a reading of public data Shell-like environment for easy testing and automation Web extensions for Chrome, Firefox, and Opera The documentation contains fully explained API reference and communication protocol reference with real “hands-on” byte level examples for implementing communication protocol. However, API is a much more comfortable and recommended way of implementation. Where not possible, implementation of communication protocol is a very good alternative, especially when using the RS232 model. All libraries, software examples, tools, and documents are regularly updated. They are totally FREE and can be obtained through the download section of the company’s website. Our support team always provides quick responses, usually not more than 24 hours, which also depends on the complexity and the question itself. We can also provide custom solutions based on each customer's needs, so please free to contact us for any questions or further help regarding your projects and implementation. Device models Standard model - WiFi (TCP/IP, HTTP, UDP), Bluetooth (Serial, HID, BLE), USB, and external EEPROM. Advanced model - WiFi (TCP/IP, HTTP, UDP), Bluetooth (Serial, HID, BLE), Ethernet, UART TTL, RS232, USB, RTC (Real Time Clock), external EEPROM, and I/O. Configuration options Wi-Fi - Standard device model with Wi-Fi configuration. Can be reconfigured into any other mode except Ethernet. Wi-Fi + Bluetooth Serial - Standard device model with Wi-Fi and Bluetooth Serial configuration. Can be reconfigured into any other mode except Ethernet. Bluetooth Serial - Standard device model with Bluetooth Serial configuration. Can be reconfigured into any other mode except Ethernet. Bluetooth HID - Standard device model with Bluetooth HID configuration. Can be reconfigured into any other mode except Ethernet. Bluetooth BLE - Standard device model with Bluetooth BLE configuration. Can be reconfigured into any other mode except Ethernet. Ethernet - Advanced device model with Ethernet configuration. Package content 1x µFR Nano Online NFC Reader 1x Micro USB cable 1x Ethernet adapter (For Ethernet configuration only) 5x ISO14443 contactless cards Shipping and delivery Buyers can choose from two available shipping services: Free shipping DHL Express Free shipping - registered airmail service. The average delivery time for registered airmail service is 15-30 business days. DHL Express - Expedited shipping service for the additional price of $24. The average delivery time for DHL Express is 3-7 business days. Important notice: "Business days" implies Monday to Friday. Saturday and Sunday are not considered business days. Average delivery time does not include delays caused by: National holidays, Customs delays, Force Majeure events, etc. related to all transit countries. Customs duties & taxes Buyers are responsible for eventual Custom fees, import duties, and/or any local taxes.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	uFR Nano Online
Equipment Connection	Bluetooth, USB, Ethernet, Wireless
Country/Region of Manufacture	Serbia
Brand	Digital Logic
MPN	uFR Nano Online
Equipment Type	RFID Reader, NFC RFID Reader Writer
